USER MANUAL
VIO
300 D
®
V 2.7.x
ELECTROSURGERY
80113-751_V23791
2022-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIO 300 D and is the answer not in the manual?

Questions and answers

Related Manuals for Erbe VIO 300 D

Summary of Contents for Erbe VIO 300 D

  • Page 1 USER MANUAL 300 D ® V 2.7.x ELECTROSURGERY 80113-751_V23791 2022-07...
  • Page 3 USER MANUAL 300 D ®...
  • Page 4 Manual may be reproduced in any form (by photocopying, microfilming or other methods) or processed, duplicated or dissemi- nated by the use of electronic systems without the written consent of Erbe Elektromedizin GmbH. The information contained in this User Manual can be changed or expanded without prior notice and without obligation on the part of Erbe Elektromedizin GmbH.

  • Page 5: Table Of Contents

    VIO 300 D example accessories........
  • Page 6 Table of Contents Working with the Electrosurgical Unit: a Tutorial ....47 The tutorial and your electrosurgical system .......47 Make power connection, switch on unit, self-test, assignment of active program .
  • Page 7 Installing the unit on an Erbe cart ........
  • Page 8 Table of Contents Notes on electromagnetic compatibility (EMC) ....173 Guidelines for avoiding, recognizing and rectifying unwanted electromagnetic effects on other units or systems, which are the result of operating the VIO system.

  • Page 9: General Instructions For Use

    Compatibility The VIO 300 D can be combined with suitable Erbe units and modules (e.g. APC 2, EIP 2, ERBEJET 2), instruments and accessories. See the Accessories chapter for information on the compatibility of instruments and accessories.
  • Page 10 1 • General Instructions for Use / 182...

  • Page 11: Safety Instructions

    2 • Safety Instructions Chapter 2 Safety Instructions Safety notations DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 12: Compliance With Safety Information

     In the event of uncertainties or if you have any questions, please contact Erbe Elektromedizin. You will find the addresses in the ad- dress list at the end of this User Manual.

  • Page 13: Risks Due To The Environment

    2 • Safety Instructions Risks due to the environment Interference with the unit from portable and mobile HF telecom- munications units (e.g. mobile phones, WLAN units) Electromagnetic waves emitted by portable and mobile HF telecom- munications units may affect the unit. The unit may fail or not perform properly.

  • Page 14: Electric Shock

     Only connect the unit to a power supply network with proper grounding.  Only use the Erbe power cord or an equivalent power cord with a national quality symbol for this purpose.  Check the power cord for damage. You must not use a damaged power cord.

  • Page 15: Fire / Explosion

    2 • Safety Instructions Fire / explosion In electrosurgery electric sparks and arcs occur at the instrument. Flammable gases, vapors, and liquids can be set alight or caused to explode. DANGER Flammable anesthetics Risk of explosion to the patient and medical personnel! Risk of dam- age to property.

  • Page 16: Burns

    2 • Safety Instructions WARNING Active or hot instruments in contact with combustible materials Materials like gauze, swabs, and cloths can catch fire. Risk of fire to the patient and medical personnel! Risk of damage to property.  Do not bring active or hot instruments into contact with combus- tible materials.
  • Page 17 2 • Safety Instructions  For your safety and that of the patient: Never attempt to perform repairs or make modifications yourself. Any modification will in- validate liability on the part of Erbe Elektromedizin GmbH. WARNING HF leakage current flows through metal parts The patient must not have contact with electrically conductive ob- jects.
  • Page 18 2 • Safety Instructions CAUTION Hot instruments Even non-active instruments that are still hot can burn the patient or medical personnel.  Put instruments down in a safe place: sterile, dry, non-conductive, and easy to see. Instruments that have been put down must not come into contact with the patient, medical personnel, or com- bustible materials.
  • Page 19 2 • Safety Instructions WARNING Power setting too high, ON time too long, effects too high The higher the power setting the longer the ON time of the unit and the higher the effect the higher the risk of accidental tissue damage. Risk of accidental tissue damage to the patient! ...

  • Page 20: Inadvertent Tissue Damage

    2 • Safety Instructions WARNING Tissue structures / vessels with a cross-section that is small or becoming smaller If monopolar HF current flows through parts of the body with a rela- tively small cross-section, there is a risk of unintentional coagulation for the patient! ...

  • Page 21: Risks Due To Incorrect Use Of The Neutral Electrode

    2 • Safety Instructions CAUTION Electrically conductive implants can redirect or concentrate cur- rent flow. Risk of burns for the patient and possible damage to the implant.  In the case of patients wearing electrically conductive implants, consult the manufacturer of the implant or the relevant specialist department of your hospital prior to surgery.
  • Page 22 Chapter 2 of this Manual "Safety Fea- tures" for NESSY. Note: Erbe recommends the use of split neutral electrodes in combination with the NESSY setting set to “NE: dynamic” or “NE: dual surface”. With this combination the optimal use of the safety monitoring functions are given (see chapter 2 “NESSY Safety...

  • Page 23: Defective Unit

    36 A²s according to the manufacturer's specifications. These are, for ex- ample, the Erbe neutral electrodes NESSY Plate 170 (REF No. 20193-070, 20193-074) or NESSY RePlate 200 (REF No. 20193- 090).
  • Page 24 2 • Safety Instructions  Do not position the neutral electrode near cardiac pacemakers, in- ternal defibrillators, or other active implants. Interference with electronic units due to the electrosurgical unit The activated electrosurgical unit can affect the performance of elec- tronic units by causing interference.

  • Page 25: Damage To The Unit And Accessories

    "Notes on electromagnetic compatibility (EMC)".  If you are using accessories from other manufacturers, check whether the Erbe unit is interfering with other units or being af- fected by interference itself. You cannot use the unit if there is any interference.

  • Page 26: Notes

    However, the user surfaces remain fully functional. This does not present a hazard. Using a smoke evacuator Note: In order to evacuate the smoke that develops during electrosurgical procedures, Erbe recommends using a smoke evacuator. / 182...

  • Page 27: Safety Features

    3 • Safety Features Chapter 3 Safety Features NESSY What is NESSY? The unit is equipped with a Neutral Electrode Safety System (NESSY), which monitors the neutral electrode (neutral electrode), warns of critical situations, and thus prevents burns. How effective the monitoring is depends on whether you choose a single sur- face or dual surface neutral electrode and on the NESSY setting.

