Page 1 MX432, XM3142 MFPs Service Manual www.lexmark.com June 2024 ...
Page 2: Product Information
Product information Product name: Lexmark MX432adwe; Lexmark XM3142 MFPs Machine type: 7019-6wx Model(s): 6w6, 6w9...
Page 3: Edition Notice
Evaluation and verification of operation in conjunction with other products, programs, or services, except those expressly designated by the manufacturer, are the user’s responsibility. Lexmark and the Lexmark logo are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard ...
Page 4: Table Of Contents
Service Manual Contents Product information ..................2 Edition notice....................3 Notices, conventions, and safety information Laser notice......................12 Avis relatif à l'utilisation du laser................12 Aviso de láser ......................12 Laser-Hinweis......................13 Conventions ......................13 Safety information ....................14 Consignes de sécurité....................15 Información de seguridad..................
Page 5 Service Manual Precauciones durante la solución de problemas ............34 Vorsichtsmaßnahmen bei der Fehlerbehebung ............35 Troubleshooting overview ................... 36 Performing the initial troubleshooting check ............. 36 Using Safe Mode....................... 36 Securing the printer..................... 37 Resetting the printer without admin credentials ............37 Using the security reset jumper.................
Page 6 Service Manual 242 paper jams......................97 242 paper jam messages ....................97 280–295 paper jams....................98 280–295 paper jam messages ..................98 ADF jam service check......................98 User attendance messages ................102 User attendance messages..................102 Unsupported or unresponsive toner cartridge service check ........106 ............................106 Unsupported or unresponsive imaging unit service check........107 ............................107 Mismatched supplies error service check ...............
Page 7 Service Manual 900 error messages......................140 900 error service check ....................140 912 errors ........................ 145 912 error messages......................145 Optional tray communication error service check............147 938–992 errors ......................148 938–992 error messages....................148 NVRAM mismatch failure service check................149 Other symptoms ....................151 Base printer symptoms.................... 151 Base printer symptoms....................151 Tray near empty service check..................152 False bin full error service check ..................153...
Page 8 Service Manual Serial number ........................178 Model name ........................178 Engine setting [x] ......................179 EP setup ..........................179 Input tray quick print ....................179 Scanner Diagnostics ....................179 Motor Tests ........................179 Sensor Test........................180 Feed Test .........................181 Scanner Calibration Reset....................181 ............................181 Controller Calibration.......................181 Configuration Menu................... 182 Entering the Configuration Menu................
Page 9 Service Manual Left side removals ..................... 206 Left cover removal....................206 Main drive gears removal ..................209 Imaging unit coupling removal................. 215 Pick roller clutch removal ..................216 Left front door link removal..................218 Right side removals................... 220 Right cover removal ....................220 Controller board removal..................
Page 10 Service Manual ADF tray removal ....................278 ADF separator pad removal ..................278 ADF and scanner removal..................279 ..........................281 Scanner pivot arm removal ..................282 Replacing parts ....................284 Replacing the imaging unit ..................284 Replacing the tray ....................287 Replacing the pick roller assembly................
Page 11 Service Manual Applicability of Regulation (EU) 2019/2015 and (EU) 2019/2020 ..... 336 Noise emission levels..................336 Temperature information ................... 336 Theory of operation POR sequence ....................337 Print cycle operation..................337 Print engine layout....................337 Print cycle........................ 338 Flowchart .........................338 Charge ..........................338 Expose..........................338 Develop ...........................339...
Page 12: Notices, Conventions, And Safety Information
Notices, conventions, and safety information Notices, conventions, and safety information Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1: 2014.
Page 13: Laser-Hinweis
Notices, conventions, and safety information Los productos láser de Clase I no se consideran peligrosos. El sistema láser y la impresora se han diseñado para que el ser humano no acceda nunca a las radiaciones láser por encima del nivel de Clase I durante su uso normal, ni en tareas de mantenimiento o intervenciones de servicio técnico prescritas. El conjunto de cabezal de impresión de la impresora no se puede reparar y contiene un láser con las siguientes especificaciones: Class: IIIb (3b) AlGaInP...
Page 14: Safety Information
Notices, conventions, and safety information CAUTION—HOT SURFACE Indicates a risk of burn if touched. CAUTION—TIPPING HAZARD Indicates a crush hazard. CAUTION—PINCH HAZARD Indicates a risk of being caught between moving parts. Safety information • The safety of this product is based on testing and approvals of the original design and specific components.
Page 15: Consignes De Sécurité
CAUTION—POTENTIAL INJURY Only a Lexmark Inline Surge Protector that is properly connected between the printer and the power cord provided with the printer may be used with this product. The use of non-Lexmark surge protection devices may result in a risk of fire, property damage, or poor printer performance.
Page 16 CAUTION—POTENTIAL INJURY Utilisez uniquement un parasurtenseur correctement raccordé à l'imprimante et au câble d'alimentation fourni avec la machine. L'utilisation de parasurtenseurs non fabriqués par Lexmark comporte un risque d'incendie et de dégâts matériels, et peut amoindrir les performances de l'imprimante. CAUTION—POTENTIAL INJURY N'utilisez pas ce produit avec un parasurtenseur en ligne.
Page 17: Información De Seguridad
Notices, conventions, and safety information CAUTION—POTENTIAL INJURY Si votre imprimante pèse plus de 20 kg (44 lb), l'intervention d'au moins deux personnes est nécessaire pour la soulever sans risque. Información de seguridad • La seguridad de este producto se basa en las pruebas y comprobaciones del diseño original y los componentes específicos. El fabricante no se hace responsable de la seguridad en caso de uso de piezas de repuesto no autorizadas.
Page 18: Sicherheitshinweise
Lexmark debidamente conectado entre la impresora y el cable de alimentación que con ella se suministra. El uso de protectores de sobretensión de marcas distintas a Lexmark puede dar lugar a que el rendimiento de la impresora sea bajo, a daños materiales o a posibles incendios.
Page 19 Brandgefahr, Beschädigung von Eigentum oder einer eingeschränkten Druckerleistung führen kann. CAUTION—POTENTIAL INJURY Mit diesem Produkt darf nur ein Lexmark Inline Surge Protector verwendet werden, der vorschriftsgemäß zwischen dem Drucker und dem mitgelieferten Netzkabel angeschlossen ist. Die Verwendung von nicht von Lexmark stammenden Überspannungsschutzgeräten kann zu Brandgefahr,...
Page 20 Notices, conventions, and safety information CAUTION—POTENTIAL INJURY Verwenden Sie dieses Produkt nicht mit einem Inline- Überspannungsschutz. Die Verwendung von Überspannungsschutzgeräten kann zu Brandgefahr, Beschädigung von Eigentum oder einer eingeschränkten Druckerleistung führen. CAUTION—POTENTIAL INJURY Wenn der Drucker mehr als 20 kg wiegt, sind zum sicheren Anheben mindestens zwei Personen notwendig.
Page 21: Change History
Change history Change history Change history June 14, 2024 • Added information about the ellipses loading screen on the Entering Recovery mode topic of the Service menus chapter. See Entering Recovery mode on page 188. August 17, 2023 • Updated the Motor (main drive) service check topic of the Diagnostics and troubleshooting chapter.
Page 22: General Information
General information General information Printer model configurations The Lexmark™ MX432 and XM3142 MFPs are monochrome, network‑capable laser printers. Model name Configuration/description Machine type/model number MX432adwe Network, duplex, print, 7019-6w6 scan, fax, ADF, 4.3-inch XM3142 7019-6w9 touch screen, and front USB port Selecting paper Paper guidelines Use the appropriate paper to prevent jams and help ensure trouble‑free printing. •...
Page 23: Smoothness
General information high temperatures. Storing paper unwrapped in hot, humid, cold, or dry conditions can contribute to paper curling before printing and can cause feeding problems. Smoothness Paper smoothness directly affects print quality. If paper is too rough, toner cannot fuse to it properly.
Page 24: Selecting Preprinted Forms And Letterhead
General information • Coated papers (erasable bond), synthetic papers, thermal papers • Rough‑edged, rough or heavily textured surface papers, or curled papers • Recycled papers that fail EN12281:2002 (European) • Paper weighing less than 60 g/m (16 lb) • Multiple‑part forms or documents Selecting preprinted forms and letterhead • Use grain long paper. •...
Page 25 General information Paper size Standard Optional Multipurpose Two‑sided 250‑sheet 550‑sheet feeder printing tray tray ✓ ✓ ✓ A5 Portrait (SEF) 148 x 210 mm (5.83 x 8.27 in.) ✓ ✓ ✓ Landscape (LEF) 210 x 148 mm (8.27 x 5.83 in.) ✓...
Page 26 General information Paper size Standard Optional Multipurpose Two‑sided 250‑sheet 550‑sheet feeder printing tray tray ✓ ✓ ✓ Executive 184.2 x 266.7 (7.25 x 10.5 in.) ✓ ✓ ✓ ✓ Letter 215.9 x 279.4 (8.5 x 11 in.) ✓ ✓ ✓ ✓...
Page 27 General information Paper size Standard Optional Multipurpose Two‑sided 250‑sheet 550‑sheet feeder printing tray tray ✓ 10 Envelope 104.8 x 241.3 (4.12 x 9.5 in.) ✓ DL Envelope 110 x 220 mm (4.33 x 8.66 in.) ✓ C5 Envelope 162 x 229 mm (6.38 x 9.01 in.) ✓...
Page 28: Supported Paper Types
General information Supported paper types Paper type Standard Optional Multipurpose Two‑sided Automatic 250‑sheet 550‑sheet feeder printing document tray tray feeder ✓ ✓ ✓ ✓ ✓ Plain paper ✓ Card stock ✓ ✓ ✓ ✓ Recycled ✓ ✓ ✓ Paper labels* ✓...
Page 29: Supported Fax
✓ ✓ XM3142 Needs a subscription. For more information, go to https://www.etherfax.net/lexmark contact the place where you purchased the printer. Needs an installed license bundle. For more information, contact the place where you purchased the printer. Finding the printer serial number...
Page 30 General information 2. Locate the printer serial number behind the front door.
Page 31: Tools Required For Service
General information Tools required for service • Flat-head screwdrivers, various sizes • #1 Phillips screwdriver, magnetic • #2 Phillips screwdriver, magnetic • #2 Phillips screwdriver, magnetic short-blade • Torx screwdriver (T20 head) • Needle‑nose pliers • Diagonal side cutters • Spring hook •...
