SportsPlay Equipment 111-201 Manual

PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
must be installed in accordance with these instructions.
against Bill of Lading and Parts list.
reported to your distributor within 10 days of receipt of your order.
properly installed and maintained, equipment will give many years of Safe,
Trouble-Free use.
must be tightened and broken parts must be replaced as they can possibly
create dangerous situations leading to unnecessary accidents.
Surfacing should be used under all playground equipment.
these instructions for maintenance and replacement part purposes
Appropriate publications, available at no charge, from the Consumer Product
Safety Commission, include "A Handbook for Public Playground Safety".
can receive your free copy by calling 1-301-504-7908 or at www.cpsc.gov.
can get a copy of the ASTM standards for Play Equipment and Safety surfacing
at www.astm.org
Safety Surfacing - Use of safety surfacing in compliance with
ASTM specification F1292 is required. Contact your surfacing
supplier for required surfacing depth for this equipment.

PACKING LIST

1 CTN 1
8 503-637
1 CTN 2 103-038A
1 SKID 2 113-044
2 CTN
SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
111-201 PLAY HOUSE

IMPORTANT

Periodically check for loose or broken parts.
Hardware Bag
Anchor
Grille
Shell
1 SKID 3 TOTAL PCS
www.sportsplayinc.com
Check your shipment
Any missing or broken parts must be
Retain a copy of
12 116-530 5/16" x 1" Button Head Bolt
16 116-540 5/16" x 2" Button Head Bolt
28 326-501 5/16" Lock Washer
52 316-601 3/8" Flat Washer
28 216-512 5/16" Button Head Nut
2 105-210 Angle Bracket
2 416-350 3/16" Socket Key
2 805-532 Warning Label
2 805-534 MFG Label
Weight 400#
1
Page
Rev. 05/21/2010
All equipment
When
Loose bolts
Resilient
You
You
HARDWARE BAG
Class 70
