Specifications

24V Hi-G BATTERY
Battery
Drive Time
Charge Time
Refresh Time
External Dimensions
(W×H×D)
Weight
Operating Temperature
and Humidity
Storage Temperature and
Humidity
Vibration
Impact
Applicable Standards
Status LED
STATUS
● Since there are individual differences between batteries and the ambient
temperature has an effect, the status LED display should be used as a target.
(00375)H
Battery Used:
Nominal Voltage:
Nominal Capacity:
Life:
About 50 minutes (reference value with Q-HUB+Q1m/Q1v 4 (no
options), new battery, fully charged)
About 2 hours 20 minutes (using the dedicated charger)
About 1 hours 50 minutes (using the dedicated charger)
About W158×H47×D135mm (excluding the connector and
protruding parts)
About 2.1kg (excluding the accessories)
Charge: +5 to 35°C, 30 to 80%RH (no condensation)
Discharge: +5 to 40°C, 30 to 80%RH (no condensation)
-20 to 30°C, 20 to 80%RH (no condensation)
Conforms to MIL-STD-810C METHOD 514.2 CATEGORY b2
(RANDOM VIBRATION ENVELOPE) FIGURE 514.2-2A
Half sine, 11msec, 150G,6 shafts total of 1000 times
CE, FCC
Green: Remaining H
Orange: Remaining M
Red: Remaining L
7-13
NiMH battery
DC 24V
4.5Ah
1 year
(Target replacement at 1 year due to the
tremendous variation in ambient temperature
and use environment)