Page 32: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Diagnostics and troubleshooting Troubleshooting precautions CAUTION—SHOCK HAZARD When you see this symbol on the product, there is a danger from hazardous voltage in the area of the product where you are working. Unplug the product before you begin, or use caution if the product must receive power in order to perform the task.
Page 33: Précautions De Dépannage
Diagnostics and troubleshooting Précautions de dépannage CAUTION—SHOCK HAZARD Ce symbole indique un danger lié à des niveaux de tension dangereux dans la zone du produit à manipuler. Débranchez le produit avant de commencer, ou agissez avec prudence si le produit doit être alimenté pour effectuer l'opération.
Page 34: Precauciones Durante La Solución De Problemas
Diagnostics and troubleshooting Precauciones durante la solución de problemas CAUTION—SHOCK HAZARD Cuando vea este símbolo en el producto, existe peligro de tensiones peligrosas en el área del producto en la que está trabajando. Desconecte el producto antes de empezar o tenga cuidado si el producto debe recibir alimentación a fin de realizar la tarea.
Page 35: Vorsichtsmaßnahmen Bei Der Fehlerbehebung
Diagnostics and troubleshooting Vorsichtsmaßnahmen bei der Fehlerbehebung CAUTION—SHOCK HAZARD Wenn Sie dieses Symbol sehen, besteht eine Gefahr durch gefährliche Spannungen in dem Produktbereich, in dem Sie arbeiten. Trennen Sie das Produkt von seiner Stromverbindung, bevor Sie beginnen, oder gehen Sie vorsichtig vor, wenn das Produkt für die Durchführung der Aufgabe mit Strom versorgt werden muss.
Page 36: Troubleshooting Overview
Diagnostics and troubleshooting Troubleshooting overview Performing the initial troubleshooting check • With the power cord unplugged from the electrical outlet, check if the cord is free from breakage, short circuits, disconnected wires, or incorrect connections. • Make sure that the printer is properly grounded. •...
Page 37: Securing The Printer
Diagnostics and troubleshooting Securing the printer Resetting the printer without admin credentials Note: • Resetting the printer or replacing the controller board deletes all security settings. • Before changing the security settings, ask permission from your administrator. Perform an Out of Service Erase to reset the printer to factory defaults without using admin credentials.
Page 38 Diagnostics and troubleshooting Move the jumper to cover the middle and exposed prongs. Note: The movement of the jumper triggers the reset, not the jumper position. Attach the controller board shield. Turn on the printer. Note: • The security framework remains in place after the reset. Public permissions are reset to default and now include Out of Service Erase as an option.
Page 39: Data Security Notice
Diagnostics and troubleshooting Data security notice Identifying printer memory • Volatile memory—The printer uses standard random access memory (RAM) to buffer user data temporarily during simple print and copy jobs. • Nonvolatile memory—The printer may use two forms of nonvolatile memory: EEPROM and NAND (flash memory). Both types are used to store the operating system, printer settings, network information, scanner and bookmark settings, and embedded solutions. The following parts can store memory: •...
Page 40 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 41 Diagnostics and troubleshooting Note: You may need a pair of pliers to remove pieces of plastic inside the imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the toner cartridge. Does the problem remain? ◦...
Page 42: Blank Page Check
Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 43 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove any packing material left on the imaging unit. Note: You may need a pair of pliers to remove pieces of plastic inside the imaging unit.
Page 44: Print Is Too Dark Check
From the control panel, navigate to Settings > Troubleshooting > Print Quality Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge.
Page 45 Diagnostics and troubleshooting Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦ Yes: Go to step 3. ◦ Go to the next step. Insert a genuine and supported Lexmark toner cartridge. Does the problem remain? ◦...
Page 46: Print Is Too Light Check
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove the right cover. See .Right cover removal on page 220 Make sure that the HVPS1 cable on the controller board and HVPS is properly connected.
Page 47 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 48 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Remove the imaging unit. Push either side of the transfer roller, and then check if it depresses and bounces back into place. If the transfer roller does not depress and bounce back into place, then reinstall the transfer roller.
Page 49: Paper Curl Check
Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 50 Diagnostics and troubleshooting The problem is solved. Check if the printer is using a genuine and supported Lexmark fuser. Is the printer using a genuine and supported Lexmark fuser? ◦ Yes: Go to step 5. ◦ Go to the next step.
Page 51: Folded Or Wrinkled Paper Check
Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Perform the following tests: Check if the printer is using a non-Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Make sure that the toner cartridge is compatible with the imaging unit.
Page 52: Solid Black Pages Check
Diagnostics and troubleshooting The problem is solved. Perform the following tests: Check the toner cartridge for leaks. Using an approved toner vacuum, completely remove the stray toner from the printer, toner cartridge, and imaging unit. Does the problem remain? ◦ Yes: Go to the next step.
Page 53 Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 54 Diagnostics and troubleshooting Is the charge roller contact free of damage and contamination? ◦ Yes: Go to step 6. ◦ Go to the next step. Perform the following tests: Perform a POR. Perform a print test. Does the problem remain? ◦...
Page 55: Skewed Print Check
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Skewed print check Note: Before performing this print quality check, print the Print Quality Test Pages. From the control panel, navigate to Settings > Troubleshooting > Print Quality Test Pages, and then perform the initial print quality check.
Page 56 Diagnostics and troubleshooting Is the paper supported? ◦ Yes: Go to step 5. ◦ Go to the next step. Remove the paper, and then load a supported one. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.
Page 57: Streaked Vertical Lines Appear On Prints During A Print Job Check
Diagnostics and troubleshooting ◦ Go to the next step. Replace the front door with MPF pick roller. See Front door removal on page 255. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Reinstall or replace the transfer roller.
Page 58 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 59: Streaked Vertical Lines Appear On Prints During A Copy Job Check
Diagnostics and troubleshooting Streaked vertical lines appear on prints during a copy job check Note: Before performing this print quality check, print the Print Quality Test Pages. From the control panel, navigate to Settings > Troubleshooting > Print Quality Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Perform the following tests:...
Page 60 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. With the scanner cover open, perform a copy job to check the scanner lamp. Note: The scanner lamp must light up and move along the scan area. Is the scanner lamp functional? ◦...
Page 61: Horizontal Light Bands Check
Diagnostics and troubleshooting Is the firmware updated to the latest version? ◦ Yes: Go to step 11. ◦ Go to the next step. Update the firmware. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the controller board is properly installed.
Page 62 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 63: Vertical Light Bands Check
Replace the fuser. See .Fuser removal on page 264 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 64: Vertical Dark Bands Check
Diagnostics and troubleshooting Is the printer using a genuine and supported Lexmark toner cartridge? ◦ Yes: Go to step 5. ◦ Go to the next step. Insert a genuine and supported Lexmark toner cartridge. Does the problem remain? ◦ Yes: Go to the next step.
Page 65 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 66: Vertical Dark Streaks With Print Missing Check
Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 67 Diagnostics and troubleshooting Go to step 5. ◦ Go to the next step. Insert a genuine and supported Lexmark toner cartridge. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove any packing material left on the imaging unit.
Page 68: White Streaks And Voided Areas Check
Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 69: Clipped Pages Or Images Check
Diagnostics and troubleshooting Check the status of the imaging unit. Is the imaging unit near its end of life? ◦ Yes: Go to the next step. ◦ Contact the next level of support. Replace the imaging unit. Does the problem remain? ◦...
Page 70 Yes: Go to the next step. ◦ The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 71: Incorrect Margins On Prints Check
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Incorrect margins on prints check Note: Before performing this print quality check, print the Print Quality Test Pages. From the control panel, navigate to Settings > Troubleshooting > Print Quality Test Pages, and then perform the initial print quality check.
Page 72: Toner Rubs Off Check
Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 73: Toner Specks Appear On Prints During A Print Job Check
Test Pages, and then perform the initial print quality check. See Performing the initial troubleshooting check on page Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier. Is the printer using a genuine and supported Lexmark toner cartridge? ◦...
Page 74 Diagnostics and troubleshooting ◦ Go to the next step. Insert a genuine and supported Lexmark toner cartridge. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: From the control panel, navigate to Status/Supplies > Supplies.
Page 75: Toner Specks Appear On Prints During A Copy Job Check
Diagnostics and troubleshooting Using an approved toner vacuum, completely remove the stray toner from the printer, toner cartridge, and imaging unit. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Toner specks appear on prints during a copy job check Note: Before performing this print quality check, print the Print Quality Test Pages.
Page 76: Repeating Defects Check
Diagnostics and troubleshooting ◦ The problem is solved. Replace the ADF and scanner. See .ADF and scanner removal on page 279 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the controller board is properly installed.
Page 77 Diagnostics and troubleshooting ◦ 37.7 mm (1.48 in.) ◦ 96 mm (3.78 in.) Does the distance between the repeating defects match any of the measurements? ◦ Yes: Go to the next step. ◦ Go to step 3. Replace the imaging unit. Does the problem remain? ◦ Yes: Go to the next step.
Page 78: 200 Paper Jams
Diagnostics and troubleshooting The problem is solved. Check if the distance between the repeating defects is equal to any of the following: ◦ 62.5 mm (2.46 in.) ◦ 79.8 mm (3.14 in.) Does the distance between the repeating defects match any of the measurements? ◦ Yes: Go to the next step.
Page 79: Sensor (Input): Paper Arrived Too Early Jam Service Check
Diagnostics and troubleshooting Error code Description Action 200.12 Paper fed from tray 1 was Sensor (input): Paper detected earlier than arrived too early jam service expected at the sensor check on page (input). 200.13 Paper fed from tray 1 was .Sensor (input): Paper detected later than failed to arrive jam service...
Page 80 Diagnostics and troubleshooting Perform the following tests: Make sure that the MPF pick roller is free of contamination. Clean the MPF pick roller. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the front door. See Front door removal on page 255.
Page 81: Sensor (Input): Paper Cleared Too Early Jam Service Check
Diagnostics and troubleshooting ◦ Yes: Go to step 9. ◦ Go to the next step. Perform the following tests: Remove the right cover. See .Right cover removal on page 220 Make sure that the JMTR1 sensor cable is properly connected to the controller board. Does the problem remain? ◦...
Page 82 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Check the tray for crumpled, damaged, or deformed paper. Are there crumpled, damaged, or deformed paper in the tray? ◦ Yes: Go to the next step. ◦...
Page 83: Sensor (Input): Paper Failed To Arrive Jam Service Check
Diagnostics and troubleshooting Sensor (input): Paper failed to arrive jam service check Note: This service check is not applicable to tray 2. Perform the following tests: Remove the tray insert. Make sure that the paper is properly loaded in the tray. From the printer control panel or Printing Preferences or Print dialog, verify the paper size setting.
