- Page 1 USER MANUAL VIRON 1 ENDOSCOPY CAMERA 80860-002_EN_V001 2022-07...
- Page 2 Erbe Swiss AG Fröschenweidstrasse 10 8404 Winterthur...
- Page 3 USER MANUAL VIRON 1...
- Page 4 User Manual may be reproduced in any form (by photocopying, microfilming or other methods) or processed, duplicated or disseminated by the use of electronic systems without the written consent of Erbe Vision GmbH. The information contained in this User Manual can be changed or expanded without prior notice and without obligation on the part of Erbe Vision GmbH.
-
Page 5: Table Of Contents
Table of Contents Table of Contents Safety instructions........7 Safety instructions and levels of danger . - Page 6 Table of Contents Snapshot image files ..........34 Record video files.
-
Page 7: Safety Instructions
1 • Safety instructions Chapter 1 Safety instructions Safety instructions and levels of danger IMPORTANT! Please read these safety instructions carefully, before using the camera system on a patient, it is extremely important that you are familiar with the equipment operation and control. - Page 8 1 • Safety instructions WARNING! To avoid the risk of electric shock, this equipment must only be connected to supply mains with protective earth. WARNING! When endoscopes are used with energized endotherapy devices, patient leakage currents may be additive. It must be noted that this is particularly important if a type of CF applied part endoscope is used.
-
Page 9: General Information
2 • General information Chapter 2 General information This user manual is valid for the following article no. 10800-002, 10801-002, 20800-002 Fig. 2-1 / 44... -
Page 10: Symbols
2 • General information Symbols Symbols Meaning Caution, observe ACCOMPANYING DOCUMENTS Potential equalization Refer to instruction manual (the symbol is in blue color) A hyperlink underneath this symbol indicates the location of the electronic instructions for use. Type BF applied part Mains/line fuse Alternating current (AC) On (power supply, connection to mains/line) - Page 11 2 • General information Symbols Meaning Keep away from sunlight Keep dry Order reference number Serial number Unique Device Identification Device is subject to the requirements of waste electrical and electronic equipment (WEEE) Directive, 2012/19/EU Indication that this is a medical device. Identification in conformity with Medical Devices Regulation 2017/745.
-
Page 12: Intended Use
2 • General information Intended use The VIRON 1 - endoscopy camera is intended to produce video images in the medical endoscopic operation procedures. The camera accepts all standard C-mount lenses and outputs HD video signals which can connect to a HD video monitor or a HD video capture frame grabber of a computer- based imaging system. -
Page 13: Electromagnetic Compatibility (Emc)
Guidance and Manufacturer's declaration Guidance and manufacturer's declaration - electromagnetic emissions The VIRON 1 is intended for use in the electromagnetic environment specified below. The customer or the user of the VIRON 1 should assure that it is used in such an environment. - Page 14 2 • General information Guidance and manufacturer's declaration - electromagnetic immunity The VIRON 1 is intended for use in the electromagnetic environment specified below. The customer or the user of the VIRON 1 should assure that it is used in such an environment.
- Page 15 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Model 006 is used exceeds the applicable RF compliance level above, the VIRON 1 should be observed to verify normal operation.
- Page 16 Recommended separation distances between portable and mobile RF communications equipment and VIRON 1 The VIRON 1 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the VIRON 1 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and VIRON 1 as recommended below, according to the maximum output power of the communications equipment.
