  • Page 1 USER MANUAL U1 VOICE Digital System Version: V1.0 Code: SRD -UME-0612-V1.0...
  • Page 2 Preamble Thank you for purchasing Urmet products. This document is the user manual of the U1 Voice system. The user should read this manual thoroughly before operating the products of U1 Voice system. Disclaimer The description, pictures, tables, etc. in this document have been written and verified to the best of knowledge and responsibility of the authors and editors.

  • Page 3: Table Of Contents

    IS IN YOUR LIFE Contents Requirements for Installation Environment ..................2 Storage & Transportation ........................2 Cabling Requirements of System ......................2 Introduction of System .......................... 3 Features ............................... 3 Functions ............................3 Topological graph ..........................5 Instruction for Use of Device ......................... 6 Monitor ..............................

  • Page 4: Requirements For Installation Environment

    IS IN YOUR LIFE Requirements for Installation Environment  The communication signals shall be far away from the interference source as far as possible. The noise or electromagnetic device, if interfering the working system, may influence the audio and video signal. ...

  • Page 5: Introduction Of System

    IS IN YOUR LIFE Introduction of System Adopting TCP/IP pure digital networking, digital intercom system for building has digitally visual intercom, multi-channel calling, household-to-household intercom, information release, alarm linkage and other functions. With overall TPC/IP networking, the system can directly connect to all products with standard 2-layered network switch, fully meeting the needs of creating digital intercom community of clients.
  • Page 6 IS IN YOUR LIFE board can monitor call module and MCM. The call modules can be switched during monitoring.  Multichannel function: The system adopts TCP/IP networking, realizing the video and audio intercom of device of 100 ways under the bandwidth in100M LAN of the same trunk, and avoiding the engaging of different calls at the same time.

  • Page 7: Topological Graph

    IS IN YOUR LIFE Topological graph Main PoE...

  • Page 8: Instruction For Use Of Device

    IS IN YOUR LIFE Instruction for Use of Device Monitor As a TCP/IP transport protocol-based device and the constituent device of digital intercom system for building, this product supports visual intercom, defense zone settings and stand-by picture pushing. Function features 7-inchcapacitive touch screen;...
  • Page 9 IS IN YOUR LIFE Appearance Front View of Monitor...
  • Page 10 IS IN YOUR LIFE Operation instruction Visitor call Initiative call The visitor calls the monitor through call Click in main interface to enter into intercom module, then the call module will vibrate and interface. ring. 1. Call The tenant talks with the visitor after pressing Dial the other monitors of the tenant, click pop up the list of monitor, and select the extension to The tenant unlocks for the visitor by pressing...
  • Page 11 IS IN YOUR LIFE Community monitoring: Click to select IP camera for monitoring. Settings System settings Engineering settings 1. Time settings 2. Camera settings 3. Call transfer settings 1. Room number settings 4. Password settings 5. Alarm settings 6. PCM settings 2.
  • Page 12 IS IN YOUR LIFE Installation Support (The same below) Wall Surface Wall Surface Steps: 1) Fix the support: Fix the support on the wall surface with 503 concealed box, mounting box (diameter: 60) or mounting box (86 x 86) and the screws provided with the device; 2) Wire: Connect the lines on the back of the extension successively based on the instruction;...
  • Page 13 IS IN YOUR LIFE Wiring Diagram of Defense Zone Z(1~7) single security detector: Z8 single defense zone: Normally Opened Normally Closed Normally Interface Interface Opened Interface Z (1~7) multiple-security detectors: Normally Normally Normally Opened Opened Opened Normally Closed Normally Closed Normally Closed Z8 multiple-security detectors: Normally...
  • Page 14 IS IN YOUR LIFE out once the zone is triggered before the delay defense zone after the defense is set up; otherwise the trigger countdown will start. The user shall cancel the defense before the deadline; otherwise the alarm will be given out.