Page 84: Sensor (Input): Paper Failed To Clear Jam Service Check
Diagnostics and troubleshooting The problem is solved. Perform the following tests: Enter theDiagnostics menu, and then navigate to: Printer diagnostics & adjustments > Sensor tests Find the sensor (input). Make sure that the sensor actuator freely moves and is not stuck. Does the sensor status change while toggling the sensor? ◦...
Page 85 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the tray is not overfilled. Make sure that the paper guides are not set too tight against the paper. Does the problem remain? ◦...
Page 86 Diagnostics and troubleshooting ◦ The problem is solved. Make sure that the pick roller is free of contamination. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Replace the pick roller. Replace the separator roller.
Page 87: Sensor (Input): Static Jam Service Check
Diagnostics and troubleshooting Sensor (input): Static jam service check Check the paper path for paper fragments and partially fed paper. Is the paper path free of paper fragments and partially fed paper? ◦ Yes: Go to step 3. ◦ Go to the next step. Remove the paper fragments and partially fed paper.
Page 88: 202 Paper Jams
Diagnostics and troubleshooting 202 paper jams 202 paper jam messages Error code Description Action 202.03 Paper fed from the MPF Sensor (fuser exit): never arrived at the sensor Paper failed to arrive jam (fuser exit). service check on page 202.13 Paper fed from tray 1 never arrived at the sensor (fuser exit).
Page 89 Diagnostics and troubleshooting Go to step 3. ◦ Go to the next step. Remove the paper fragments and partially fed paper. Warning—Potential Damage Do not remove any paper or paper fragments from the fuser using tools. Does the problem remain? ◦ Yes: Go to the next step.
Page 90 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests Find the main motor (forward). Open the front door, remove the imaging unit, and then close the front door.
Page 91: Sensor (Fuser Exit): Paper Cleared Too Early Jam Service Check
Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the metal shutter in the printer frame is not stuck. Check the metal shutter for fuser entry. Does the metal shutter freely move? ◦...
Page 92 Diagnostics and troubleshooting Check the rear door for damage. Is the rear door functional and free of damage? ◦ Yes: Go to step 3. ◦ Go to the next step. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...
Page 93: Sensor (Fuser Exit): Static Jam Service Check
Diagnostics and troubleshooting Go to step 8. ◦ Go to the next step. Replace the redrive. See .Redrive removal on page 267 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform a print test. Does the problem remain? ◦...
Page 94: 232 Paper Jams
Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform a print test. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. 232 paper jams 232 paper jam messages Error code Description Action...
Page 95: Sensor (Input): Paper (Duplex Job) Failed To Arrive Jam Service Check
Diagnostics and troubleshooting Error code Description Action 232.93 Paper fed from an unknown tray was detected later than expected or was never detected at the sensor (input) during a duplex print job. 232.95 Paper fed from an unknown tray never cleared the sensor (input) during a duplex print job.
Page 96 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the duplex guide for proper installation. Is the duplex guide properly installed? ◦ Yes: Go to step 8. ◦ Go to the next step. Reseat the duplex guide, and then make sure that it is properly closed.
Page 97: 242 Paper Jams
Diagnostics and troubleshooting Perform the following tests: Remove the right cover. See .Right cover removal on page 220 Make sure that the JMTR1 sensor cable is properly connected to the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦...
Page 98: 280-295 Paper Jams
Diagnostics and troubleshooting Error code Description Action 242.86 Paper jam caused by the motor (tray 2) running too long. 280–295 paper jams 280–295 paper jam messages Error code Description Action 280.11 Paper remains detected at .ADF jam service the sensor (ADF scan) after check on page 98 the printer is turned on.
Page 99 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Open the ADF cover, and then check if it closes properly. Check the cover for improper installation. Is the ADF cover functional and properly installed? ◦ Yes: Go to step 5. ◦...
Page 100 Diagnostics and troubleshooting Remove and install, clean, or replace the ADF separator pad. See ADF separator pad removal on page 278. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics >...
Page 101 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 16. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Motor tests Select Scanner, and then start the test. Does the motor run? ◦...
Page 102: User Attendance Messages
Diagnostics and troubleshooting The problem is solved. Make sure that the controller board is properly installed. Reseat all the cables on the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the controller board and its connector pins for damage.
Page 103 Diagnostics and troubleshooting Error code Description Action 32.40B The toner cartridge is unsupported. 32.40C The toner cartridge is unsupported. 32.40D The toner cartridge is unsupported. Note: • A toner cartridge that ships with the printer or equipment (SWE) cannot be switched with another SWE toner cartridge.
Page 104 32.60E The imaging unit is unsupported. 32.60F The imaging unit is unsupported. 33.40 A non-Lexmark black toner Unsupported or cartridge was detected. unresponsive toner cartridge service check on page 106.
Page 105 Diagnostics and troubleshooting Error code Description Action 33.60 A non-Lexmark black Install a genuine and imaging unit was detected. supported Lexmark black imaging unit. 41.60 The imaging unit and toner Mismatched supplies cartridge are mismatched or error service check on page incompatible.
Page 106: Unsupported Or Unresponsive Toner Cartridge Service Check
Unsupported or unresponsive toner cartridge service check Check whether the toner cartridge installed is genuine. Is the cartridge a genuine and supported Lexmark unit? ◦ Yes: Go to step 3. ◦ Go to the next step.
Page 107: Unsupported Or Unresponsive Imaging Unit Service Check
Contact the next level of support. ◦ The problem is solved. Unsupported or unresponsive imaging unit service check Check whether the imaging unit installed is genuine and supported by the printer model. Is the imaging unit a genuine and supported Lexmark unit?
Page 108 Diagnostics and troubleshooting ◦ Yes: Go to step 3. ◦ Go to the next step. Install a genuine and supported Lexmark imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Check the imaging unit contacts for contamination.
Page 109: Mismatched Supplies Error Service Check
Contact the next level of support. ◦ The problem is solved. Mismatched supplies error service check Check whether the supplies installed are genuine and supported by the printer model. Are the supplies genuine and supported Lexmark units? ◦ Yes: Go to step 3. ◦...
Page 110: Fax Station Error Service Check
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform a feed test to check if the printer has paper feed problems. Does the printer have a problem feeding paper during the test? ◦...
Page 111 Diagnostics and troubleshooting The problem is solved. Perform the following tests: From the control panel, navigate to: Settings > Fax > Analog Fax Setup > General Fax Settings Set the fax name and fax number. Does the problem remain? ◦ Yes: Go to the next step.
Page 112: Fax Failure Service Check
Diagnostics and troubleshooting ◦ The problem is solved. Fax failure service check Turn off the printer, wait for about 10 seconds, and then turn on the printer. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the telephone cable is properly connected to the line port of the printer.
Page 113: Printer Hardware Errors
Diagnostics and troubleshooting ◦ The problem is solved. Make sure that the controller board is properly installed. Reseat all the cables on the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the controller board and its connector pins for damage.
Page 114: Printhead Service Check
Diagnostics and troubleshooting Error code Description Action 111.32 Printhead error (lost HSYNC) was detected. 111.33 Printhead error (lost HSYNC) was detected during servo. 111.34 Printhead error (mirror motor lost lock) was detected. 111.35 Printhead error (mirror motor never got first lock) was detected.
Page 115: 121 Errors
Diagnostics and troubleshooting Go to step 4. ◦ Go to the next step. Replace the printhead. See .Printhead removal on page 265 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform a POR. Does the problem remain? ◦...
Page 116 Diagnostics and troubleshooting Error code Description Action 121.05 During an attempt to heat up, the fuser relay was open and the micro‑controller was reporting an error. 121.10 Fuser did not reach the required temperature during the start of EWC/line voltage detection. 121.11 Fuser reached the required temperature too late during...
Page 117: Fuser Service Check
Go to the next step. ◦ The problem is solved. Check whether the fuser installed is genuine and supported by the printer model. Is the fuser a genuine and supported Lexmark unit? ◦ Yes: Go to the next step. ◦...
Page 118 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 6. Replace the fuser. See .Fuser removal on page 264 Note: Make sure that the new fuser is supported by the printer model. Does the problem remain? ◦...
Page 119: 126 Errors
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the fuser. See .Fuser removal on page 264 Does the problem remain? ◦ Yes: Contact the next level of support. ◦...
Page 120 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Make sure that the voltage output of the electrical outlet matches the voltage rating of the printer. Does the problem remain? ◦...
Page 121: 140 Errors
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. 140 errors 140 error messages Error code Description Action 140.80 Motor (main drive) does not Motor (main drive) turn on. service check on page 121.
Page 122: 162 Errors
Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Make sure that the JMTR1 cable is properly connected to the controller board. Is the cable properly connected to the controller board? ◦ Yes: Go to step 5. ◦...
Page 123: Optional Tray Pick Drive Failure Service Check
Diagnostics and troubleshooting Error code Description Action 162.85 The motor (tray 2 pick) ran too fast. 162.86 The motor (tray 2 pick) ran too long. Optional tray pick drive failure service check Check if the optional tray motor (pick) runs. Does the motor run? ◦...
Page 124: 6Yy Errors
Diagnostics and troubleshooting Remove the tray insert from the optional tray. Check if the lift plate moves properly. Check the lift plate gears for damage. Is the tray insert functional and free of damage? ◦ Yes: Contact the next level of support. ◦...
Page 125 Diagnostics and troubleshooting Error code Description Action 600.11 Packing material was Remove the imaging unit detected by the sensor and toner cartridge, and (toner density). then make sure that all packing material are properly removed. 600.95 RIP intentionally declared a Resend the print job.
Page 126: Fuser Overheated Service Check
Diagnostics and troubleshooting Error code Description Action 662.80 Jam detection caused by motor (tray 2) not turning 662.81 Jam detection caused by motor (tray 2) not turning off. 662.82 Jam detection caused by motor (tray 2) speed not ramping up to the required level.
Page 127: Adf Failure Service Check
Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. ADF failure service check Perform the following tests: Check the ADF paper path for paper fragments, partially fed paper, and obstructions. ◦ Under the ADF cover ◦...
Page 128 Diagnostics and troubleshooting ◦ Go to step 9. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Sensor tests Run the test on the following sensors: ▪ ADF paper present ▪ ADF scan Does the sensor status change while toggling the sensors? ◦...
Page 129: Scanner Communication Error Service Check
Diagnostics and troubleshooting Make sure that the controller board is properly installed. Reseat all the cables on the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the controller board and its connector pins for damage. Are the controller board and its connectors free of damage? ◦...