  • Page 28: Electrode

    3 • Safety Features A check of the connecting cable can be performed before use as follows: • Switch on the Unit. Set the NESSY setting to "NE: either way". Connect the cable to the neutral electrode socket. • If the connecting cable or the clip of a reusable cable do not have shorts the dis- play of the dual surface (1) and the display of the single surface (2) will light up red.
  • Page 29 Dual-surface neutral electrode To optimally utilize the unit's monitoring functions, Erbe recommends connecting a dual-surface electrode, and in particular the Erbe NESSY Omega electrode. Apart from connected. "Neutral electrode: many other advantages, this electrode virtually eliminates any possibility of excessive Dual surface"...
  • Page 30 3 • Safety Features If the currents differ too greatly from each other, the dual-surface electrode symbol on the VIO illuminates red. Monopolar mode cannot be activated. If you attempt acti- vation, an audible warning signal is emitted. A red warning message appears on the display: When applying the neutral electrode, ensure that the line of symmetry points toward the operating field.
  • Page 31 3 • Safety Features Checking function of the NESSY window when a dual-surface electrode is connected with "Neutral electrode: Dynamic" setup Fig. 3-6 If you press the Focus button on the neutral electrode socket, you change to the NESSY window. You will see a traffic-light symbol (1).

  • Page 32: Automatic Monitoring Of Equipment Output Error

    3 • Safety Features Automatic monitoring of equipment output error The unit is equipped with an automatic monitoring system for the HF output parame- ters. This system monitors any divergence between the actual value and the setpoint of the HF output parameters selected and emits warning signals or switches off the HF generator if the divergence is so great that the required quality of the respective effect (CUT or COAG) is no longer guaranteed.

  • Page 33: Protection From Operating Errors

    3 • Safety Features Protection from operating errors To prevent operating errors the front panel and the menus are designed so as to au- tomatically monitor and signal illogical or incomplete settings. All sockets of the applied part are arranged in the socket strip next to the front panel. These sockets are designed so that only connectors of the proper accessories can be inserted (provided that only the accessories supplied or recommended by the manu- facturer of the unit are used).
  • Page 34 3 • Safety Features / 182...

  • Page 35: Accessories

    Instructions are available in this chapter. The following offers an overview of example accessories for each accessory category. A complete overview is available in the Erbe accessories catalog and on the Erbe web- site. We recommend the use of Erbe accessories.

  • Page 36: Vio 300 D Example Accessories

    4 • Accessories VIO 300 D example accessories VIO 300 D Monopolar electrosurgical pencils, monopolar electrodes Neutral electrodes Bipolar instruments, bipolar forceps Connecting cables for electrosurgery BiClamp and BiClamp LAP forceps Adapters for electrosurgery / 182...
  • Page 37 4 • Accessories APC 2 (unit for argon-plasma coagulation) EIP 2 (irrigation pump) VEM 2 (module for socket extension) IES 2 (smoke evacuation) NT 2 (nerve stimulator) Accessories for ESU and modules / 182...

  • Page 38: Check Compatibility Of Instrument And Cut / Coag Mode With The Help Of The Upmax Display

    4 • Accessories Check compatibility of instrument and CUT / COAG mode with the help of the Upmax display CAUTION Electric load on instrument too high The instrument can be damaged. If the damaged area comes into contact with tissue, it can lead to unintentional coagulation.
  • Page 39 4 • Accessories Fig. 4-2 The AUTO CUT mode with Effect 8 would load the instrument with peak voltage of 740 Vp (1). Do not operate the instrument with Effect 8 of the AUTO CUT mode. The elec- trical capacity of the instrument (500 Vp) is less than the HF peak voltage (740 Vp) of the AUTO CUT mode with Effect 8.

  • Page 40: Check Compatibility Of The Neutral Electrode

    VIO D / VIO S series and special footswitches for the VIO C series. Adapter bipolar resection Intended use The adapter bipolar resection is used to connect bipolar resectoscopes to a VIO 300 D with MF socket. It allows the use of the BIPOLAR CUT ++ and BIPOLAR SOFT COAG ++ modes.
  • Page 41 2. Hold the magnetic inside of the adapter on the right wall of the VIO (socket side). The adapter sticks. 3. Connect the bipolar resectoscope with the Erbe bipolar cable for resectoscopes to the RESECTOSCOPE socket (2). BIPOLAR CUT ++ and BIPOLAR You must use the adapter to access the optimized BIPOLAR CUT ++ and BIPOLAR SOFT COAG ++ modes.
  • Page 42 4 • Accessories / 182...

  • Page 43: Description Of The Controls

    5 • Description of the Controls Chapter 5 Description of the Controls Controls on the front panel Fig. 5-1 Power (1) Power switch Unit on/off. The unit is only fully disconnected from the power supply once the power cord is pulled out. Install the unit such that the power cord could be easily disconnect- ed from the power source.
  • Page 44 5 • Description of the Controls Pilot lamps (16) Footswitch The footswitch symbol lights up when the respective footswitch is assigned to the scoket. (17) Auto Start When this lamp is lit up, Auto Start is active. (18) Neutral electrodes Single-surface or dual-surface neutral electrode connected.

  • Page 45: Controls On The Back

    (1) or socket (2). The same applies to the single-pedal footswitch. (3) ECB sockets (ECB means Erbe Communication Bus) You can connect other units to the electrosurgical unit, e. g. an APC or a smoke evac- uator.
  • Page 46 (4) Potential equalization terminal Connect a potential equalization line and connect this to the potential equalization system of the operating room. If you are using the Erbe VIO-CART, connect the poten- tial equalization line to the potential equalization pin of the VIO-CART.

  • Page 47: Working With The Electrosurgical Unit: A Tutorial

    VIO-CART. The tutorial is based on a sample In this tutorial you will learn how to operate the VIO 300 D electrosurgical unit using a configuration sample configuration. Although the unit you have before you may be configured dif- ferently, the structure of the user environment and operation of the functions is nev- ertheless identical.
  • Page 48 6 • Working with the Electrosurgical Unit: a Tutorial 3. Getting an overview: assignment of the active program for the electrosurgical unit Fig. 6-1 Once the performance test has been completed, you will see the window Guide. Here you can see the number (1) and the name (2) of the active program. In this example it is the program 1 program xy.
  • Page 49 Press the Up button several times. You will move to the first view of the window Guide. 6. Connecting the IES 3 to the VIO Connecting the IES 3 to the VIO 300 D: Read the chapter The IES 3 in combination with 300 D, operating the IES 3 a VIO D-series electrosurgical unit in the IES 3 user manual.

  • Page 50: Adopt Program

    6 • Working with the Electrosurgical Unit: a Tutorial Adopt Program Adopt Program Fig. 6-3 If you want to accept the active Existing Program, press the selection button next to the menu item Adopt program. You will then move to the window Cut / Coag Settings. You will then see the settings of the socket last activated.
  • Page 51 6 • Working with the Electrosurgical Unit: a Tutorial 2. Select Program Fig. 6-5 You will then move to the window Select Program. You will then see a selection list of programs (1). 1. If you press the Up/Down buttons (2), and more than 4 programs are stored, the window scrolls in the program selection list.

