Thank you for purchasing this Rouen Bed. Please read the instructions carefully before use to ensure safe
and satisfactory operation of this product.
PRE-ASSEMBLY PREPARATION
Please ensure instructions are read in full before attempting to assemble this product.
Necessary Tools
Please check the pack contents before attempting to assemble this product. A full checklist of components is
given in this leaflet. If any components are missing, please contact the John Lewis Helpline.
This product is HEAVY. It should be assembled as near as possible to the point of use. TAKE CARE WHEN
LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 40 MINUTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG CHILDREN.
Read this leaflet in full before commencing assembly.
If you require any additional information or have any issues with this product please call the
John Lewis Helpline on 01244 689949 or email mail@fwgroup-uk.com
Rouen Bed
1/6
King, Superking
For product support or spare parts please call
the John Lewis Helpline;
E: mail@fwgroup-uk.com
(NOT INCLUDED)
T: 01244 689949
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for John Lewis Rouen Bed King
Summary of Contents for John Lewis Rouen Bed King
- Page 1 Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the John Lewis Helpline. This product is HEAVY. It should be assembled as near as possible to the point of use. TAKE CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.
- Page 2 Fittings and parts checklist Fittings M4 Allen Key x 1 M8 Nut x 2 M5 Allen Key x 1 Screw 3.5 X 30mm x 2 Centre Caps x 8 M13 Spanner x 1 Side Caps x 16 Wide Centre Caps x 8 M6 X 25mm Bolt x 6 Wide Side Caps x 16 M8 Spring Washer x 2...
- Page 3 Step by step assembly instructions Step One Place Metal Bracket on Side Rails (3) over pre-inserted bolts in Headboard (1) and Footboard (2) and hand-tighten to loosely secure parts together. Do not tighten bolts with M5 Allen Key (B) until you have inserted the Centre Rail in the next step.
- Page 4 Step Three Starting with the Headboard (1), insert the Front Legs (7)x2 into the pre-drilled holes on the underside of the Headboard (1) and twist to secure, as shown in the diagram below. Legs x 2 Step Four Attach the Metal Plate (8) to the bottom of Footboard (2) using bolt M6 x 25mm (E)x2 and Screw 3.5 x 30mm (H)x1. Tighten the bolt with M4 Allen Key (A).
- Page 5 Step Five With the curved side facing upwards, insert 2 slats into a centre cap then into 2 side caps on either end(x16). (Please note the Wide Slats must be inserted with the Wide Centre Caps (J) and Wide Side Caps (K)). Repeat this process for all slats. Note: Please see the Diagram 1 below to arrange the slat with the correct system).
-
Page 6: Care And Maintenance
Please be careful to retain all fittings when doing this. If you require any additional information or have any issues with this product please call the John Lewis Helpline on 01244 689949 or email mail@fwgroup-uk.com John Lewis Partnership 171 Victoria Street, London, SW1E 5NN.