Page 130: 84Y Errors
Diagnostics and troubleshooting The problem is solved. Replace the ADF and scanner. See .ADF and scanner removal on page 279 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the controller board. See .Controller board removal on page 222 Does the problem remain? ◦...
Page 131: Scanner Communication Failure Service Check
Diagnostics and troubleshooting Error code Description Action 845.03 A back side scan error Duplex scan error occurred. service check on page 136. Scanner communication failure service check Perform the following tests: Check the ADF paper path for paper fragments, partially fed paper, and obstructions. ◦...
Page 132 Diagnostics and troubleshooting Settings > Device > Maintenance > Configuration Menu > Scanner Configuration > Disable Scanner Select Enable. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics >...
Page 133 Diagnostics and troubleshooting Is the sensor free of damage? ◦ Yes: Go to the next step. ◦ Go to step 13. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Motor tests Select Scanner, and then start the test. Does the motor run? ◦...
Page 134: Scanner Noise Service Check
Diagnostics and troubleshooting Make sure that the controller board is properly installed. Reseat all the cables on the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the controller board and its connector pins for damage. Are the controller board and its connectors free of damage? ◦...
Page 135 Diagnostics and troubleshooting Perform the following tests: Check the scanner and its components for damage. ◦ Scanner lamp ◦ Motor (scanner) ◦ Scanner belt ◦ Glass panes ◦ Cables Are the scanner and its components free of damage? ◦ Yes: Go to step 5.
Page 136: Duplex Scan Error Service Check
Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Duplex scan error service check Perform the following tests: Check the ADF paper path for paper fragments, partially fed paper, and obstructions. ◦ Under the ADF cover ◦...
Page 137 Diagnostics and troubleshooting ◦ Go to step 7. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Sensor tests Run the test on the following sensors: ▪ ADF paper present ▪ ADF scan Does the sensor status change while toggling the sensors? ◦...
Page 138: Procedure Before Starting The 9Yy Service Checks
Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the ADF and scanner. See .ADF and scanner removal on page 279 Does the problem remain? ◦ Yes: Contact the next level of support. ◦...
Page 139: Collecting The Firmware Logs (Fwdebug And Logs.tar.gz) From The Se Menu
Diagnostics and troubleshooting Email the text file to your next level of support. B. Collecting the firmware logs (Fwdebug and logs.tar.gz) from the SE menu Note: • Make sure that your printer is connected to a network or to a print server. •...
Page 140: Collecting Information From The User
Diagnostics and troubleshooting Printing the Menu Settings Page From the home screen, navigate to: Reports > Menu Settings Page Print the Menu Settings Page, and then email a scanned copy of the page to your next level of support. D. Collecting information from the user Ask the user for information about the following: •...
Page 141 Diagnostics and troubleshooting See the error code and its service instructions in the printer Service Manual. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Turn off the printer. At the rear of the printer, disconnect the network cable, USB cable, and fax line.
Page 142 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 10. Perform the following tests: Start the printer in Invalid engine mode. See .Entering Invalid engine mode on page Check if an Invalid Engine Code message appears. Does an Invalid Engine Code message appear? ◦...
Page 143 Diagnostics and troubleshooting Is a hard disk installed? ◦ Yes: Go to the next step. ◦ Go to step 17. Perform the following tests: Check for buffered print jobs, and then delete them. Perform a POR. Does the problem remain? ◦...
Page 144 Diagnostics and troubleshooting Remove all the installed components. Turn on the printer. Does the problem remain? ◦ Yes: Go to step 21. ◦ Go to the next step. Perform the following tests: Turn off the printer. Install the following components one at a time: ▪...
Page 145: 912 Errors
Diagnostics and troubleshooting 912 errors 912 error messages Error code Description Action 912.01 An engine error occurred. Resend the print job. If the problem remains, then 912.02 An engine error occurred. contact the next level of support. 912.04 An engine error occurred. 912.05 An engine error occurred.
Page 146 Diagnostics and troubleshooting Error code Description Action 912.35 An engine error occurred. 912.36 An engine error occurred. 912.38 An engine error occurred. Optional tray communication error service check on page 147. 912.39 An engine error occurred. Resend the print job. If the problem remains, then 912.40 An engine error occurred.
Page 147: Optional Tray Communication Error Service Check
Diagnostics and troubleshooting Error code Description Action 912.72 An engine error occurred. 912.73 An engine error occurred. 912.74 An engine error occurred. 912.75 An engine error occurred. 912.77 An engine error occurred. 912.86 An engine error occurred. Optional tray communication error service check Check the paper path and trays for paper fragments and partially fed paper.
Page 148: 938-992 Errors
Diagnostics and troubleshooting Remove the optional tray. Make sure that the interconnect cable of the tray is properly installed. Check the interconnect cable and its connector pins for damage. Make sure that the tray controller board is properly installed. Reseat all the cables on the tray controller board. Check the optional tray controller board and its connector pins for damage.
Page 149: Nvram Mismatch Failure Service Check
Diagnostics and troubleshooting Error code Description Action 980.03 980.04 980.05 980.11 980.13 980.14 980.15 981.91 An invalid paper port protocol error occurred. 982.92 A paper port error occurred. 982.93 982.94 982.95 982.96 982.97 983.98 An unsupported paper port command error occurred. 984.99 An invalid paper port parameter error occurred.
Page 150 Diagnostics and troubleshooting Warning—Potential Damage Do not perform a Power‑On Reset (POR) until the problem is resolved. If a POR is performed at this point, then the replacement part can no longer be used in another printer and must be returned to the manufacturer. Enter the Diagnostics menu. The Diagnostics menu allows you to use temporarily the replacement part.
Page 151: Other Symptoms
Diagnostics and troubleshooting Check if the controller board was recently replaced. Was the controller board recently replaced? ◦ Yes: Go to the next step. ◦ Contact the next level of support. Replace the current controller board with the original controller board. See .Controller board removal on page 222 Does the problem remain?
Page 152: Tray Near Empty Service Check
Diagnostics and troubleshooting Tray near empty service check Check the actuator in the tray insert for damage. Is the actuator free of damage? ◦ Yes: Go to step 3. ◦ Go to step 2. Replace the tray insert. Does the problem remain? ◦ Yes: Go to step 3. ◦...
Page 153: False Bin Full Error Service Check
Diagnostics and troubleshooting ◦ The problem is solved. Perform a POR. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. False bin full error service check Remove, and then install the bin full sensor actuator. See .Bin full sensor actuator removal on page 268 Does the problem remain?
Page 154: Fax Error Log Codes
Diagnostics and troubleshooting Symptom Action The printer does not transmit faxes. Fax transmission service check on page 163. The printer does not receive faxes. Fax reception service check on page 166. Cannot set up etherFAX. Cannot set up etherFAX on page 161.
Page 155 Diagnostics and troubleshooting Error code Description Action Error occurred when • Check line quality. receiving a frame. • Adjust ‘Receive Threshold’. Error occurred when • Check line quality. sending a frame. • Adjust ‘Transmit Level’. • Select a lower ‘Max Speed’ value under Fax Send settings. Received EOT If error persists, then unexpectedly from the disable V34 modulation...
Page 156 Diagnostics and troubleshooting Error code Description Action T5 Timeout occurred when • Check line quality. transmitting image data to • Adjust ‘Transmit remote fax device. Level’. • Select a lower ‘Max Speed’ value under Fax Send settings. Too many errors when • Check line quality. transmitting in ECM mode. •...
Page 157 Diagnostics and troubleshooting Error code Description Action Timeout occurred after Adjust “Receive Threshold”. waiting too long to receive a good frame. Tried too many times at • Adjust ‘Transmit selected speed using V34 Level’. modulation scheme. • Adjust to a lower modulation scheme. Fax transmission was Troubleshoot MFP if error interrupted due to power...
Page 158 Diagnostics and troubleshooting Error code Description Action Failure to transmit training • Select a lower “Max successfully in V17, V27 Speed” under Fax terminal modulation Send settings. schemes. • Adjust the “Transmit Level”. • Check line quality. Failure to transmit training • Select a lower “Max successfully in V29, V27 Speed” under Fax ...
Page 159 Diagnostics and troubleshooting Error code Description Action Failed to connect using • Check line quality. V.34 modulation scheme. • Adjust to a lower modulation scheme. • Adjust Transmit Level Receive Threshold values. No fax tones detected from • Verify destination remote end.
Page 160: Modem/Fax Card Service Check
Diagnostics and troubleshooting Error code Description Action Received request for No action needed. unsupported image resolution from remote fax device. Received request for No action needed. unsupported compression type from remote fax device. Received request for No action needed. unsupported image length from remote fax device.
Page 161: Cannot Set Up Etherfax
Diagnostics and troubleshooting Make sure that the modem cable is properly connected to the modem card and to the JFAX2 connector on the controller board. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the fax card.
Page 162: Cannot Send Or Receive Faxes Using Etherfax
◦ Yes: The problem is solved. ◦ Go to https://www.etherfax.net/lexmark. Cannot send or receive faxes using etherFAX Make sure that the printer is connected to a network and that the network is connected to the Internet. Can you send or receive faxes using etherFAX? ◦...
Page 163: Fax Transmission Service Check
Diagnostics and troubleshooting The problem is solved. ◦ Go to https://www.etherfax.net/lexmark. Fax transmission service check Note: These instructions apply only to printers that support analog fax. For more information, see .conkeyref: keys/supported-fax Reseat the telephone cable on the LINE port of the printer and on the wall jack.
Page 164 Diagnostics and troubleshooting Perform the following tests: From the home screen, navigate to Settings > Fax > Analog Fax Setup > Fax Receive Settings > Admin Controls > Enable Fax Receive. Select On. Does the problem remain? ◦ Yes: Go to the next step. ◦...
Page 165 Diagnostics and troubleshooting ◦ Go to the next step. Check if a different device can send a fax. Can the device send a fax? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Perform the following tests: From the home screen, navigate to Settings >...
Page 166: Fax Reception Service Check
Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Service Engineer menu, and then navigate to: Fax SE > Fax Settings > AutoPrint T30 Logs Check the reported error code.
Page 167 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check if the telephone line is analog. Is the telephone line analog? ◦ Yes: Go to step 7. ◦ Go to the next step. Check if the telephone line is a VOIP line.
Page 168 Diagnostics and troubleshooting From the home screen, navigate to Settings > Fax > Analog Fax Setup > Fax Send Settings > Behind a PABX. Select No. Check if access to an outside line needs a dial prefix. Does access to an outside line need a dial prefix? ◦...