  • Page 52: The Basic Concept Of The Electrosurgical Unit: Focusing Attention On The Functions Of A Socket (Focus View)

    6 • Working with the Electrosurgical Unit: a Tutorial The basic concept of the electrosurgical unit: focusing attention on the functions of a socket (Focus View) Fig. 6-7 The window Cut / Coag Settings The window Cut / Coag Settings focuses attention on the functions of a socket as you only ever see the CUT settings (1) and COAG settings (2) of one socket.

  • Page 53: Setting Cut Mode

    6 • Working with the Electrosurgical Unit: a Tutorial Meaning of the asterisk When you change a program, an asterisk next to the name of the program shows that you have made a change. When you save the program, the asterisk disappears. The changed Basic Program cannot be saved.

  • Page 54: Setting Cut Effect

    6 • Working with the Electrosurgical Unit: a Tutorial Call up information on CUT mode If you wish, you can display information about the active CUT mode after selection of the CUT mode. Press the selection button next to the menu item Mode again. Press the selection button next to the menu item Info.

  • Page 55: Selecting Cut Max. Wattage

    6 • Working with the Electrosurgical Unit: a Tutorial 2. Choose CUT Effect Fig. 6-12 You will then move to the window Select Cut Effect. You will see a numerical display for the effect (1) and a display in the form of a bar diagram (2).

  • Page 56: Select Coag Mode, Coag Effect And Coag Power Limitation

    6 • Working with the Electrosurgical Unit: a Tutorial 2. Select Cut power limitation Fig. 6-14 You will then move to the window Cut power limitation. Selection of a power limitation level is for the safety of the patient and protects the instrument from damage. You will see a numerical display for the power limitation (1) and a display in the form of a bar diagram (2).
  • Page 57 6 • Working with the Electrosurgical Unit: a Tutorial 1. Call up window Select activation type Fig. 6-15 1. First use a Focus button (1) to select a socket to which you want to allocate a footswitch. You will see the functions of the socket in the window Cut / Coag Set- tings.

  • Page 58: Activation Of Cut And Coag Modes With Fingerswitch, Auto Start, Auto Stop

    6 • Working with the Electrosurgical Unit: a Tutorial Orientation: Footswitch display in the window Cut / Coag Settings and on the socket Fig. 6-18 In the window Cut / Coag Settings you will see the monopolar socket displayed. The yellow pedal allocated is highlighted yellow in the display.
  • Page 59 50 watts. You cannot set the bipolar coagulation above 50 watts. AUTO START without power limitation The power limitation can be displayed in the Service Setup. Please contact an Erbe em- ployee. You can then select the power limitation under the respective bipolar coagu- lation mode.

  • Page 60: The Focus View And Activation Concept Of The Electrosurgical Unit. What Points Must I Observe

    6 • Working with the Electrosurgical Unit: a Tutorial The Focus View and activation concept of the electrosurgical unit. What points must I observe? Instrument at monopolar and bipolar socket Fig. 6-21 Please imagine the following situation: The yellow pedal CUT (1) is allocated to the monopolar socket.

  • Page 61: Electrode

    Chapter 2 of this Manual "Safety Features" for NESSY. Note: Erbe recommends the use of split neutral electrodes in combination with the NESSY setting set to “NE: dynamic” or “NE: dual surface”. With this combination the optimal use of the safety monitoring functions are given (see chapter 2 “NESSY Safety...
  • Page 62 Dual-surface neutral electrode To optimally utilize the unit's monitoring functions, Erbe recommends connecting a dual-surface electrode, and in particular the Erbe NESSY Omega electrode. Apart from connected. "Neutral electrode: many other advantages, this electrode virtually eliminates any possibility of excessive Dual surface"...
  • Page 63 6 • Working with the Electrosurgical Unit: a Tutorial Application direction of the contact surface relative to the conduction direction When dual-surface electrodes are used, NESSY also monitors the direction of applica- tion of the contact surface relative to the conduction direction. The high-frequency current is not, as a rule, distributed evenly over the contact surface of the neutral elec- trode.
  • Page 64 6 • Working with the Electrosurgical Unit: a Tutorial "Neutral electrode: Dual surface" setup. The diagram on the right (3) shows the con- tact resistance as a bar. The upper and lower limits of the Green safety status are in- dicated by a red line at the top and bottom.

  • Page 65: Saving The Amended Basic Program Under A New Name

    6 • Working with the Electrosurgical Unit: a Tutorial Neonatal NE Monitoring System When using Neonatal neutral electrodes, you can activate the Neonatal NE Monitoring System. You can then turn the Neonatal NE Monitoring System on or off in the NESSY window.

  • Page 66: Overwriting A Program

    6 • Working with the Electrosurgical Unit: a Tutorial 2. The password is up to four characters long. As an example, we shall call the pass- word "Test". Select the letter T using the Up/Down buttons. Press the Selection button arrow to move the cursor on to the next character. By pressing the selec- tion button next to the menu item Char set, you can choose between upper case, lower case and numbers.

  • Page 67: Creating All Settings For A Program From Scratch

    6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-29 4. You will then move to the window Save as. Depress the Enter button for 3 sec. to overwrite the program. Creating all settings for a program from scratch You can create a program from an empty program template.
  • Page 68 6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-30 Fig. 6-31 Examples of options for ReMode 1st option: You can switch between any two settings of a socket as required. function 2nd option: You can switch between the settings of two sockets, for example, if you assign the footswitch in program a to a monopolar socket and in program b to a bipolar socket.
  • Page 69 6 • Working with the Electrosurgical Unit: a Tutorial Create programs 3a ReMode and 3b ReMode to familarize yourself with the first ReMode option Fig. 6-32 1. Call up the Basic Program. Call up the monopolar socket. 2. Change the setting according to the following specifications: AUTO CUT, Effect 5, 100 W.
  • Page 70 6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-34 Fig. 6-35 6. You will then move to the window Cut / Coag Settings. There you will see the name of the program 3 ReMode at the top of the window . Change the settings of the program 3 ReMode according to the following specifications: DRY CUT, Effect 3, 80 W.
  • Page 71 6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-37 9. You will then move to the window Save as. Press the Enter button. The program will be saved. Switch between program 3a ReMode and 3b ReMode Fig. 6-38 The system has renamed program 3 ReMode as 3a ReMode and saved a program 3b ReMode.

