Thank you for purchasing this Riley guest bed. Please read the instructions carefully before use to ensure
safe and satisfactory operation of the product.
For product support or spare parts please call
the John Lewis Helpline;
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Please check the pack contents before attempting to assemble this product. A full checklist of
compenents is given in this lea et. If any components are missing, please contact the
John Lewis helpline.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE
CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 40 MINUTES to assemble with 2 PEOPLE.
The ttings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Riley Guest Bed
T: 01244 689949
E: mail@fwgroup-uk.com
Stock code 800/65201, 800/65202
Page 1
Advertisement
Related Manuals for John Lewis Riley Guest Bed 800/65201
Summary of Contents for John Lewis Riley Guest Bed 800/65201
- Page 1 Thank you for purchasing this Riley guest bed. Please read the instructions carefully before use to ensure safe and satisfactory operation of the product. For product support or spare parts please call the John Lewis Helpline; T: 01244 689949 E: mail@fwgroup-uk.com...
- Page 2 Main Bed Parts and Fittings Check List Parts Footboard x 1 (G2) Headboard x 1 (G1) Side Rail x 2 (G4) Top Rail x 2 (G3) Slats x 1 (G5) Fittings Page 2...
- Page 3 Step 1 Attach the top rail (G3) to the head and foot board using bolt (H1) and wooden dowel (H4) to attach. G1/G2 Step 2 Secure 2 side rails (H4) on to the head and foot boards using bolts (H2). Page 3...
- Page 4 Step 3 along the side rails. (4 on each side). Page 4...
-
Page 5: Parts Checklist
FITTINGS CHECKLIST PARTS CHECKLIST Page 5... - Page 6 Place head panel (G1) at the top of the side rail (G4). Join the top and bottom xing holes with dowels (H6). Join the middle hole with the 50mm bolt (H2) and insert barrel nut (H7) into the side rail (G4), then insert the wood button (H9) into the end of the bolt.
- Page 7 Place the spring and metal plate on the top leg (G2) into the slots on the underbed. Attach the spring with pan head screw (H5) and secure the metal plate with 30mm bolt (H3). Caution: Please do not place the truckle upon its side as it features a spring mechanism that could cause potential injury.
- Page 8 Step 4 Place the slats (G5) into the underbed and secure in place using M4 x 35mm Screw (H3 x 8), into the pre - drilled holes as shown in the below diagram. H3 x 8 Step 5 Push the castor wheels (H8) into the top of the legs (G2) as shown in the diagram below. Caution: Please do not place the truckle upon its side as it features a spring mechanism that could cause potential injury.
-
Page 9: Care And Maintenance
Please be careful to retain all ttings when doing this. This product complies with BS EN 1725 1998. If you require any additional information or have any issues with this product please call the John Lewis Helpline on 01244 689949 or email mail@fwgroup-uk.com...