-
Page 17: Illustration
3 • Illustration Chapter 3 Illustration Front view VIRON 1 camera front view Fig. 3-1 Power ON/OFF switch "|" is on and "O" is off. (After turning on the power, the green indicator is lit.) White balance button / black balance function... -
Page 18: Camera Rear View
3 • Illustration Camera rear view VIRON 1 camera rear view Fig. 3-2 Power input connector (with double fuse holder) Socket for potential equalization PS/2 Keyboard Connector RS-232 communication port RGB/YPbPr, VGA (RGBHV) analog output Reserved Acc. (REC. / PRT.) control output... -
Page 19: Camera Head
3 • Illustration Camera head Fig. 3-3 Camera head Control buttons on camera head C-Mount interface for lens Camera cable Camera plug Protection cap for camera plug / 44... -
Page 20: Setup
4 • Setup Chapter 4 Setup WARNING! The device is not protected against explosions. Do not operate this device in areas where there is a danger of explosion. WARNING! The device is not intended to be used in an oxygen rich environment. WARNING! No modification of this equipment is allowed. -
Page 21: Preparation
Disconnect and connect after powering off. Power on after confirming properly connected the camera head. IMPORTANT! This camera head must be connected only to the VIRON 1 camera controller. Do not combine this camera head with other camera controller. IMPORTANT! -
Page 22: Connecting The Camera Head To The Camera Controller
4 • Setup Connecting the camera head to the camera controller A protection cap has been put on the camera plug for the factory setting. The following figure shows how to unplug the protection cap. Hold the protection cap with one hand and use the other hand to hold the middle of the camera plug and pull it directly from the protection cap. -
Page 23: Connecting The C-Mount Lens Or Adapter
When the endoscope is connected, normally a light source for illumination will be needed. This coupler must be connected only to the Erbe Vision camera head. Do not combine this coupler with other camera head. NOTE! When operating the camera, turn around the camera head so the control buttons are on top (indicated as in the following Figure 4-2) to avoid a tilted image. -
Page 24: Checks
5 • Checks Chapter 5 Checks IMPORTANT! Run through the checks before and after each use. Do not use the products if they are damaged, incomplete or have loose parts or accessories. Before every use of camera head, check through the camera completely to ensure there are no unintended rough surfaces, sharp edges or protrusions on the camera head. -
Page 25: Use
6 • Use Chapter 6 WARNING! During operation of the camera, do NOT touch the patient and any signal connector of the camera, such as video output connectors. WARNING! Before each use or after a change of viewing modes / settings, the user must check to ensure the view observed through the camera provides a live image (rather than a stored one) and has the correct image orientation. -
Page 26: Working Modes (Settings For Different Users)
When the endoscope, light source or other working condition is changed, please use the correct settings for the corresponding working condition. The HD endoscopy camera VIRON 1 provide seven surgery modes (or called user settings) for seven users or surgery conditions. Each user settings can be adjusted... -
Page 27: Camera Head Control
6 • Use Camera Head Control WARNING! Orientation or movement related functions, such as FREEZE, MIRROR, FLIP, ROTATION may increase risk by intentionally or unintentionally use. Extra attention must be paid if these functions are assigned on the camera head buttons. Always view the on-screen display information to make sure the correct image is achieved. - Page 28 6 • Use Function Description Automatic black balance, same function as pressing and holding button for about 3 seconds. FREEZE Freeze or unfreeze the image. ZOOM UP Increase the digital zoom value, step 0.1 ZOOM DOWN Decrease the digital zoom value, step 0.1 ZOOM LOOP Set digital zoom magnification.