  • Page 15: Switch Board

    IS IN YOUR LIFE Switch board This product is a TCP/IP transport protocol-based device and the central device of managing community tenant and access host. Function features 7-inch capacitive touch screen design; Monitor and call module call receivable; Synchronous alarm information of monitor; Alarm information storage function;...
  • Page 16 IS IN YOUR LIFE Appearance 话柄 摄像头 触摸屏 刷卡区 主 免 报 视 麦 开 扬 6 7 8 9 10 界 提 警 频 克 锁 声 面 键 信 监 风 键 器 按 息 视 Front view of switchboard 键...
  • Page 17 IS IN YOUR LIFE Operation Instruction Call intercom: Call history: Click Call Intercom button in main interface and select Click Call History icon to enter in call history device type to call. interface. Check the call history between management Call monitor: center and tenant/visitor.
  • Page 18 IS IN YOUR LIFE External interface Interface description Interface drawing 交换机 电源 Power Supply...

  • Page 19: Call Module

    IS IN YOUR LIFE Call module As the main constituent device of digital intercom system for building, this product is connected with standard Category 5 cable, hence realizing the call with monitor or switch board and supporting IC access control. Function features 4.3-inch TFT display screen;...
  • Page 20 IS IN YOUR LIFE Appearance Aluminum panel Lens Flash light aperture Display zone Card slotting zone Button zone Loudspeaker Front View of Call Module...
  • Page 21 IS IN YOUR LIFE External interface Interface description Interface drawing Exit Button Gate Magnet Electronic control lock ①: Network interface (supports non-standard POE power supply, which shall be custom-made). ②: Power input interface DC 24V ③ : +12V will only be supplied when call module input voltage is more than 18V. The actual voltage will be lower than +10V when the input voltage is +12V.
  • Page 22 IS IN YOUR LIFE Operation instruction Call tenant Call management center The visitor enters room number (e.g. 0101) to call. The visitor can call the management center of The device rings, and the visitor can cancel the call community by pressing on the call module by pressing *.
  • Page 23 IS IN YOUR LIFE Installation method Buckle Groove Buckle Embedded Box Call Module Install the embedded box on the reserved groove on the wall, penetrate the terminal through the outlet, and Ground fix it with wall nail or seal it with cement around the embedded box.

  • Page 24: Pcm

    IS IN YOUR LIFE As a PCM of digital intercom system of U1 series for building, this product is connected with standard Category 5 cable, hence realizing the visible intercom call with monitor or switch board and supporting IC access control. Function features IC card allowed;...
  • Page 25 IS IN YOUR LIFE Appearance Camera Flash Light Microphone Induction Zone Call Button Gate Plate Window Loudspeaker Front View of PCM...
  • Page 26 IS IN YOUR LIFE External interface Interface description Interface drawing Exit Button Gate Magnet Electronic control lock RJ45 network interface: Connecting line interface (allows 24V non-standard POE interchanger; NO COM NC: Normally opened/closed interface; GS GS-GND: Gate status detection interface; UNLOKC: Indoor unlocking interface;...
  • Page 27 IS IN YOUR LIFE Configuration PCM matches with monitor Keep pressing the button of call module until hearing “toot, toot, toot” and press it until hearing long “toot” within 3 minutes after powering up, then the PCM can be configured. Click Engineering Settings in main interface of monitor, enter engineering password 000000 to go to settings interface, select PCM 1 or PCM 2 and the device on the right of the interface, click Monitor,...
  • Page 28 IS IN YOUR LIFE Operation Call tenant Call management center The visitor press Call button and the device rings, Keep pressing Call button for 2s. The device rings, during which press the button to reset 30s count down while automatically ends when there is no response and keep pressing it to call management.
  • Page 29 IS IN YOUR LIFE 卡扣 Buckle Step 2: Insert Wall 墙体 PCM into embedded Embedded box, and 埋墙盒 tighten it with screw. 螺丝 Screw Recommended installation height...

  • Page 30: Engineering Debugging

    IS IN YOUR LIFE Engineering Debugging Connect all devices based on the wiring instruction of product, power up and debug the system after the inspection. Debug the system from the corridor to networking system, i.e. debug the device of corridor one by one and then debug the networking system.

  • Page 31: Unit Debugging

    IS IN YOUR LIFE Unit debugging Call module calls monitor Enter room number 0101 in call module to call monitor. The monitor will be unlocked after replying. Indoor monitoring Press Monitor button to monitor call module. PCM calls monitor Press PCM button to call monitor. The monitor will be unlocked after replying. [Note] Please read Troubleshooting of this handbook in the case of any faults during debugging.