  • Page 72: Remode Change-Over With A 2-Button Handpiece

    6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-39 Fig. 6-40 In the program 3a ReMode you will see the settings of the monopolar socket of this program. The footswitch (CUT and COAG) is allocated to the monopolar socket. If you switch to the program 3b ReMode, you will see the settings of the bipolar socket.
  • Page 73 6 • Working with the Electrosurgical Unit: a Tutorial Fig. 6-41 Fig. 6-42 Fig. 6-43 Brightness Display of screen brightness in 16 levels. Volume Selection of the volume level of the warning signals in 16 levels. The warning signals must be clearly audible! Volume button Selection of the button volume in 16 levels.
  • Page 74 6 • Working with the Electrosurgical Unit: a Tutorial Power display If you switch on the output display, you will see a bar diagram on activation of the unit. The diagram shows the maximum possible output in the respective mode. The green line represents the power limitation.

  • Page 75: Description Of Socket Hardware

    A socket module consists of a front plate, socket insert and two holding clips. Installa- tion in the electrosurgical unit is simple and can be carried out quickly by any techni- cian authorized by Erbe. Sockets for different modes and instrument connectors In this chapter the sockets are described from the aspect of their usage and compati- bility with various instrument connectors.

  • Page 76: Bipolar Socket

    Fig. 7-2 Erbe No. 20140-623 You can connect ONE of the following connectors as required: a monopolar 3-pin con- nector; a monopolar socket based on Erbe standard; a monopolar connector dia. 4 mm to the input marked blue. Bipolar socket...

  • Page 77: Multifunctional Socket

    7 • Description of socket hardware The socket module is suitable for the following connectors: Bipolar connector based on Erbe standard. Rear contact ring dia. 8 mm, front contact ring dia. 4 mm. Socket module BI 2 pin 22 – 28 – 8 / 4 Fig.

  • Page 78: Socket For Neutral Electrode

    Socket module NE 6 and NE 2-pin Fig. 7-8 Erbe No. 20140-642 You may connect ONE of the following plugs: Erbe neutral electrode plug with Ø 6.35 mm; neutral electrode plug with 2 pins. The socket is equipped with a slide switch that / 182...
  • Page 79 7 • Description of socket hardware allows you to connect the plug with Ø 6.35 mm or the plug with 2 pins based on the position of the socket (see illustration above). / 182...
  • Page 80 7 • Description of socket hardware / 182...

  • Page 81: Monopolar Standard Modes

    8 • Monopolar Standard Modes Chapter 8 Monopolar Standard Modes AUTO CUT Properties Reproducible, gentle cuts, extra kind to tissue, minimal to medium hemostasis. PPS (Power Peak System) The AUTO CUT mode is equipped with PPS. A special problem during incision may be posed by the initial incision phase, in particular when the cutting electrode is pressed firmly against the tissue to be cut before activation of the HF generator so that the cutting electrode has a relatively extensive and thus low-resistance contact with the...
  • Page 82 8 • Monopolar Standard Modes Diagrams AUTO CUT = 500 Ohm Effect7-8 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 8-1 Fig. 8-2 / 182...

  • Page 83: High Cut

    8 • Monopolar Standard Modes AUTO CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 8-3 HIGH CUT Properties Reproducible tissue-sparing cuts, in particular in poorly conductive and varying tissue. PPS (Power Peak System) The HIGH CUT mode is equipped with PPS. A special problem during incision may be posed by the initial incision phase, in particular when the cutting electrode is pressed firmly against the tissue to be cut before activation of the HF generator so that the cutting electrode has a relatively extensive and thus low-resistance contact with the...
  • Page 84 8 • Monopolar Standard Modes Rated load resistor 500 ohms Max. HF peak voltage 1040 V (if an arc is present) Number of effects Consistency of effects Automatic control of arc intensity HF power limitation 10 watts to 300 watts in 1-watt steps Max.

  • Page 85: Dry Cut

    8 • Monopolar Standard Modes HIGH CUT Effect8: Effect7: Effect6: Effect5: Effect4: Effect3: Effect2: Effect1: Power HF max. (W) Fig. 8-6 DRY CUT Properties Intense hemostasis with somewhat slower cutting speed. Areas of use E.g. cuts in "open surgery" and cuts in endoscopic operations that require very good primary hemostasis during the cut and tolerate a somewhat slower cutting speed.
  • Page 86 8 • Monopolar Standard Modes HF power limitation 10 watts to 200 watts in 1-watt steps Max. power output at rated load resis- 200 watts ± 20% Max. RMS current (maximum HF output 280 mA current in normal use) Diagrams DRY CUT = 500 Ohm Effect8...

  • Page 87: Dry Cut

    8 • Monopolar Standard Modes DRY CUT 1600 1400 Effect8 1200 Effect7 Effect6 1000 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 8-9 DRY CUT ° Properties Intense hemostasis with somewhat slower cutting speed. Difference compared with Dry Cut Changed ratio of crest factor to RF peak voltage.
  • Page 88 8 • Monopolar Standard Modes Max. power output at rated load resis- 200 watts ± 20% Max. RMS current (maximum HF output 600 mA current in normal use) Diagrams DRY CUT ° = 500 Ohm Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1...

  • Page 89: Soft Coag

    8 • Monopolar Standard Modes DRY CUT ° 1800 1600 Effect8 1400 Effect7 1200 Effect6 1000 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 8-12 SOFT COAG Properties Carbonization of the tissue is prevented, adhesion of the electrode to the tissue is greatly reduced.
  • Page 90 36 A²s according to the manufacturer's specifications. These are, for ex- ample, the Erbe neutral electrodes NESSY Plate 170 (REF No. 20193-070, 20193-074) or NESSY RePlate 200 (REF No. 20193- 090).

  • Page 91: Swift Coag

    8 • Monopolar Standard Modes SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 100W 1000 10000 Resistance (Ohm) Fig. 8-14 SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 8-15 SWIFT COAG Properties Fast effective coagulation which is very suitable for dissection with high hemostasis...
  • Page 92 8 • Monopolar Standard Modes Suitable electrodes Ball electrodes for coagulation only. Knife or spatula electrodes for dissection and co- agulation. Technical data HF voltage waveform pulse-modulated sinusoidal alternat- ing voltage Rated frequency 350 kHz (at R = 500 ohms) ± 10% Crest factor 5.2 (at R = 500 ohms)

  • Page 93: Swift Coag

    8 • Monopolar Standard Modes SWIFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 100W 1000 10000 Resistance (Ohm) Fig. 8-17 SWIFT COAG 3000 2500 Effect8 Effect7 2000 Effect6 Effect5 1500 Effect4 Effect3 1000 Effect2 Effect1 Power HF max. (W) Fig.
  • Page 94 8 • Monopolar Standard Modes Applications Coagulation and dissection. Suitable electrodes Ball electrodes for coagulation only. Knife or spatula electrodes for dissection and co- agulation. Technical data HF voltage waveform pulse-modulated sinusoidal alternat- ing voltage Rated frequency 350 kHz (at R = 500 ohms) ±...