Page 169 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Contact the next level of support. Perform the following tests: Open a web browser and then type https://<IP address>/se. Navigate to: Fax > Settings > Silabs Configuration Adjust the Transmit Level setting (A) in steps of ±1 dB. Does the problem remain? ◦...
Page 170: Lost Connection To Https Fax Server When Using Etherfax Service Check
Diagnostics and troubleshooting Lost connection to HTTPS fax server when using etherFAX service check Perform the following tests: Enter the Service Engineer (SE) menu, and then navigate to: Fax SE Menu > Fax Settings Make sure that the Fax Transport option is set to etherFAX. Does the problem remain? ◦...
Page 171 Diagnostics and troubleshooting ◦ No: The problem is solved.
Page 172: Service Menus
Service menus Service menus Understanding the printer control panel Using the control panel Control panel part Function Power button • Turn on or turn off the printer. Note: To turn off printer, press and hold the power button for five seconds.
Page 173: Understanding The Status Of The Indicator Light
Service menus Control panel part Function Display • View the printer messages and supply status. • Set up and operate the printer. Indicator light Check the status of the printer. Understanding the status of the indicator light Indicator light Printer status The printer is off.
Page 174: Installed Licenses
Service menus Installed Licenses This setting lists all the installed licenses and their feature data. Enter the Diagnostics menu, and then navigate to: Reports > Licenses > Installed Licenses Advanced Print Quality Samples This setting prints the Print Quality Test Pages. Enter the Diagnostics menu, and then navigate to: Advanced Print Quality Samples >...
Page 175: Print Log Summary
Service menus Print Log Summary This setting lists a brief summary of the various printer events. Enter the Diagnostics menu, and then navigate to: Event Log > Print Log Summary > Start. Note: Depending on the operational history of the printer, the events that appear in the report vary.
Page 176: Motor Tests
Service menus List of sensor tests MPF media present Tray1 present Input Output bin/Narrow media Fuser exit Front door interlock Motor tests Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests Select a motor. Note: •...
Page 177: Margin Offset
Service menus For non-touch-screen printer models, press to navigate through the settings. Enter the Diagnostics menu, and then navigate to: Printer diagnostics and adjustments > Registration adjust Select a setting. Margin Offset This setting allows you to adjust the margin offset and to print or reset the default settings. For non-touch-screen printer models, press to navigate through the settings.
Page 178: Enable Edge-To-Edge (Printing)
Service menus Enable edge‑to‑edge (printing) This setting allows print jobs to include the edges of the page. Enter the Diagnostics menu, and then navigate to: Printer Setup > Enable edge‑to‑edge (printing) Select a setting. Enable edge‑to‑edge (copy) This setting allows copy jobs to include the edges of the page. Enter the Diagnostics menu, and then navigate to: Printer Setup >...
Page 179: Engine Setting [X]
Service menus Engine setting [x] Warning—Potential Damage Do not change this setting without specific instructions from the next level of support. This setting allows you to select a printer engine setting. Possible values are 0–255. 0 is the default. For non‑touch‑screen printer models, press to navigate through the settings. Enter the Diagnostics menu, and then navigate to: Printer Setup > Engine setting [x] Select a setting, and then enter a value.
Page 180: Sensor Test
Service menus Scanner Diagnostics > Motor Tests Select a motor. Note: • If the motor is activated, then it is properly working. • Some motors require automatic deactivation to avoid secondary issues such as possible damage and contamination. • Some tests require a special action to activate a motor such as removing a major component.
Page 181: Feed Test
Service menus Feed Test This test allows for a continuous feed from the ADF or flatbed scanner. Enter the Diagnostics menu, and then navigate to: Scanner Diagnostics > Feed Test Note: Set the paper size to match the paper loaded in the ADF tray if necessary. Touch Feed Test.
Page 182: Configuration Menu
Service menus Configuration Menu Entering the Configuration Menu From the control panel, navigate to: Settings > Device > Maintenance > Configuration Menu Configuration Menu Menu item Description USB Configuration Change the USB driver mode of the printer to improve its compatibility with a personal USB PnP computer.
Page 183 Service menus Menu item Description Tray Configuration Set the paper source that the user fills when a prompt to load paper appears. Paper Prompts Auto* Note: For Multipurpose Feeder to Multipurpose Feeder appear, in the Paper menu, set Manual Paper Configure MP to Cassette.
Page 184 Service menus Menu item Description Printer Emulations Set the printer to recognize and use the PS data stream. PS Emulation Printer Emulations Activate Formsmerge to store the forms into the intelligent storage drive (ISD). Enable Formsmerge Off* Note: The printer must have an ISD installed.
Page 185 Service menus Menu item Description Fax Configuration Set the storage location for all faxes. Fax Storage Location Note: This menu item appears only NAND when an ISD is installed. Disk* Print Configuration Set a text point-size value below which the high‑frequency screens are used when ...
Page 186 Enable the printer to use the orientation setting under the Copy menu when sending Honor orientation on fast path copy quick copy jobs. Off* App Configuration Enable Lexmark Embedded Solutions (LES) applications. LES Applications Scanner Configuration Print a Quick Test target page. Scanner Manual Registration...
Page 187: Entering Invalid Engine Mode
Service menus Menu item Description Scanner Configuration Set the size, in millimeters, of the no‑print area around an ADF or flatbed scan job. Edge Erase Flatbed Edge Erase (3*) ADF Edge Erase (3*) Scanner Configuration Disable the scanner when it is not working properly. Disable Scanner ADF Only Scanner Configuration Set the byte order of a TIFF‑formatted scan ...
Page 188: Entering Recovery Mode
Service menus Touch ‑> to navigate the menu that appears on the display, and then select ENGINE_FLASH. Note: The selected menu turns green. Touch Boot. Entering Recovery mode This mode allows the printer to boot from a secondary set of instructions and flash firmware code.
Page 189: For 2-Line Display
Service menus Press and hold the Stop button. Turn on the printer. When all the icons flash, release the button. For 2‑line display Turn off the printer. Press and hold the OK and Back buttons. Turn on the printer. When the display shows the following icon, release the buttons. For 2.4-, 4.3-, 7-, and 10-inch displays with number pads Turn off the printer.
Page 190: For 2.8-, 4.3-, 7-, And 10-Inch Displays Without Number Pads
Service menus For 2.8‑, 4.3‑, 7‑, and 10‑inch displays without number pads Turn off the printer. Open tray 1. Note: Make sure that paper is loaded in the tray. Turn on the printer. When the display shows either of the following icons, close tray 1. For 2.8-inch display: For 4.3-, 7-, and 10-inch displays: Note: If tray 1 is not closed, then the printer boots normally.
Page 191: Se Menu
Service menus SE menu Entering the SE menu From the home screen, touch Touch **411, and then touch OK. Network SE Menu Enter the SE menu, and then select Network SE Menu. Note: Use these settings as directed by the next level of support. Top‑level menu Intermediate menu HISTORY...
Page 192: Scanner Se Menu
Service menus Top‑level menu Intermediate menu Other Actions • ifconfig • IPtables [Firewall Dump] • IP6tables [Firewall Dump] • IPsec Dump Enable DHCPCD Debugging Enable wpa‑supplicant Debugging Enable Ethernet Gigabit Enable Dual NIC Enable BLE Netconfig Debug Level IPP Cons • Delete intermediate icons •...
Page 193 Service menus Note: • Use these settings as directed by the next level of support. • For printers with firmware version FW7.1 and up, adjust the Transmit Level setting via EWS SE. See EWS SE Menu on page 195. Top‑level menu Intermediate menu Agency Test Menu •...
Page 194 Service menus Top‑level menu Intermediate menu Modem Settings • Adjust Power FSK • ARA EQM Bias • Busy Tone Cycles • Busy Tone Max Off Time • Busy Tone Max On Time • Busy Tone Min Off Time • Busy Tone Min On Time •...
Page 195: Ews Se Menu
Service menus Top‑level menu Intermediate menu Fax logs • Print all T30 Logs • Print CallerID Log • Print Call Log • Print Fax Settings • Print Job Log • Print All T30 Error Logs • Print T30 Log • Print T38 Trace Log •...
Page 196: Parts Removal
Parts removal Parts removal Erasing printer memory To erase volatile memory or buffered data in your printer, turn off the printer. To erase nonvolatile memory, device and network settings, security settings, and embedded solutions, perform an Out of Service Erase (OOSE). Note: This process also destroys the encryption key that is used to protect user data.
Page 197: Important Removal Information
Parts removal Note: • The intelligent storage drive (ISD) is cryptographically erased. • The process to sanitize the ISD can take from several minutes to more than an hour, making the printer unavailable for other tasks. Important removal information Removal precautions CAUTION—SHOCK HAZARD The low-voltage power supply (LVPS) and the high-voltage power supply (HVPS) may have residual voltage present.
Page 198: Précautions De Retrait
Parts removal Précautions de retrait CAUTION—SHOCK HAZARD Une tension résiduelle peut être présente dans le bloc d'alimentation basse tension (LVPS) et le bloc d'alimentation haute tension (HVPS). Pour éviter tout risque d'électrocution, ne touchez pas les composants du circuit ou le côté...
Page 199: Vorsichtsmaßnahmen Bei Der Demontage
Parts removal CAUTION—SHOCK HAZARD Este producto utiliza un interruptor de corriente electrónico. No desconecta físicamente la entrada de voltaje de CA. Para evitar el riesgo de descarga eléctrica, desenchufe siempre el cable de alimentación de la impresora cuando sea necesario retirar la entrada de voltaje de CA. CAUTION—SHOCK HAZARD Para evitar el riesgo de descargas eléctricas y daños en la impresora, retire el cable de alimentación de la toma eléctrica y desconecte todas las...
Page 200: Handling Esd-Sensitive Parts
Parts removal CAUTION—SHOCK HAZARD Um das Risiko eines elektrischen Schlags und Schäden am Drucker zu vermeiden, ziehen Sie das Netzkabel aus der Steckdose und trennen Sie alle Verbindungen zu jeglichen externen Geräten, bevor Sie Kabel, Elektronikplatinen oder Baugruppen einstecken oder abziehen. CAUTION—HOT SURFACE Das Innere des Druckers kann sehr heiß...
Page 201: Critical Information For Controller Board Or Control Panel Replacement
Parts removal Critical information for controller board or control panel replacement CAUTION—POTENTIAL INJURY The lithium battery in this product is not intended to be replaced. There is a danger of explosion if a lithium battery is incorrectly replaced. Do not recharge, disassemble, or incinerate a lithium battery. Discard used lithium batteries according to the manufacturer's instructions and local regulations.
