Image Sensor
Sensitivity MEMRECAM Q1v
ISO 8,000
(720lx, F4, 1000frames/sec, shutter 1/1,000s, Digital Gain: NORMAL)
Color
ISO25,000 (After HXLink Ver1.92a, Recording Priority: Sensitivity )
(231lx, F4, 1,000 frames/sec, shutter 1/1000s, Digital Gain: NORMAL)
ISO 50,000
(115lx, F4, 1000frames/sec, shutter 1/1,000s, Digital Gain: NORMAL)
B/W
ISO160,000 (After HXLink Ver1.92a, Recording Priority: Sensitivity )
(36lx, F4, 1,000 frames/sec, shutter 1/1000s, Digital Gain: NORMAL)
* The brightness of the subject is the brightness when the output signals reach 100% for the
subject at a reflectance of 89% and the f-stop value is the aperture stop for the lens at that
time.
● Above sensitivity is at 1,000fps (full resolution). In specific combination of
framing rate and resolution, the sensitivity could be lower by Max. 20%.
4-6
(00375)H