  • Page 95: Forced Coag

    8 • Monopolar Standard Modes SWIFT COAG ° Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 100W 1000 10000 Resistance (Ohm) Fig. 8-20 SWIFT COAG ° 1800 1600 Effect8 1400 Effect7 1200 Effect6 1000 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max.
  • Page 96 8 • Monopolar Standard Modes Suitable electrodes Ball electrodes for coagulation. Insulated monopolar forceps for clamp coagulation. Technical data HF voltage waveform pulse-modulated sinusoidal alternat- ing voltage Rated frequency 350 kHz (at R = 500 ohms) ± 10% Crest factor 5.0 (at R = 500 ohms) Rated load resistor...

  • Page 97: Spray Coag

    8 • Monopolar Standard Modes Fig. 8-23 FORCED COAG 2500 2000 1500 Effect4 Effect3 Effect2 1000 Effect1 Power HF max. (W) Fig. 8-24 SPRAY COAG Properties Contact-free, efficient surface coagulation, low penetration depths. Automatic dosing of power within the pre-selected limits. Areas of use Coagulation of diffuse hemorrhage.
  • Page 98 8 • Monopolar Standard Modes Suitable electrodes Knife and lancet-shaped electrodes. Technical data HF voltage waveform pulse-modulated sinusoidal alternat- ing voltage Rated frequency 350 kHz (at R = 500 ohms) ± 10% Crest factor 7.4 (at R = 500 ohms) Rated load resistor 500 ohms Max.

  • Page 99: Classic Coag

    8 • Monopolar Standard Modes SPRAY COAG Effect2 Effect1 Effect2(60W) Effect1(60W) 1000 10000 Resistance (Ohm) Fig. 8-26 SPRAY COAG 5000 4500 4000 3500 3000 Effect 2 2500 Effect 1 2000 1500 1000 Power HF max. (W) Fig. 8-27 CLASSIC COAG Properties Reproducible preparation characteristics that are well suited for dissecting tissue lay- ers with very good hemostasis and low lateral tissue damage.
  • Page 100 8 • Monopolar Standard Modes Suitable electrodes Knife electrodes and spatula electrodes. Technical data HF voltage waveform pulse-modulated sinusoidal alternat- ing voltage Rated frequency 350 kHz (at R = 500 ohms) ± 10% Crest factor 4.5 (at R = 1000 ohms) Rated load resistor 1,000 ohms Max.
  • Page 101 8 • Monopolar Standard Modes Fig. 8-29 CLASSIC COAG 1600 1400 Effect2 1200 Effect1 1000 Power HF max. (W) Fig. 8-30 / 182...
  • Page 102 8 • Monopolar Standard Modes / 182...

  • Page 103: Bipolar Standard Modes

    9 • Bipolar Standard Modes Chapter 9 Bipolar Standard Modes BIPOLAR CUT Properties Cutting current that only flows directly around the distal end of the applicator. You can use the effect levels to set the degree of hemostasis at the cut edge. PPS (Power Peak System) The BIPOLAR CUT mode is equipped with PPS.
  • Page 104 9 • Bipolar Standard Modes Diagrams BIPOLAR CUT = 500 Ohm Effect1-8 Power HF max. (W) Fig. 9-1 BIPOLAR CUT Effect6-8 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 50W 1000 10000 Resistance (Ohm) Fig. 9-2 / 182...

  • Page 105: Bipolar Cut

    9 • Bipolar Standard Modes BIPOLAR CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 9-3 BIPOLAR CUT + Properties Reproducible, tissue-sparing cuts. You can use the effect levels to set the degree of hemostasis at the cut edge. Areas of use Cutting procedures in Bipolar Resection.

  • Page 106: Bipolar Cut

    9 • Bipolar Standard Modes Design load resistance 500 ohms Max. HF peak voltage 770 Vp Number of effects Consistency of effects Automatic control of HF peak voltage Max. output across the design load 370 W +8 % / -20 % resistor Diagrams Fig.

  • Page 107: Bipolar Soft Coag

    9 • Bipolar Standard Modes Suitable electrodes Bipolar resectoscopes that are connected with the Erbe bipolar cable for resectoscopes to the RESECTOSCOPE socket of a bipolar resection adapter. Technical data Type of HF voltage Unmodulated sinusoidal AC voltage Nominal frequency 350 kHz (across R = 500 ohms) ±...
  • Page 108 9 • Bipolar Standard Modes AUTO START In the window Select activation type you can select an AUTO START function for BIPO- LAR SOFT COAG. When the instrument touches tissue, coagulation starts automatically after a specified period of time. Suitable electrodes Bipolar instruments, e.g.

  • Page 109: Bipolar Soft Coag

    9 • Bipolar Standard Modes BIPOLAR SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 60W 1000 10000 Resistance (Ohm) Fig. 9-7 BIPOLAR SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig.

  • Page 110: Bipolar Soft Coag

    Lower voltages, carbonization of the tissue is prevented, adhesion of the electrode to the tissue is reduced considerably. Areas of use Coagulation in Bipolar Resection. Suitable electrodes Bipolar resectoscopes that are connected with the Erbe bipolar cable for resectoscopes to the RESECTOSCOPE socket of a bipolar resection adapter. / 182...

  • Page 111: Bipolar Forced Coag

    9 • Bipolar Standard Modes Technical data Type of HF voltage Unmodulated sinusoidal AC voltage Nominal frequency 350 kHz (across R = 500 ohms) ± 10% Crest factor 1.4 (across R = 500 ohms) Designed load resistance 50 ohms Max. HF peak voltage 200 Vp Number of effects Consistency of effects...
  • Page 112 9 • Bipolar Standard Modes Difference from BIPOLAR SOFT Faster bipolar coagulation. Carbonization of the tissue cannot be precluded. COAG Suitable electrodes Bipolar instruments, e.g. bipolar forceps, bipolar hook electrodes. Technical data Type of HF voltage pulse-modulated sinusoidal AC voltage Nominal frequency 350 kHz (at R = 500 ohms) ±...
  • Page 113 9 • Bipolar Standard Modes BIPOLAR FORCED COAG Effect1-2 max.Pa =45W 1000 10000 Resistance (Ohm) Fig. 9-12 BIPOLAR FORCED COAG Effect2 Effect1 Power HF max. (W) Fig. 9-13 / 182...
  • Page 114 9 • Bipolar Standard Modes / 182...