Page 202: Updating The Printer Firmware
Parts removal Warning—Potential Damage To avoid damaging the part or experiencing NVRAM mismatch issues, replace only one of the following components at a time: • Control panel • Controller board To replace a component and to test whether the problem is resolved: Replace the affected component.
Page 203: Using A Flash Drive
Parts removal Using a flash drive Note: The printer must be in ready state to update the firmware. Insert the flash drive into the front USB port. Do any of the following: ◦ From the control panel, navigate to USB Menu: Print from USB > Accept or OK, and then select the file that you need to flash.
Page 204: Ribbon Cable Connectors
Parts removal Go to support.lexmark.com, and then download USB Flash Utility. Extract, and then run the utility. Click Browse Files, and then browse to the firmware file directory. Select the firmware file. Select the source printer. Click Start. Using USButil Go to support.lexmark.com, and then download USButil.
Page 205 Parts removal 2. Insert the cable. Note: Make sure that the cable is installed straight into the connector to avoid intermittent failures.
Page 206: Adjustments
Parts removal Adjustments Adjusting the fax volume Enter the SE menu on the EWS page by navigating to the following address: http://<printer’s IP address>/se. From the menu options, click Fax. Under Settings, click Conexant Configuration. Change the volume level based on the following values: ◦...
Page 207 Parts removal 2. Open the front door, and then release the left front door link (B).
Page 208 Parts removal Place the printer on its right side. Release the two latches (C) at the bottom of the left cover, and then remove the cover.
Page 209: Main Drive Gears Removal
Parts removal Main drive gears removal Remove the left cover. See Left cover removal on page 206. Place the printer on its right side. Warning—Potential Damage If the printer is not placed on its right side, then the gears fall out of place when the gear plates are removed.
Page 210 Parts removal 4. Remove the gears.
Page 211 Parts removal Installation Note ◦ Pay attention to the position of the gears. ◦ Most gears have a molded letter for identification. ◦ Note the letter or number on the gears, and then use the following illustration to match their proper location and position in the printer. ◦...
Page 212 Parts removal Remove the left front door link. See Left front door link removal on page 218. Remove the two screws (A), and then remove the coupling (B).
Page 213 Parts removal 7. Place the printer on its left side, remove the screw (C), and then remove the duplex swing arm assembly (D).
Page 214 Parts removal Installation Note Make sure that the gears assembly is properly installed in the housing. Align the tab on the housing to the notch in the frame, and then install the duplex swing arm assembly.
Page 215: Imaging Unit Coupling Removal
Parts removal Imaging unit coupling removal Remove the left cover. See . Remove the left front door link. See . Remove the two screws (A), and then remove the imaging unit coupling (B).
Page 216: Pick Roller Clutch Removal
Parts removal Pick roller clutch removal Remove the left cover. See Left cover removal on page 206. Remove the wire from the cable guide (A), remove the six screws, and then remove the gear cover.
Page 217 Parts removal Remove the three gears. Installation Note Pay attention to the position of the gears. Remove the clutch (A), and then disconnect the cable (B).
Page 218: Left Front Door Link Removal
Parts removal Left front door link removal Remove the left cover. See Left cover removal on page 206. Remove the wire from the cable guide (A), remove the six screws, and then remove the gear cover.
Page 219 Parts removal Remove the gear. Release the left front door link (A) from the retainer (B), and then remove the left front door link.
Page 220: Right Side Removals
Parts removal Right side removals Right cover removal Remove the two screws (A) at the front and the rear of the right cover.
Page 221 Parts removal...
Page 222: Controller Board Removal
Parts removal Open the front door, and then place the printer on its left side. Release the three latches at the bottom, and then pry the sides of the cover. Remove the right cover. Controller board removal For a video demonstration, see Controller board removal.
Page 223: Lvps Removal
Parts removal Remove the wireless network card. See Wireless network card removal on page 235. Disconnect all the cables from the controller board, and then remove the six screws. Remove the ground clip, and then remove the controller board. LVPS removal Remove the right cover.
Page 224 Parts removal 2. Disconnect the two cables (A), remove the six screws (B), and then remove the LVPS. CAUTION—SHOCK HAZARD To avoid the risk of electrical shock, do not remove the shield from the back of the LVPS. CAUTION—SHOCK HAZARD Pour éviter tout risque d'électrocution, ne retirez pas la protection de l'arrière du bloc d'alimentation basse tension (LVPS).
Page 225: Hvps Removal
Parts removal HVPS removal Note: For a video demonstration, see HVPS removal. Remove the right cover. SeeRight cover removal on page 220. Remove the rear door. See Rear door removal on page 263. Place the printer on its left side. Remove the three screws (A), remove the right paper tray guide assembly, and then ...
Page 226 Parts removal...
Page 227: Sensor (Mpf Paper Present) Removal
Parts removal Remove the plastic shield (C). Installation Note Make sure to properly attach the plastic shield. Remove the two screws (D). Separate the HVPS (E) from the right paper tray guide (F). Sensor (MPF paper present) removal Note: For a video demonstration, see Sensor (MPF paper present) removal.
Page 228: Right Front Door Link Removal
Parts removal Right front door link removal Remove the right cover. See Right cover removal on page 220. Remove the screw, and then remove the link from the front door.
Page 229 Parts removal...
Page 230: Mpf Solenoid Cable Removal
Parts removal Installation Note Use a manual screwdriver when attaching the right door link. It is easy to over-torque the screw with an electric screwdriver, breaking the retraction mechanism of the smart chip contacts. MPF solenoid cable removal Note: For a video demonstration, see MPF solenoid cable removal.
Page 231: Main Fan Removal
Parts removal Main fan removal Note: For a video demonstration, see Main fan removal.
Page 232 Parts removal Remove the left cover. See . Remove the right cover. See .Right cover removal on page 220 Remove the ADF and scanner. See .ADF and scanner removal on page 279 Disconnect the cable, and then remove the screw to remove the fan.
Page 233 Parts removal...
Page 234: Speaker Removal
Parts removal Speaker removal Remove the ADF and scanner. See ADF and scanner removal on page 279. Remove the two screws (A), and then remove the cable (B). Remove the speaker. Interlock switch removal Remove the right cover. See .Right cover removal on page 220 Remove the screw (A), and then disconnect the connector (B).
Page 235: Wireless Network Card Removal
Parts removal Remove the switch. Wireless network card removal Remove the ADF and scanner. See ADF and scanner removal on page 279. Lift the tab (A) to release the wireless network card.
Page 236: Tpm Card Removal
Parts removal TPM card removal Remove the right cover. See Right cover removal on page 220. Release the latches, and then remove the card. Warning—Potential Damage To avoid electrical damage, make sure that the printer is unplugged.
Page 237 Parts removal Installation Note Make sure that the connector is plugged.
Page 238: Isd Card Removal
Parts removal ISD card removal Open the controller board access door.
Page 239 Parts removal 2. Release the latches, and then remove the card. Warning—Potential Damage To avoid electrical damage, make sure that the printer is unplugged.
Page 240 Parts removal Installation Note Make sure that the connector is plugged.
Page 241: Front Side Removals
Parts removal Front side removals Control panel removal Note: For a video demonstration, see Control panel removal. Open the ADF, and then remove the two screws (A).
Page 242 Parts removal 2. Pry the control panel, and then remove the cable.
Page 243: Control Panel Back Plate Removal
Parts removal Remove the control panel. Control panel back plate removal Note: For a video demonstration, see Front‑side removals. Remove the control panel. See Control panel removal on page 241. Remove the four screws (A).
Page 244: Control Panel Right Support Removal
Parts removal Remove the control panel back plate. Control panel right support removal Note: For a video demonstration, see Front‑side removals. Remove the ADF and scanner. See ADF and scanner removal on page 279. Remove the control panel. See Control panel removal on page 241.
Page 245 Parts removal 4. Remove the two screws (B).
Page 246: Control Panel Left Support Removal
Parts removal Remove the control panel right support. Control panel left support removal Note: For a video demonstration, see Front‑side removals. Remove the control panel right support. See Control panel right support removal on page 244. Remove the front USB. See Front USB removal on page 250.
Page 247: Control Panel Cable Removal
Parts removal Remove the control panel left support. Control panel cable removal Note: For a video demonstration, see Front‑side removals. Remove the ADF and scanner. See ADF and scanner removal on page 279. Remove the control panel. See Control panel removal on page 241.
Page 248 Parts removal 4. Remove the two screws (B), and then remove the control panel right support.
Page 249 Parts removal 5. Release the control panel cable (C).
Page 250: Front Usb Removal
Parts removal Front USB removal Note: For a video demonstration, see Front‑side removals. Remove the ADF and scanner. See ADF and scanner removal on page 279. Remove the control panel. See Control panel removal on page 241. Remove the four screws (A), and then remove the control panel back plate. Remove the two screws (B).
Page 251 Parts removal 5. Release the front USB cable (C) to remove the front USB.
Page 252: Headphone Jack Removal
Parts removal Headphone jack removal Note: For a video demonstration, see Front‑side removals. Remove the ADF and scanner. See ADF and scanner removal on page 279. Remove the control panel. See Control panel removal on page 241. Remove the four screws (A), and then remove the control panel back plate. Remove the two screws (B), and then remove the control panel right support.
Page 253 Parts removal Remove the screw (C). Release the headphone jack cable (D) to remove the headphone jack.
Page 254: Upper Front Cover Removal
Parts removal Upper front cover removal Note: For a video demonstration, see Upper front cover removal. Open the front door. Release the two latches.
Page 255: Front Door Removal
Parts removal Remove the cover. Front door removal Note: For a video demonstration, see Front door removal. Remove the right cover. See .Right cover removal on page 220 Remove the right front door link. See .Right front door link removal on page 228 Release the left front door link, and then remove the front door.
Page 256: Transfer Roller Removal
Parts removal Transfer roller removal Open the front door. Release the two latches, and then remove the transfer roller.
Page 257 Parts removal...
Page 258: Mpf Pick Roller Removal
Parts removal Installation Note ◦ Do not touch the foam on the roller. ◦ The shaft has grease. To avoid contaminating the roller, do not touch the shaft. ◦ Make sure that the spring (A) is properly installed on the left side of the roller. MPF pick roller removal Open the front door.
Page 259 Parts removal...
