Bromic Heating Smart-Heat Control On/Off 1 CH Installation And Instruction Manual page 16

HEATER TYPES & LOAD DISTRIBUTION
If you intend to control two elements from a single heater independently, refer to the element
loads below, as well as applicable heater instruction manual for wiring diagrams. If this is not the
case simply refer to the total appliance load listed below.
Heater Power
4000W (2 elements)
4500W (2 elements)
6000W (2 elements)
Supply Voltage (AC 50-60Hz)
100-127V
16
Step 3 – Continued ... (2 Element Heaters)
Supply Voltage (AC 50-60Hz)
200V
208V
220-240V
277V
200V
208V
220-240V
200V
208V
220-240V
277V
Load distribution for applicable Bromic gas heaters
(Only compatible with Smart-Heat Control On/Off models)
Load produced per
Heater
1A
Maximum Load per Control
Channel
10A
bromic.com
CONTINUED...
Maximum Appliance Load
Element 1: 10A
Element 2: 10A
Total: 20A
Element 1: 9.5A
Element 2: 9.5A
Total: 19A
Element 1: 8A
Element 2: 8A
Total: 16.5A
Element 1: 7A
Element 2: 7A
Total: 14A
Element 1: 7.5A
Element 2: 15A
Total: 22.5A
Element 1: 7A
Element 2: 14A
Total: 21.5A
Element 1: 12.5A
Element 2: 6A
Total: 18.5A
Element 1: 15A
Element 2: 15A
Total: 30A
Element 1: 14A
Element 2: 14A
Total: 28.5A
Element 1: 12.5A
Element 2: 12.5A
Total: 25A
Element 1: 10.5A
Element 2: 10.5A
Total: 21.5A
