SMART MAGNETIC RESISTANCE EXERCISE BIKE WITH DUMBBELL HOLDER SF-B123033 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment English, Pages 1~15 instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.
PRE-ASSEMBLY CHECK LIST Before you start to assemble, please make sure all parts are included. Description Spec. Qty. Description Spec. Qty. Main Frame Seat KX8022 Handlebar Post Adjustment Knob M16X1.5X22 Seat Post Meter BJHT-087 Handlebar Bottle Holder Seat Slider Dumbbell Rack Front Stabilizer 80X40X1.2X460 Manual...
HARDWARE PACKAGE Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓ The model number (found on cover of manual) ✓ The product name (found on cover of manual) ✓...
Page 5
ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669) STEP 1: Remove 2 Carriage Bolts (No. 14), 2 Flat Washers (No. 10), 2 Cap Nuts (No. 13) and 2 Spring Washers (No.
Page 6
We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669) STEP 3: IMPORTANT! Read instructions carefully, failure to do so may cause permanent damage to your bike. Remove the Left &...
Page 7
We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669) STEP 4: Loosen and pull out the Adjustment Knob (No. 26). Insert the Seat Post (No. 3) into the sleeve located on the Main Frame (No.
Page 8
We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669) STEP 6: Insert the Meter (No. 31) to the Meter Bracket (No. 34), then connect Sensor Wire (No.
ADJUSTMENT GUIDE ADJUSTING THE HANDLEBAR: It is important that the handlebar and seat are both set to the correct height of your body. To adjust the handlebar height, loosen and pull the Adjustment Knob (No. 26) outward, then slide the Handlebar Post (No.
TIGHTENING THE SEAT Tighten the Seat (No. 22) by using the Spanner (No. 95) if the Seat (No. 22) is loose. ADJUSTING THE BALANCE If the bike is not leveled, adjust the Rear End Caps (No. 17). Turn counter-clockwise to raise, turn clockwise to lower. ADJUSTING THE RESISTANCE Adjust the resistance of the bike using the Tension Control Knob (No.
BATTERY INSTALLATION & REPLACEMENT Battery Battery Cover BATTERY INSTALLATION 1. Take out 2 AAA batteries from the meter box. 2. Press the buckle of battery cover on the Meter (No. 31), then remove battery cover. 3. Install 2 AAA batteries into the battery case on the back of the Meter (No. 31). Pay attention to the battery + and –...
EXERCISE METER FUNCTION BUTTONS MODE: 1. Pressing the MODE key to select and lock on a function. 2. Press and hold the MODE key for 3 seconds to reset all the values to zero, except ODO (TOTAL DISTANCE). SLEEP MODE: 1.
APP CONNECTION: Connect Smart Equipment to SunnyFit App: 1. Scan to download SunnyFit from the app store: 2. Ensure that the Bluetooth function is turned on from your mobile device. 3. If this is your first time using the SunnyFit app, follow the in-app instructions to register for your free SunnyFit account and log in.
MAINTENANCE INSTRUCTIONS This is general information for daily, weekly, and monthly maintenance to be performed on your bike. DAILY MAINTENANCE MONTHLY MAINTENANCE After each exercise session, wipe down all 1. Check all hardware is secure, such as: bottle the equipment: seat, frame, and handlebars. holder, flywheel nuts, belt/chain guard bolts, Pay special attention to the seat post, brake caliper lock nuts and brake caliper...
PARTS LIST Description Spec. Qty. Description Spec. Qty. Main Frame Sensor Wire L850 Handlebar Post Pulse Wire A L650 Seat Post Pulse Wire B L650 Handlebar Meter Bracket Seat Slider Bottle Holder Front Stabilizer 80X40X1.2X460 Screw with Washer M5X16 Rear Stabilizer 80X40X1.2X500 Screw M4X15...
Page 16
Description Spec. Qty. Description Spec. Qty. Φ12.2XΦ18X4 Φ240X20 Sleeve Belt Pulley Φ18XΦ12.2X65.2 Flywheel Sleeve Belt 500PJ6 Φ18X3XΦ14X7XΦ10X10 Adjusting Belt Bolt M8X48 Sleeve Magnet 25X10X5 Flywheel Cover Φ12XL28.6XM6 Magnetic Board Axle Sensor Bracket Φ14.5XΦ1.6Φ61.2 Pull Spring Brake Sheet 9X35X26 Cross Countersunk Outer Belt Cover M5X12 Head Screw...
Page 17
INFORMACIÓN IMPORTANTE SOBRE SEGURIDAD Le agradecemos que haya elegido nuestro producto. Para garantizar su seguridad y su salud, utilice este equipo correctamente. Es importante leer este manual en su totalidad antes de montar y utilizar el equipo. Sólo se puede lograr un uso seguro y eficaz si el equipo se monta, mantiene y utiliza correctamente.
Page 18
LISTA DE COMPROBACIÓN PREVIA AL MONTAJE Antes de empezar a montar, asegúrese de que se incluyen todas las piezas. n.° Descripción Espec. Cant. n.° Descripción Espec. Cant. Bastidor Principal Asiento KX8022 Tija del Manillar Pomo de Ajuste M16X1.5X22 Tija de Sillí n Medidor BJHT-087 Manillar...