  • Page 115: Monopolar Optional Modes

    10 • Monopolar Optional Modes Chapter 10 Monopolar Optional Modes PRECISE CUT Properties Very fine adjustment, minimum necroses at the cut edge, very fine power output in a range of 1 to 50 watts. Areas of use E.g. cuts in operations where strain on the tissue or patient must be kept to a mini- mum, e.g.
  • Page 116 10 • Monopolar Optional Modes Diagrams PRECISE CUT = 500 Ohm Effect3-8 Effect2 Effect1 Power HF max. (W) Fig. 10-1 PRECISE CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 25W 1000 10000 Resistance (Ohm) Fig. 10-2 / 182...

  • Page 117: Endo Cut Q

    10 • Monopolar Optional Modes PRECISE CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 10-3 ENDO CUT Q Properties The cut consists of alternating cutting and coagulating phases. The cut is easy to con- trol and is characterized by a reproducible, preselectable coagulation property while cutting.

  • Page 118: Endo Cut I

    10 • Monopolar Optional Modes move the lesion quickly. A long cutting interval makes it easier to remove the lesion slowly under control. Technical data HF voltage waveform unmodulated sinusoidal alternating voltage Rated frequency 350 kHz (at R = 500 ohms) ± 10% Crest factor 1.4 (at R = 500 ohms)
  • Page 119 10 • Monopolar Optional Modes Suitable electrodes Papillotomy and needle electrodes Expert mode For a customized setting you can have Expert mode activated by a service technician. The Cut / Coag Settings window will then also show the parameters Cutting duration and Cutting interval .

  • Page 120: Precise Coag

    10 • Monopolar Optional Modes Diagrams ENDO CUT I Cutting_stage max. Power Cutting_stage min. Power 1000 10000 Resistance (Ohm) Fig. 10-5 PRECISE COAG Properties Extremely fine adjustment, extremely fine precision power output in range from 1 to 50 watts. Applications Coagulation processes where stress for tissue or patient must be minimized, e.g.
  • Page 121 10 • Monopolar Optional Modes Max. power output at rated load resis- 50 watts ± 20 % Max. RMS current (maximum HF output 700 mA current in normal use) Diagrams PRECISE COAG = 50 Ohm Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1...

  • Page 122: Twin Coag

    10 • Monopolar Optional Modes PRECISE COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 10-8 TWIN COAG Properties Fast, effective coagulation, which is highly suitable for preparation with high hemo- stasis owing to its limited tissue-cutting property. Two monopolar instruments can be activated at the same time.
  • Page 123 10 • Monopolar Optional Modes Max. HF peak voltage 2000 Vp Number of effects Consistency of effects Automatic control of HF peak voltage HF power limitation 5 watts to 200 watts in 1-watt steps Max. power output at rated load resis- 200 watts ±...
  • Page 124 10 • Monopolar Optional Modes TWIN COAG 2500 Effect8 2000 Effect7 Effect6 1500 Effect5 Effect4 1000 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 10-11 / 182...

  • Page 125: Bipolar Optional Modes

    BiClamp Properties Special COAG mode for Erbe BiClamp (bipolar clamp). With four effect graduations you can adjust the coagulation performance exactly to the type of tissue involved. The AUTO STOP function is adjusted to BiClamp and ends activation automatically when the best coagulation effect is achieved.

  • Page 126: Bipolar Precise Cut

    11 • Bipolar Optional Modes Diagrams BiClamp Effect 4 Effect 3 Effect 2 Effect 1 1000 Resistance (Ohm) Fig. 11-1 BIPOLAR PRECISE CUT Properties Very fine adjustment, minimal necrosis at the cut edge, extremely precise power out- put in the 1 to 50 W range. Applications For example, incisions during procedures where stress for the tissue or patient must be minimised, e.g.
  • Page 127 11 • Bipolar Optional Modes HF power limitation 1 watt to 50 watts in 1 watt steps Max. power output at rated load resis- 50 watts ± 20% Diagrams BIPOLAR PRECISE CUT = 500 Ohm Effect1-8 Power HF max. (W) Fig.

  • Page 128: Bipolar Precise Coag

    11 • Bipolar Optional Modes BIPOLAR PRECISE CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 11-4 BIPOLAR PRECISE COAG Properties Very fine adjustment, extremely precise power output in the 1 to 50 W range. AUTO START In the Select activation type window, you can select an AUTO START function for BI- POLAR PRECISE COAG .
  • Page 129 11 • Bipolar Optional Modes HF power limitation 1 watt to 50 watts in 1 watt steps Max. power output at rated load resis- 50 watts ± 20% Diagrams Fig. 11-5 Fig. 11-6 / 182...
  • Page 130 11 • Bipolar Optional Modes BIP. PRECISE COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 11-7 / 182...

  • Page 131: Apc Socket (Only Available With The Apc Module)

    12 • APC socket (only available with the APC module) Chapter 12 APC socket (only available with the APC module) APC socket Cutting and coagulation modes Standard • Forced APC • Precise APC • Pulsed APC • Argon-assisted AUTO CUT Mode •...
  • Page 132 12 • APC socket (only available with the APC module) / 182...

  • Page 133: Apc Standard Modes (Only Available With An Apc Module)

    13 • APC Standard Modes (Only Available with an APC Module) Chapter 13 APC Standard Modes (Only Available with an APC Module) FORCED APC Properties Standard setting for the APC with ignition assistance for safe ignition of the plasma. Areas of use Hemostasis of small, diffuse areas of bleeding.
  • Page 134 13 • APC Standard Modes (Only Available with an APC Module) Diagrams FORCED APC = 500 Ohm Power HF max. (W) Fig. 13-1 FORCED APC Pmax(120) Pmax(60) 1000 10000 Resistance (Ohm) Fig. 13-2 / 182...

  • Page 135: Precise Apc

    13 • APC Standard Modes (Only Available with an APC Module) FORCED APC 5000 4500 4000 3500 3000 2500 2000 1500 1000 Power HF max. (W) Fig. 13-3 PRECISE APC Properties APC with well controllable change of effect at the tissue surface, largely independent of the distance between applicator and tissue.

  • Page 136: Pulsed Apc

    13 • APC Standard Modes (Only Available with an APC Module) Number of effects Consistency of effects automatic control of arc intensity Max. power output at rated load resis- 160 watts ± 20% Max. RMS current (maximum HF output 240 mA current in normal use) Diagrams PRECISE APC...
  • Page 137 13 • APC Standard Modes (Only Available with an APC Module) Rated load resistor 500 ohms Max. HF peak voltage 4 700 V Number of effects Consistency of effects Restriction of HF peak voltage HF power limitation 1 watts to 120 watts in 1-watt steps Max.

