Connect the Equipment and Cables
Connect the Windows PC for Control
Use the Ethernet to connect to a PC.
Connect the simple J3 cable to the UP LINK connector
● Connect the simple J3 cable or the J3 splitter cable (sold
separately) to the REMOTE connector.
2
Connect the Ethernet cable to the simple J3 cable Ethernet
connector. Connect to the Windows PC.
● Connect the Ethernet cable to the Ethernet connector
(RJ45) of the simple J3 cable. Connect the other
Ethernet cable to the Windows PC.
6-14
(00375)H