Page 19
PAQUETE DE HARDWARE Pedido de piezas de repuesto (sólo para clientes de EE.UU. y Canadá) Proporcione la siguiente informació n para que podamos identificar con precisión la(s) pieza(s) necesaria(s): ✓ El nú mero de modelo (se encuentra en la portada del manual) ✓...
INSTRUCCIONES DE MONTAJE Valoramos su experiencia con los productos Sunny Health and Fitness. Para obtener ayuda con las piezas o la resolución de problemas, pó ngase en contacto con nosotros en support@sunnyhealthfitness.com o en el 1-877-90SUNNY (877-907-8669). PASO 1: Retire los 2 Pernos de Carro (n.° 14), las 2 Arandelas Planas (n.°...
Page 21
Valoramos su experiencia con los productos Sunny Health and Fitness. Para obtener ayuda con las piezas o la resolución de problemas, pó ngase en contacto con nosotros en support@sunnyhealthfitness.com o en el 1-877-90SUNNY (877-907-8669). PASO 3: ¡ IMPORTANTE! Lea atentamente las instrucciones, de lo contrario podrí...
Page 22
Valoramos su experiencia con los productos Sunny Health and Fitness. Para obtener ayuda con las piezas o la resolución de problemas, pó ngase en contacto con nosotros en support@sunnyhealthfitness.com o en el 1-877-90SUNNY (877-907-8669). PASO 4: Afloje y extraiga el Pomo de Ajuste (n.° 26). Inserte la Tija de Sillí...
Page 23
Valoramos su experiencia con los productos Sunny Health and Fitness. Para obtener ayuda con las piezas o la resolución de problemas, póngase en contacto con nosotros en support@sunnyhealthfitness.com o en el 1-877-90SUNNY (877-907-8669). PASO 6: Inserte el Medidor (n.° 31) en el Soporte del Medidor (n.°...
GUÍ A DE AJUSTE AJUSTE DEL MANILLAR: Es importante que tanto el manillar como el asiento estén ajustados a la altura correcta de su cuerpo. Para ajustar la altura del manillar, afloje y tire de la Pomo de Ajuste (n.° 26) hacia fuera, luego deslice el Tija del Manillar (n.°...
APRETAR EL ASIENTO: Si el Asiento (n.° 22) está flojo, ajústelo con la Llave (n.° 95). AJUSTE DEL EQUILIBRIO: Si la moto no está nivelada, ajuste los Tapas Traseras (n.° 17). Gire en sentido contrario a las agujas del reloj para elevar, gire en sentido de las agujas del reloj para bajar.
INSTALACIÓN Y SUSTITUCIÓN DE BATERÍ AS Baterí a Tapa de la Baterí a INSTALACIÓN DE LA BATERÍ A 1. Extraiga 2 baterí as AAA de la caja del medidor. 2. Presione la hebilla de la tapa de las baterí as en el Medidor (n.° 31) y, a continuación, retire la tapa de las baterí...
MEDIDOR DE EJERCICIO BOTONES DE FUNCIÓN MODE: 1. Pulse la tecla MODE para seleccionar y bloquear una función. 2. Mantenga pulsada la tecla MODE durante 3 segundos para poner a cero todos los valores, excepto ODO (DISTANCIA TOTAL). MODO SUEÑO: 1.
Page 28
CONEXIÓN A LA APP: Conecte el equipo inteligente a la SunnyFit App: 1. Escanee para descargar SunnyFit desde la tienda de aplicaciones: 2. Asegúrese de que la función Bluetooth está activada desde su dispositivo móvil. 3. Si es la primera vez que utiliza la app SunnyFit, siga las instrucciones de la app para registrarse en su cuenta gratuita de SunnyFit e iniciar sesió...
INSTRUCCIONES DE MANTENIMIENTO Esta es información general para el mantenimiento diario, semanal y mensual que debe realizar en su motocicleta. MANTENIMIENTO DIARIO MANTENIMIENTO MENSUAL Después de cada sesión de ejercicio, limpie todo 1. Compruebe que toda la tornillerí a está bien el equipo: sillí...
LISTA DE PIEZAS n.° Descripción Espec. Cant. n.° Descripción Espec. Cant. Bastidor Principal Cable del Sensor L850 Tija del Manillar Cable de Impulsos A L650 Tija de Sillí n Cable de Impulsos B L650 Manillar Soporte del Medidor Deslizador de Asiento Sea Soporte Botella Estabilizador Delantero 80X40X1.2X460...
Page 31
n.° Descripción Espec. Cant. n.° Descripción Espec. Cant. Φ12.2XΦ18X4 Φ240X20 Manguito Polea de Correa Φ18XΦ12.2X65.2 Manguito del Volante Correa 500PJ6 Perno de la Correa Φ18X3XΦ14X7XΦ10X10 M8X48 Manguito de Ajuste Imán 25X10X5 Tapa Volante Tablero Magnético Φ12XL28.6XM6 Soporte Sensor Φ14.5XΦ1.6Φ61.2 Muelle de Tracción Hoja Freno 9X35X26 Cubierta Exterior de...
Page 32
EXPLODED DIAGRAM (DIAGRAMA DE DESPIECE) 1...
Page 33
EXPLODED DIAGRAM (DIAGRAMA DE DESPIECE) 2 Version: 1.1...