  • Page 138: Argon-Assisted Auto Cut Mode

    13 • APC Standard Modes (Only Available with an APC Module) Fig. 13-7 Argon-assisted AUTO CUT Mode Properties Reproducible, extremely tissue-sparing cuts, minimal to medium hemostasis. The ar- gon gas reduces the formation of smoke and the carbonization. Areas of use All cutting procedures in electrically conductive tissue: e.g.
  • Page 139 13 • APC Standard Modes (Only Available with an APC Module) Max. power output at rated load resis- 300 watts ± 20% Max. RMS current (maximum HF output 220 mA current in normal use) Diagrams AUTO CUT = 500 Ohm Effect7-8 Effect6 Effect5...

  • Page 140: Argon-Assisted High Cut Mode

    13 • APC Standard Modes (Only Available with an APC Module) AUTO CUT Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 13-10 Argon-assisted HIGH CUT Mode Properties Reproducible, tissue-sparing cuts, in particular in poorly conductive and varying tissue. The argon gas reduces the formation of gas and carbonization.
  • Page 141 13 • APC Standard Modes (Only Available with an APC Module) Diagrams HIGH CUT = 500 Ohm Effect1-8 Power HF max. (W) Fig. 13-11 HIGH CUT Effect8: Effect7: Effect6: Effect5: Effect4: Effect3: Effect2: Effect1: max.Pa = 150W 1000 10000 Resistance (Ohm) Fig.

  • Page 142: Argon-Assisted Dry Cut Mode

    13 • APC Standard Modes (Only Available with an APC Module) HIGH CUT Effect8: Effect7: Effect6: Effect5: Effect4: Effect3: Effect2: Effect1: Power HF max. (W) Fig. 13-13 Argon-assisted DRY CUT Mode Properties Intense hemostasis with somewhat slower cutting speed. The argon gas reduces the formation of smoke and the carbonization.
  • Page 143 13 • APC Standard Modes (Only Available with an APC Module) HF power limitation 10 watts to 200 watts in 1-watt steps Max. power output at rated load resis- 200 watts ± 20% Max. RMS current (maximum HF output 280 mA current in normal use) Diagrams DRY CUT...

  • Page 144: Argon-Assisted Dry Cut ° Mode

    13 • APC Standard Modes (Only Available with an APC Module) DRY CUT 1600 1400 Effect8 1200 Effect7 Effect6 1000 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 13-16 Argon-assisted DRY CUT ° Mode Properties Intense hemostasis with somewhat slower cutting speed. Difference compared with Dry Cut Changed ratio of crest factor to RF peak voltage.
  • Page 145 13 • APC Standard Modes (Only Available with an APC Module) Max. power output at rated load resis- 200 watts ± 20% Max. RMS current (maximum HF output 600 mA current in normal use) Diagrams DRY CUT ° = 500 Ohm Effect8 Effect7 Effect6...

  • Page 146: Argon-Assisted Swift Coag Mode

    Ball electrodes only for coagulation. Knife or blade electrodes for preparation and co- agulation. (Note: When using the Erbe VIO APC handpiece, a conventional 4 mm elec- trode can be used instead of the argon applicator. For this, the flow setting must be...
  • Page 147 13 • APC Standard Modes (Only Available with an APC Module) Max. power output at rated load resis- 200 watts ± 20% Max. RMS current (maximum HF output 570 mA current in normal use) Diagrams SWIFT COAG = 500 Ohm Effect8 Effect7 Effect6...

  • Page 148: Argon-Assisted Swift Coag ° Mode

    Ball electrodes only for coagulation. Knife or blade electrodes for preparation and co- agulation. (Note: When using the Erbe VIO APC handpiece, a conventional 4 mm elec- trode can be used instead of the argon applicator. For this, the flow setting must be...
  • Page 149 13 • APC Standard Modes (Only Available with an APC Module) Consistency of effects Automatic control of HF peak voltage HF power limitation 5 watts to 200 watts in 1-watt steps Max. power output at rated load resis- 200 watts ± 20% Max.

  • Page 150: Argon-Assisted Forced Coag Mode

    Ball electrodes for contact coagulation. Insulated monopolar forceps for clamp coag- ulation. (Note: When using the Erbe VIO APC handpiece, a conventional 4 mm electrode can be used instead of the argon applicator. For this, the flow setting must be set to 0)
  • Page 151 13 • APC Standard Modes (Only Available with an APC Module) Max. power output at rated load resis- 120 watts ± 20% Max. RMS current (maximum HF output 1150 mA current in normal use) Diagrams FORCED COAG = 500 Ohm Effect3-4 Effect2 Effect1...

  • Page 152: Argon-Assisted Soft Coag Mode

    Contact electrodes, for this in particular electrodes with large contact surface, e.g. ball electrodes for deep coagulation. (Note: When using the Erbe VIO APC handpiece, a conventional 4 mm electrode can be used instead of the argon applicator. For this, the...
  • Page 153 36 A²s according to the manufacturer's specifications. These are, for ex- ample, the Erbe neutral electrodes NESSY Plate 170 (REF No. 20193-070, 20193-074) or NESSY RePlate 200 (REF No. 20193- 090).
  • Page 154 13 • APC Standard Modes (Only Available with an APC Module) SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 100W 1000 10000 Resistance (Ohm) Fig. 13-30 SOFT COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max.

  • Page 155: Apc Optional Modes (Only Available With An Apc Module)

    14 • APC Optional Modes (Only Available with an APC Module) Chapter 14 APC Optional Modes (Only Available with an APC Module) Argon-assisted TWIN COAG Mode Properties Fast, effective coagulation, which is highly suitable for preparation with high hemo- stasis owing to its limited tissue-cutting property. Two monopolar instruments can be activated at the same time.
  • Page 156 14 • APC Optional Modes (Only Available with an APC Module) Diagrams TWIN COAG = 500 Ohm Effect7-8 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 14-1 TWIN COAG Effect8 Effect7 Effect6 Effect5 Effect4 Effect3 Effect2 Effect1 max.Pa = 100W 1000 10000...
  • Page 157 14 • APC Optional Modes (Only Available with an APC Module) TWIN COAG 2500 Effect8 2000 Effect7 Effect6 1500 Effect5 Effect4 1000 Effect3 Effect2 Effect1 Power HF max. (W) Fig. 14-3 / 182...
  • Page 158 14 • APC Optional Modes (Only Available with an APC Module) / 182...