  • Page 32: Networking Debugging

    IS IN YOUR LIFE Switch board settings Number settings: Settings -> Engineering Settings -> Number Settings [Note] Enter engineering number 000000. Set switch board number in Number Settings (effective address: 01~32). Switch board zone settings: Main switch board (default): Settings -> System Settings -> Incoming Call Management -> All Units Zone switch board: Settings ->...
  • Page 33 IS IN YOUR LIFE The list of networking device will be automatically generated after the research. Monitor calls switch board Press “Switch Board” button on monitor to call switch board. The switch board will reply. Monitor monitors MCM Select MCM in switch board, and enter MCM number (e.g. enter “01” when monitoring #01 MCM). Security alarm of monitor Set up and trigger the defense of monitor to give out alarm, then monitor, switch board and PC switch board will give out alarm accordingly.

  • Page 34: Troubleshooting

    IS IN YOUR LIFE Troubleshooting The common faults and troubleshooting methods, as shown below, are only for your reference. Please consult our customer service staff or dealer if the faults cannot be solved. Faults Methods The networking logo of 1. Check the connected netting twine between the monitor status bar turns monitor and its interchanger;...
  • Page 35 IS IN YOUR LIFE Check whether the terminal is well contacted, whether The communication fails. the set device number is wrong; Monitor networking logo Check whether monitor and interchanger are well turns grey. connected; Call module is powered on, display screen works Check whether the button is stuck;...

  • Page 36: Project Cases

    IS IN YOUR LIFE Project cases Client demands Building A (9 tenants/floor * 8 floors) and Building B (20 tenants/floor * 8 floors) are situated in a community, each of which is required for 1 call module for access control. 2 external enclosing wall gates and 2 MCMs have been used in the community.
  • Page 37 IS IN YOUR LIFE Wiring Diagram of Defense Zone of Building A Wiring Diagram of Defense Zone of Building B Configuration List of Product: Qty. [Note]Unit interchanger is 2-layered networking interchanger. Room Number of Building A/B 0801-0803 0804-0806 0807-0809 0801-0807 0808-0814 0815-0820 0701-0703...
  • Page 38 IS IN YOUR LIFE Setting & debugging of unit device Please set and debug the unit device based on Engineering Debugging. Setting & debugging of networking device Please set ad debug the height of networking device based on Engineering Debugging.

  • Page 39: Appendix

    IS IN YOUR LIFE Appendix Other cabling diagram  Unlocking and wiring of signal Power Supply 电源 电源 Power Supply NC COM NO NO COM NC Normally opened unlocking and wiring method Normally closed unlocking and wiring method Note]Please check whether relevant parameters meet the requirements when signal unlocking is powered by the call module of the system, preventing the device from being damaged.
  • Page 40 IS IN YOUR LIFE [Note] The gate status alarm function can be turned off in 2 ways: 1. Ground GS port of host; 2. Set the gate status alarm to Forbidden (see “System settings -> Gate status alarm” of “Instruction for Use of Device”).

  • Page 41: Production Method Of Netting Twine

    IS IN YOUR LIFE Production method of netting twine Face the end of plug toward yourself, and make sure the contact point is at the bottom of the plug, then the leftmost contact point is ① and the rightmost one is ⑧ . Line sequence of EIA/TIA-568A: Green and white --- 1, green --- 2, orange and white --- 3, blue --- 4, blue and white --- 5, orange --- 6, brown and white --- 7, brown --- 8;...
  • Page 42 IS IN YOUR LIFE Step 3: Sector 4 pairs of core wire, arrange and straighten them from left to right based on the corresponding interface standard (EIA/TIA-568A or EIA/TIA-568B, see the appendix), until they are parallel with each other. Then cut them evenly with diagonal pliers, as shown below (EIA/TIA-568B is adopted herein): Step 4: Turn the side of the plastic joint with clip upside down, and horizontally plug the ordered twisted pair into the trunking of plastic joint.
  • Page 43 IS IN YOUR LIFE Step 5：Put the plastic joint in RJ-45 clamping slot of crimping plier, press and clamp it in the twisted pair after confirming the conductor sequence and connecting the conductor. It is recommended to clamp it for several times.
  • Page 44 IS IN YOUR LIFE two sets of indicators on it will flash, as shown below: 8 indicators on the tester will successively flash green light when the tested cable is shoot-through cable.