Page 260: Pick Separator Roller Removal
Parts removal Pick separator roller removal Remove the tray insert. Remove the pick separator roller. Sensor (input) removal Open the front door. Remove the imaging unit. Remove the two screws (A), and then remove the roller assembly (B).
Page 261 Parts removal 4. Release the two latches (C), and then remove the paper guide (D).
Page 262 Parts removal 5. Remove the screw (E), and then disconnect the cable (F) from the sensor.
Page 263: Rear Side Removals
Parts removal Rear side removals Rear door removal Remove the left cover. See .Left cover removal on page 206 Remove the screw, and then remove the rear door. Note: Pay attention to the position of the locating feature on the right side before removing the door.
Page 264: Fuser Removal
Parts removal Fuser removal Note: For a video demonstration, see Fuser removal. Remove the right cover. See .Right cover removal on page 220 Disconnect the three cables.
Page 265: Top Side Removals
Parts removal Open the rear door, remove the four screws, and then remove the fuser. Top side removals Printhead removal Remove the right cover. See Right cover removal on page 220. Remove the left cover. See Left cover removal on page 206.
Page 266 Parts removal Remove the ADF and scanner. See ADF and scanner removal on page 279. Disconnect the two cables. Remove the three screws (A), remove the two cables (B) from the toroid (C), and then remove the printhead.
Page 267: Redrive Removal
Parts removal Installation Note When installing the printhead, tighten the screws in the following the order: Redrive removal Remove the right cover. See Right cover removal on page 220. Remove the left cover. See Left cover removal on page 206. Remove the ADF and scanner.
Page 268: Bin Full Sensor Actuator Removal
Parts removal Lift the redrive, and then disconnect the cable from the redrive. Bin full sensor actuator removal Remove the ADF and scanner. See .ADF and scanner removal on page 279 Firmly pull the bin full actuator to the left until it is disengaged from the printer frame.
Page 269 Parts removal 3. Remove the actuator.
Page 270 Parts removal Installation Note Make sure that the actuator is properly positioned as shown. Carefully rotate the actuator upward until it is engaged to the printer frame.
Page 271: Bottom Side Removals
Parts removal Make sure that the actuator is properly installed and freely rotates without binding. Bottom side removals Duplex guide removal Place the printer on its left side. Remove the duplex guide.
Page 272 Parts removal Installation Note Make sure that the duplex guide is properly inserted into the locating features inside the printer.
Page 273: Duplex Shaft Bushing Removal
Parts removal Duplex shaft bushing removal Open the front door.
Page 274 Parts removal Remove the imaging unit. Close the front door.
Page 275 Parts removal Remove the tray. Position the printer on its side. Remove the pick roller assembly.
Page 276 Parts removal 7. Press the tab to remove the duplex shaft bushing.
Page 277: Adf And Scanner Removals
Parts removal ADF and scanner removals ADF cover removal Open the ADF cover. Remove the ADF cover.
Page 278: Adf Tray Removal
Parts removal ADF tray removal Open the ADF cover. Remove the ADF tray. ADF separator pad removal Open the ADF cover. Release the latch to remove the ADF separator pad.
Page 279: Adf And Scanner Removal
Parts removal Installation Note Do not lose the spring under the ADF separator pad. ADF and scanner removal Note: For a video demonstration, see ADF and scanner removal. Remove the left cover. See Left cover removal on page 206. Remove the right cover. See Right cover removal on page 220.
Page 280 Parts removal 6. On the left side of the printer, remove the screw (D).
Page 281 Parts removal Remove the top cover, ADF, and scanner. Perform the ADF scanner calibration after replacing the ADF and scanner. Load the calibration sheet into the ADF tray. Note: Adjust the guides to match the size of the calibration sheet. Enter the Diagnostics menu, and then touch Scanner Diagnostics.
Page 282: Scanner Pivot Arm Removal
Parts removal Scanner pivot arm removal Slightly raise the ADF and scanner assembly. While pulling on the scanner pivot arm latch, completely raise the ADF and scanner assembly to release the latch.
Page 283 Parts removal 3. Remove the two screws, and then remove the scanner pivot arm.
Page 284: Replacing Parts
Parts removal Replacing parts Replacing the imaging unit Open the front door. Warning—Potential Damage To prevent damage from electrostatic discharge, touch any exposed metal frame of the printer before accessing or touching interior areas of the printer.
Page 285 Parts removal Remove the used imaging unit. Twist the blue latch, and then remove the toner cartridge from the used imaging unit.
Page 286 Parts removal 4. Unpack the new imaging unit, and then insert the toner cartridge until it clicks into place. Warning—Potential Damage Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage Do not touch the photoconductor drum.
Page 287: Replacing The Tray
Parts removal Insert the new imaging unit. Close the door. Replacing the tray Remove the used tray.
Page 288: Replacing The Pick Roller Assembly
Parts removal Unpack the new tray. Insert the new tray. Replacing the pick roller assembly Turn off the printer. Unplug the power cord from the electrical outlet, and then from the printer. Open the front door.
Page 289 Parts removal Remove the imaging unit. Close the front door.
Page 290 Parts removal Remove the tray. Position the printer on its side. Remove the used pick roller assembly.
Page 291 Parts removal Unpack the new pick roller assembly. Note: To avoid contamination, make sure that your hands are clean. Insert the new pick roller assembly.
Page 292: Replacing The Tray Separator Roller
Parts removal Place the printer in its original position, and then insert the tray. Open the front door. Insert the imaging unit. Close the front door. Connect the power cord to the printer, and then to the electrical outlet. Turn on the printer. Replacing the tray separator roller Remove the tray, and then remove the used separator roller.
Page 293 Parts removal Unpack the new separator roller. Note: To avoid contamination, make sure that your hands are clean. Insert the new separator roller. Insert the tray.
Page 294: Replacing The Adf Separator Pad
Parts removal Replacing the ADF separator pad Open the ADF cover. Remove the used ADF separator pad.
Page 295 Parts removal Unpack the new ADF separator pad. Insert the new separator pad until it clicks into place.
Page 296 Parts removal...
Page 297 Parts removal 5. Close the ADF cover.
Page 298: Component Locations
Component locations Component locations Printer configuration Control panel Automatic document feeder (ADF) ADF tray ADF bin Standard bin Multipurpose feeder (MPF) Standard 250‑sheet tray Optional 550‑sheet tray...
Page 299: Controller Board Connectors
Component locations Controller board connectors Connector Connects to Pin number Signal JSCANSNS1 Sensor (ADF paper SNS_ADF_DOC present) SNS_ADF_DOC_LED SNS_ADF_SCAN PWR_ADF_SCAN_LED JFBM1 Motor (scanner FBM_BOUT1 fatbed) FBM_BOUT2 FBM_AOUT2 FBM_AOUT1 JADFM1 Motor (ADF ADFM_BOUT1 scanner) ADFM_BOUT2 ADFM_AOUT2 ADFM_AOUT1 JACIS1 Scanner flatbed OS1_AFE analog CIS bar OS2_AFE OS3_AFE...
Page 300 Component locations Connector Connects to Pin number Signal SCAN_LEDB SCAN_LEDG SCAN_LEDR JDCIS1 Scanner ADF digital CIS bar SCAN_RXIN_P(0) SCAN_RXIN_N(0) SCAN_RXCLK_P SCAN_RXCLK_N D_SOL D_AFE_SEN D_AFE_SDIO D_AFE_SCK D_CIS_PCLK +3.3 V_ADF JWIFI1 Wi‑Fi antenna WIFI_ANT USB front port +5 V_FUSB cable USB_N USB_P JVDO1 Printhead video VDO_HSYNC- VDO_K1+...
Page 301 Component locations Connector Connects to Pin number Signal VDO_LPOW_K VDO_LADJ_K1 VDO_BOOST_K +3.3 V_PHRAIL_SW VDO_LEN_K- +3.3 V_PHRAIL_SW VDO_K0+ VDO_K0- VDO_LADJ_K0 JMIR1 Motor (printhead +25 V_SW mirror) MM_START MM_LOCK MM_REFCLK JUICC28 2.8‑in. control panel LED_DRIVE +5 V_CONT MIR_TXD MIR_CS- POWER_BUTTON LCD_RS LCD_TE MIR_RXD MIR_CLK...
Page 302 Component locations Connector Connects to Pin number Signal I2C_DAT I2C_CLK +5 V_UI RESET- IRQ- LCD_WR LCD_RD +5 V_UI +5 V_UI +5 V_UI JSPKR1 Speaker Speaker+ Speaker - JSCHIP1 Toner cartridge and I2C_DAT imaging unit smart +3.3 V_SCHIP chip I2C_CLK...
Page 303 Component locations Connector Connects to Pin number Signal TONER_EMPTY JCVR1 Front door laser +3.3 V_PHRAIL safety switch +3.3 V JMPSNS1 Sensor (MPF paper SNS_MPS present) PWR_MPF JHVPS1 HVPS +25 V_SW DEV_PWM ADC_HV_SERVO XFER_EN TX_PWM CHG_PWM JMTR1 Motor (main drive) +25 V_SW BRAKE +25 V_SW Sensor (toner...
Page 304 Component locations Connector Connects to Pin number Signal CLUTCH_SINK Sensor (input) SNS_INPUT PWR_INPUT JTRAY1 Tray present switch PWR_TRAY TRAY_DETECT JOPT1 Paper handling +25 V_SW option TXD_OPT TRAY_PULLED_N RXD_OPT 5 V_OPT JLVPS1 LVPS RELAY_ON HEAT_ON ZERO_CROSS +25 V_SW_ON +25 V_CONT_RAIL +25 V_SW_RAIL JEXIT1 Sensor (fuser exit) SNS_EXIT...
Page 305 Component locations Connector Connects to Pin number Signal FAN_SINK JBIN1 Sensor (bin full) SNS_BF PWR_BF JSOL1 MPF pick solenoid +25 V_SW SOL_SINK JFAX1 TONE FAX_PWR FAX_PWR MOSI MISO...
Page 306: Maintenance
Damaged, missing, or altered covers, especially in the area of the top cover and power supply cover • Possible safety exposure from any non-Lexmark attachments Use the following table to determine when specified parts must be inspected: Printer parts Every service...
Page 307: Maintenance Kits
Maintenance Printer parts Every service Every 150K Every 360K Notes call Paper path Inspect Inspect Inspect • Check rollers paper fragments. • Check excessive toner build‑up rollers. • Clean with damp cloth if needed. Others Clean Clean Clean Use a toner vacuum and •...