  • Page 159: Installation

    15 • Installation Chapter 15 Installation Ambient conditions WARNING Ignition of anesthetics, skin cleansers, and disinfectants in poten- tially explosive atmospheres If you place the unit in a potentially explosive atmosphere, anesthet- ics, skin cleansers, and disinfectants can ignite. Risk of fire and explosion to the patient and medical personnel! Risk of damage to property.

  • Page 160: Electrical Installation

     Only connect the unit to a power supply network with proper grounding.  Only use the Erbe power cord or an equivalent power cord with a national quality symbol for this purpose.  Check the power cord for damage. You must not use a damaged power cord.
  • Page 161  When a fuse has been changed, the function of the unit must be verified. If the unit does not function properly or if there are any concerns, please contact Erbe Elektromedizin. You will find the addresses in the address list at the end of this User Manual.

  • Page 162: Install Electrosurgical Unit On Overhead Support

    15 • Installation Install electrosurgical unit on overhead support Fig. 15-1 For installation you require the VIO fastening set on console No. 20180-133. 1. Screw the bottom plate to the electrosurgical unit. 2. If the electrosurgical unit is installed on an overhead support, the caps* (1) must be fitted to the interconnections.

  • Page 163: Installing The Unit On An Erbe Cart

    Power connection (5) Power connection Connect the unit to a properly installed grounded power outlet. Only use the Erbe pow- er cord or an equivalent power cord with a national quality symbol for this purpose. Installing the unit on an Erbe cart Please read the User Manual for the cart concerned.
  • Page 164 15 • Installation / 182...

  • Page 165: Cleaning And Disinfection

    Chapter 16 Cleaning and disinfection Wipe disinfection For cleaning and disinfecting the surfaces of the unit or of the cart, Erbe recommends a wipe disinfection. Use only disinfectant which complies with the relevant national standards. Instructions for cleaning and disinfection Mix the disinfectant in the concentration specified by the manufacturer.
  • Page 166 16 • Cleaning and disinfection Penetration of liquid into the unit The housing is not absolutely watertight. If liquid penetrates, the unit can sustain damage and fail.  Make sure no liquid can penetrate the unit.  Do not place vessels containing liquids on top of the unit. Alcohol-based spray disinfectant for fast disinfection With membrane keyboards and paint surfaces there is the risk of cracks.

  • Page 167: Status Messages, Error Messages

    17 • Status Messages, Error Messages Chapter 17 Status Messages, Error Messages An error message consists of an error code and an error text. The display of the VIO system shows two different types of error messages. a) Error messages that prompt you to take action and remedy the error. You will find these error messages in the table.
  • Page 168 17 • Status Messages, Error Messages Error Messages B-10 Please end activation! Activation via finger or footswitch must be ended. After which reactivation is possible. B-12 Please end activation! Footswitch or fingerswitch activation detected during device start-up. B-16 Program memory full. Please delete programs no longer needed. B-17 Double activation.
  • Page 169 17 • Status Messages, Error Messages Error Messages B-B0 NESSY symmetry. When applying neutral electrode (patient plate), ensure that neutral electrode line of sym- metry runs towards the operating field. B-AC Contact detected. Attempt made to assign the AUTO START function to the instrument. This is not possible if the tips are touching each other.
  • Page 170 17 • Status Messages, Error Messages / 182...

  • Page 171: General Technical Data

    18 • General Technical Data Chapter 18 General Technical Data Power connection Rated supply voltage 100 V – 120 V ± 10 % 220 V – 240 V ± 10 % Rated supply frequency 50 / 60 Hz 50 / 60 Hz Line current Power input in standby mode 40 watts...
  • Page 172 18 • General Technical Data Acclimatizing If the unit has been stored or transported at temperatures below +10 °C or above +40 °C, the unit will require approx. 3 hours to acclimatize at room temperature. Standards Classification according to EC Directive 93/42/EEC II b Protection class as per EN 60 601-1 Type as per EN 60 601-1...

  • Page 173: Notes On Electromagnetic Compatibility (Emc)

    "Notes on electromagnetic compatibility (EMC)".  If you are using accessories from other manufacturers, check whether the Erbe unit is interfering with other units or being af- fected by interference itself. You cannot use the unit if there is any interference.
  • Page 174 19 • Notes on electromagnetic compatibility (EMC) the units. Check whether the units are affecting each other: Are the units behaving unusually? Are faults occurring? Interference with the unit from portable and mobile HF telecom- munications units (e.g. mobile phones, WLAN units) Electromagnetic waves emitted by portable and mobile HF telecom- munications units may affect the unit.
  • Page 175 19 • Notes on electromagnetic compatibility (EMC) Guidance and manufacturer's declaration - electromagnetic immunity The unit is intended for use in the electromagnetic environment specified below. The customer or the user of the unit should ensure that it is used in such an environment. Immunity test IEC 60601-1-2 test level Compliance level...
  • Page 176 19 • Notes on electromagnetic compatibility (EMC) Guidance and manufacturer's declaration - electromagnetic immunity The unit is intended for use in the electromagnetic environment specified below. The user of the unit should ensure that it is used in such an environment. Immunity test IEC 60601-1-2 test Compliance level...
  • Page 177 EMC-relevant accessories refers to the cable specified. The cable can affect the unit’s electromagnetic interference or the electromagnetic immunity of the unit. b) When connecting Erbe instruments and neutral electrodes, the overall cord length increases by max. 0.5 m. Operating environment For the intended use, the unit may only be operated in premises used for medical pur- poses.
  • Page 178 19 • Notes on electromagnetic compatibility (EMC) / 182...

  • Page 179: Maintenance, Customer Service, Warranty, Disposal

    Modifications and repairs may only be undertaken by Erbe or by persons expressly au- thorized by Erbe. Erbe accepts no liability if modifications and repairs to the unit or accessories are made by unauthorized persons. This will also invalidate the warranty.

  • Page 180: Warranty

    EU Directive 2012/19/EU of 07/04/2012, WEEE. In non-EU countries the local regulations must be observed. If you have any questions about disposal of the product, please contact Erbe Elektro- medizin or your local distributor. / 182...

  • Page 181: Symbols

    21 • Symbols Chapter 21 Symbols Individual details of the symbols in this chapter may deviate from your product. Not all symbols may necessarily appear on your unit or its packaging. Symbol Explanation Caution: Before switching the unit on or performing another action related to the unit, read the safety instructions in the User Manual.
  • Page 182 21 • Symbols Symbol Explanation Erbe Communication Bus Used to exchange data between Erbe units. Equipotentiality Refers to the grounding terminal. Off, On Defibrillation-proof type CF applied part The applied parts of the unit (e.g. instrument sockets) are pro- tected against the effects of defibrillator discharge.

Table of Contents

Save PDF
