Important Notes & Warnings - Bromic Heating Smart-Heat Control On/Off 1 CH Installation And Instruction Manual

IMPORTANT NOTES & WARNINGS
! WARNING
• Read all instructions before installing or using this controller.
• Use this controller only as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric
shock, or injury to persons.
• Improper installation, adjustment, or alteration and failure to follow
the warnings and instructions in this manual could result in severe
personal injury, death or property damage.
• The manufacturer is not responsible for any damage that could
happen from improper use. The manufacturer emphasises that
this controller should be used in a responsible manner and that
all procedures, warnings, and safety instructions contained in this
booklet be followed strictly.
• The storage temperature for the product is between -30°C (-22°F)
and 70°C (158°F). This temperature range is applicable when the
product is not in use for extended periods (e.g. summer).
• The product must be fixed on surfaces that cannot be damaged
by temperatures as high has 60°C (140°F). It must be installed in a
well-ventilated location. It cannot be hermetically closed. It must be
installed out of reach, and if wall mounted, it must be vertical with
cable glands downward.
• The connection cables must be protected against any accidental
impacts.
• This controller is not intended for use in bathrooms, laundry areas
and similar indoor locations. Never locate controller where it may
fall into a bathtub or other water container.
• Do not install the controller directly near a bathtub, shower, or
swimming pool.
• Do not install controller where children may gain access to it.
• This controller is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities or
lack of experience and knowledge unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Keep packaging materials out of reach of children.
• Children and adults should be alerted to the hazards of
electrocution and stay away to avoid serious personal injury.
• Children should be carefully supervised when they are in the
controller area.
• Do not attempt to alter the controller in any manner.
• Do not paint any surface of the controller.
• Do not touch the controller with wet hands at any time.
• Do not use or store flammable materials near this appliance.
• Do not spray aerosols or flammable materials near the controller
while it is in operation.
• Never operate the controller in an explosive environment, such as
areas where petrol or other flammable liquids or vapours are stored.
• Do not hang any foreign items off any part of this controller e.g. do
not hang towels, clothing, lines, lights, cables.
• Always ensure the controller and any connected devices has been
switched off for 2 hours before touching any attached heat sink.
INSTALLATION
• IMPORTANT - Installation must be carried out by a licensed and
authorized electrical technician.
• The installer is to ensure that the requirements of the local
authority, local electrical installation code, municipal building codes,
and any other relevant statutory regulations are carried out.
• After unpacking, make sure the controller shows no signs of visible
damage or tampering. If the controller appears damaged, contact
the place of purchase for assistance.
• Remove transit protection before use.
• This appliance must only be used on a 100 - 277 Volt AC electricity
supply.
6
• This controller is NOT intended to be installed on recreational vehicles
and/or boats.
• Do not run cords under carpeting. Do not cover with throw rugs,
runners or the like. Arrange cords away from the traffic area and
where it will not be tripped over.
• A controller has hot and arcing or sparking parts inside. Do not use it in
areas where gasoline, paint or flammable liquids are used or stored.
• This Installation and Operation manual should not be removed from the
installation site. Installer should leave the manual with the customer for
future reference.
• If the controller has not been used, or will not be used, for an extended
period, disconnect the power supply.
• For the disconnection from the power line, use an all-pole switch with
contacts having a dimension of at least 3.5mm.
MAINTENANCE/ REPAIR
• This product has no serviceable parts and must not be opened after
installation is complete.
• Installation must be carried out by a qualified & licenced service
person only. The controller should be inspected before use and at least
annually inspected by a qualified & licenced service person.
• Check for damage to the controller regularly. If damage to the
appliance is suspected, discontinue use immediately and contact the
supplier.
• At the end of this product's useful life, it must not be disposed of as
domestic waste but must be taken to a collection center for waste
electrical and electronic equipment. The user is responsible for disposal
of this appliance through the appropriate channels at the end of its
useful life. Failure to do so may incur the penalties established by
laws governing waste disposal. Proper differential collection and the
subsequent recycling, processing and environmentally compatible
disposal of waste equipment avoids unnecessary environmental
damage and possible related health risks and promotes recycling of
the materials used in the appliance. For further information on waste
collection and disposal, contact your local waste disposal service, or
the place of purchase.
ELECTRICAL CONNECTIONS
• All connections must be rated for the power rating of the control model
and heater model being installed. Connection must have an earth
connection.
• Arrange all the necessary safety devices and use only materials that
comply with standard electrical installations.
• Low voltage circuits and wiring must be separated from the other circuits.
• The supply circuit must include an isolation switch and/or circuit
breaker in accordance with local electrical regulations. In the US, a
2 pole isolation switch and/or circuit breaker must be installed for 2
phase electrical supplies.
• To maintain Ingress Protection Rating (IP54), only suitable IP54 (or
better) rated outdoor plug & sockets should be used for electrical
installation. The product must be protected from direct contact with
water.
• A readily accessible disconnect device shall be incorporated into the
building installation wiring.
• This product does not have a switch for electrical disconnection. A
means for disconnection of the control must be incorporated in the
fixed wiring according to the local electrical codes.
• The cable must have a section properly rated according to the load
connected and a nominal temperature range of up to 90°C (194°F).
• The Smart-Heat Control Dimmer will regulate output power by
switching off the load if temperature in the heat sink exceeds 80°C
(176°F).
• The maximum power per channel is 6000W. Refer to page 15 for
amperage capacity based on supply voltage.
• 100 - 127V AC supplies are for gas heaters only and may only be used
with the Smart-Heat Control On/Off . The maximum amperage per
channel when installing gas heater is 10A.