-
Page 29: On Screen Display (Osd) Menu
6 • Use On Screen Display (OSD) Menu NOTE! The on-screen display (OSD) menu provides very rich functions for camera settings. Only the user who has the technical background is recommended to do the parameter adjustment. When the power turns on, the normal screen shows only the live image without OSD menu. -
Page 30: Menu Page - Process
6 • Use Gain Mode Gain Steps Gain dB Value Auto (Max. Gain) MIDDLE HIGH Manual (Gain) MIDDLE HIGH Menu page - PROCESS Video level adjustment: 0 to 100 USER: LAP 10 mm Window selection: Small, -- 2 PROCESS -- Middle, Large →... -
Page 31: Menu Page - Head Key
6 • Use Menu page - HEAD KEY NOTE! The user defined functions of camera head keys and OSD buttons on controller work only when the OSD menu is off. During OSD menu on status, the keys are used for operating the OSD menu. Function for short pressing USER: ALL USERS on the “Left”... -
Page 32: Returning To Factory Settings
6 • Use Returning to factory settings IMPORTANT! This operation will completely remove the parameter settings of the current user to the factory default settings. 1. Select a working mode (or user) to set to the factory default status by briefly pressing the button on the control unit. -
Page 33: Using Digital Video Recording (Dvr) Function
6 • Use The following commands are used for entering on-screen patient information with the external keyboard: Command Function [F1] Help; to show the description of the commands [F2] Start a new patient ID [F3] Refresh current patient information [ESC] Hide the on-screen patient information;... -
Page 34: Requirement Of Usb Disk
6 • Use Requirement of USB disk The USB disk must have at least USB version 2.0 high speed or higher version, the writing speed of USB disk must be at least 30M byte per second, lower writing speed may cause frame drops or other issues. The USB disk must be format as FAT32 file system, other file systems are not supported by the DVR. -
Page 35: Reprocessing And Maintenance
7 • Reprocessing and maintenance Chapter 7 Reprocessing and maintenance Reprocessing of the camera controller WARNING! Do NOT use the camera controller in high humidity environment. (See the specification about the operation environment). Danger of electric shock. Before reprocessing switch off the device and disconnect it from the power supply. Clean the device with a soft cloth moistened with surface disinfectant, alcohol, or spirit. -
Page 36: Reprocessing Of The Coupler
7 • Reprocessing and maintenance Reprocessing of the coupler IMPORTANT! • This coupler must be cleaned by clean water or alcohol prior to the first use as well as before each subsequent use. • Cleaning must follow the instructions provided in this manual. Using unspecified cleaning method may result in incomplete cleaning or damage of the coupler. -
Page 37: Technical Information
8 • Technical information Chapter 8 Technical information Troubleshooting IMPORTANT! If you cannot eliminate the faults with the help of this table, please contact the service department or send in the device for repair. Do NOT attempt to do any repair yourself. Problem Possible reason Remedy... -
Page 38: Technical Data
IMPORTANT! Please note that any serious incident should be reported to the manufacturer and the national competent authority. Technical data General technical data Model VIRON 1 Standard 50Hz or 60Hz Progressive Resolution 1920 (H) x 1080 (V) Image sensor 1/3 Inch Minimal illumination <... -
Page 39: Compatibility Data (For Medical Application)
8 • Technical information Compatibility data (For medical Classification (according to Class I application) MDR 2017/745) Classification of applied part (camera head) Protection Class rating to IEC/EN 60601-1 Duty factor Continuous operation Degree of protection when used Device is not protected against explosions in the presence of flammable (Do not operate this device in flammable mixtures... -
Page 40: Technical Data Of Camera Controller
8 • Technical information Technical data of camera controller Degree of protection against the IP 20 (no protection) ingress of liquid Dimension 300 × 74 × 365 mm Connection for controller Push / pull plug Weight 4.5 kg Operating, storage, transport, and shipping conditions Conditions Operation conditions... -
Page 41: Replacing Parts And Disposal Rules
8 • Technical information Replacing parts and disposal rules Replace fuses CAUTION! The specification of the device fuses must correspond with the fuse ratings on the identification plate. Use only the fuses specified in the spare parts list. To replace fuses: •... - Page 42 8 • Technical information / 44...
- Page 43 8 • Technical information / 44...
- Page 44 Manufactured by Erbe Vision GmbH Eisenbahnstraße 102, 78573 Wurmlingen, Germany E-Mail: info@erbevision.com Website: www.erbe-med.com Service address: Erbe Elektromedizin GmbH Waldhörnlestraße 17, 72072 Tübingen, Germany E-Mail: techservice@erbe-med.com Tel.: +49 7071 755 - 437...
