PACKAGING CONTENTS
Model
On/Off 1-Channel
&
On/Off 2-Channel
&
Eclipse Pendant 1-Channel
Dimmer 1-Channel
&
Dimmer 2-Channel
On/Off 5-Channel
&
Dimmer 5-Channel
&
Eclipse Pendant 5-Channel

TOOLS/PARTS REQUIRED

• 4 x Fasteners appropriate for mounting
(1CH+2CH models - 4.5mm / 11/64" diameter holes)
(5CH models - 7.0mm / 17/64" diameter holes)
• [Dimmer models only] Crimping tool.
• [Dimmer models only] 10mm / 7/16 socket.
• Extra cable glands to suit desired wiring.
10
Accessory Bag Contents
2 x M25 Cable Gland (4 x supplied with 2-Channel)
5 x M4x10 Screw
5 x Spring Washer
2 x M25 Cable Gland (4 x supplied with 2-Channel)
4 x Plastic Washer (8 x supplied with 2-Channel)
4 x M6 Ring Terminal (8 x supplied with 2-Channel)
5 x M4 Screw
5 x Spring Washer
2x Jumper Wire M6 Ring to M6 Ring (2-Channel only)
1 x Doublebit Key
4 x Mounting Bracket & Screws
1 x L-Shape Busbar
3 x Straight Busbar
16 x M6 2.5-4mm2 / AWG 12-14 Ring Terminal
3 x M6 4-6mm2 / AWG 10-12 Ring Terminal
4 x M6 10-16mm2 / AWG 6-8 Ring Termal
1x M40 Cable Gland
5x M25 Cable Gland
3x M16 Cable Gland (8 x supplied with Eclipse Pendant)
15x Spring Washer
1 x Jumper Wire for BMS