Page 308 Maintenance Contents Page count 41X4467—Maintenance kit, 100K • 41X2599—Fuser, 100 100 V • 41X2575—Separator roller and pick roller • 41x4471—Duplex shaft bushing • 41x2510—ADF cover (includes ADF pick roller) • 41X2511—ADF separator pad 41X4472—Maintenance kit, 100K • 41X2586—Fuser, 115 110 V • 41X2575—Pick separator roller •...
Page 309: Cleaning Printer Parts
Maintenance From the home screen, touch Settings > Device > Maintenance > Configuration Menu > Supply Usage And Counters > Reset Maintenance Counter. Touch Start. Cleaning printer parts Cleaning the printer CAUTION—SHOCK HAZARD To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding.
Page 310: Cleaning The Touch Screen
Maintenance Note: ◦ Do not use household cleaners or detergents, as they may damage the finish of the printer. ◦ Make sure that all areas of the printer are dry after cleaning. Connect the power cord to the electrical outlet, and then turn on the printer. Cleaning the touch screen CAUTION—SHOCK HAZARD To avoid the risk of electrical shock when cleaning the exterior of the...
Page 311: Cleaning The Scanner
Maintenance Connect the power cord to the electrical outlet, and then turn on the printer. Cleaning the scanner Open the scanner cover. Using a damp, soft, lint-free cloth, wipe the following areas: ◦ ADF glass pad ◦ Scanner glass pad...
Page 312 Maintenance ◦ ADF glass ◦ Scanner glass...
Page 313: Cleaning The Pick Roller Assembly
Maintenance Close the scanner cover. Cleaning the pick roller assembly Turn off the printer. Unplug the power cord from the electrical outlet, and then from the printer. Open the front door.
Page 314 Maintenance Remove the imaging unit. Close the front door.
Page 315 Maintenance Remove the tray. Position the printer on its side. Remove the pick roller assembly.
Page 316 Maintenance Apply isopropyl alcohol to a soft, lint-free cloth, and then wipe the pick roller assembly. Insert the pick roller until it clicks into place.
Page 317 Maintenance Place the printer in its original position, and then insert the tray. Open the front door. Insert the imaging unit. Close the front door. Connect the power cord to the printer, and then to the electrical outlet. Turn on the printer.
Page 318: Parts Catalog
Parts catalog Parts catalog Legend The following column headings are used in the parts catalog: • Asm‑index—Identifies the item in the illustration. • Part number—Identifies the unique number that correlates with the part. • Units/mach—Refers to the number of units actually used in the base machine or product. • Units/FRU—Refers to the number of units in a particular FRU. • Description—Describes the part. The following abbreviations are used in the parts catalog: • NS (not shown) in the Asm‑index column indicates that the part is procurable but is not pictured in the illustration. •...
Page 319: Covers
Parts catalog Covers Asm- Units/ Units/ Description Removal procedure index mach 41X2582 Rear door Rear door removal on page 41X4216 Right cover Right cover removal on page Note: This part has a FRU sheet. 41X2584 Front door with MPF pick Front door removal on page roller...
Page 320 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X4218 Upper front cover Upper front cover removal on page 254 Note: This part has a FRU sheet. 41X2578 Left front door link Left front door link removal on page 218 41X2579 Left cover Left cover removal on page...
Page 321: Control Panel
Parts catalog Control panel Asm- Units/ Units/ Description Removal procedure index mach 41X4351 Control panel Control panel removal on page 241 41X4222 Control panel cable Control panel cable removal on page 247 Note: This part has a FRU sheet.
Page 322 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X4220 Control panel right support Control panel right support removal on page 244 Note: This part has a FRU sheet. 41X4219 Control panel left support Control panel left support removal on page 246 Note: This part has a FRU sheet.
Page 323: Electronics
Parts catalog Electronics Asm- Units/ Units/ Description Removal procedure index mach 41X2573 Printhead Printhead removal on page 41X1083 Sensor (input) Sensor (input) removal on page 260 41X4517 Wireless network card Wireless network card removal on page 235...
Page 324 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X4224 Speaker Note: This part has a FRU sheet. 41X4485 Interlock switch Interlock switch removal on page 234 Note: This part has a FRU sheet. 41X4273 Toner cartridge contact 41X4217 Controller board Controller board removal on page 222...
Page 325: Gears
Parts catalog Gears Asm- Units/ Units/ Description Removal procedure index mach 41X2425 Pick roller clutch Pick roller clutch removal on page 216 41X2576 Main drive gears kit Main drive gears removal on page 209 41X4471 Duplex shaft bushing Duplex shaft bushing removal on page 273 Note: This part has a FRU sheet.
Page 326: Paper Path
Parts catalog Paper path Asm- Units/ Units/ Description Removal procedure index mach 41X2575 Separator roller and pick roller Pick separator roller removal on page 260 Note: This part has a CRU sheet. 41X2585 250-sheet tray 41X2599 Fuser, 100 V Fuser removal on page 264 41X2586 Fuser, 115 V Fuser removal on page 264...
Page 327 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X2712 Duplex guide Duplex guide removal on page 271 41X4195 Redrive Redrive removal on page 267 41X4196 Bin full sensor actuator Bin full sensor actuator removal on page 268...
Page 328: 550-Sheet Optional Tray
Parts catalog 550‑sheet optional tray Asm- Units/ Units/ Description Removal procedure index mach 41X2612 550-sheet tray 41X2614 550-sheet tray pick roller 41X2613 550-sheet tray insert...
Page 329: Adf And Scanner
Parts catalog ADF and scanner Asm- Units/ Units/ Description Removal procedure index mach 41X4215 Scanner with fax card ADF and scanner removal on page 279 Note: This part has a FRU sheet. 41X2510 ADF cover ADF cover removal on page...
Page 330 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X2511 ADF separator pad ADF separator pad removal on page 278 Note: This part has a CRU sheet. 41X2428 ADF tray ADF tray removal on page Note: This part has a CRU sheet.
Page 331: Miscellaneous
Parts catalog Miscellaneous Asm- Units/ Units/ Description Removal procedure index mach 41X1872 MarkNet™ N8372 802.11 a/b/ ‑‑ g/n/ac wireless print server Note: This part has a CRU sheet. 40X0288 Power cord, Argentina ‑‑ 40X1767 Power cord, Europe ‑‑ 40X1766 Power cord, Bolivia and Peru ‑‑...
Page 332 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X4473 Maintenance kit, 220 V ‑‑ Note: This part has a FRU sheet. 41X1007 Cleaning kit ‑‑...
Page 333: Printer Specifications
Printer specifications Printer specifications Selecting a location for the printer • Leave enough room to open trays, covers, and doors and to install hardware options. • Set up the printer near an electrical outlet. • Make sure that airflow in the room meets the latest revision of the ASHRAE 62 standard or the CEN Technical Committee 156 standard. •...
Page 334: Power Consumption
Printer specifications Right side 76.2 mm (3 in.) Front 305 mm (12 in.) Note: The minimum space needed in front of the printer is 76 mm (3 in.). Left side 110 mm (4.33 in.) Power consumption Product power consumption The following table documents the power consumption characteristics of the product. Note: Some modes may not apply to your product.
Page 335: Sleep Mode
The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values. Sleep Mode This product is designed with an energy-saving mode called Sleep Mode. The Sleep Mode saves energy by lowering power consumption during extended periods of inactivity.
Page 336: Applicability Of Regulation (Eu) 2019/2015 And (Eu) 2019/2020
One-sided: 53Two-sided: 50 Scanning Copying Ready Values are subject to change. See www.lexmark.com for current values. Temperature information Operating temperature and relative humidity 10 to 32.2°C (50 to 90°F) and 15 to 80% RH 15.6 to 32.2°C (60 to 90°F) and 8 to 80% Maximum wet-bulb temperature : 22.8°C...
Page 337: Theory Of Operation
Theory of operation Theory of operation POR sequence As the printer is turned on, the engine code goes through a series of tests to verify hardware integrity. If a hardware failure is detected, then it is reported to the printer. If the POR sequence cannot be completed successfully, then the printer may post an error message.
Page 338: Print Cycle
Theory of operation Print cycle Flowchart Charge Charge roller Photoconductor The charge roller applies a uniform negative electrical charge to the surface of the photoconductor. The insulative properties of the photoconductor allow it to hold a charge and its photoconductive properties allow it to discharge when exposed to light. Expose Photoconductor...
Page 339: Develop
Theory of operation Printhead The printhead emits a laser that exposes the surface of the photoconductor. The laser pulses coincide with the digital latent image. The exposed areas of the photoconductor surface are discharged, resulting in a photoconductor surface potential that is less negative than the non-exposed areas.
Page 340: Clean
Theory of operation Clean Waste toner compartment Cleaning blade Photoconductor The cleaning blade removes the residual toner from the photoconductor after the transfer. Waste toner is then stored in the waste toner compartment. After cleaning, the process moves again to the charge process and repeats each cycle until the entire image is transferred to a side of the paper.
Page 341: Printer Operation
Theory of operation Printer operation Printer sections Output bin Printhead Imaging unit Toner cartridge Simplex paper path Standard tray Optional tray...
Page 342: Printer Paper Path
Theory of operation Transfer roller Duplex paper path Fuser Printer paper path Simplex print job Photoconductor Transport roller MPF pick roller Feed roller Separator roller Pick roller...
Page 343: Duplex Print Job
Theory of operation Separator pad Transfer roller Fuser Paper exit roller The pick roller picks and the feed roller feeds the paper to the separator roller or separator pad. The feed roller feeds the paper to the transport roller. For MPF print jobs, the MPF pick roller picks and feeds the paper to the transport roller.
Page 344: Printer Paper Path Sensors
Theory of operation After the first side is printed, the paper stops at the output bin while still in the paper exit roller. The paper is fed again into the duplex paper path to have the opposite side printed. The paper travels along the duplex path until it enters again the transport roller. From there, the paper continues its path until the print job is done.
Page 345 Theory of operation Sensor Function Sensor (trailing edge) Detects the trailing edge of the paper that is fed from the optional tray Sensor (index) Detects if the pick roller is at the correct height to pick paper from the optional tray Sensor (paper present) Detects paper presence in the optional tray...
Page 346: Main Drive
Theory of operation Main drive MPF pick roller Transport roller Motor (main drive) Transfer roller Photoconductor Fuser Paper exit roller Duplex The motor (main drive) provides mechanical power to the printer. The motor transfers power through several gears to the following parts:...
Page 347: Tray Drive
Theory of operation • MPF pick roller • Transport roller • Transfer roller • Photoconductor • Fuser • Paper exit roller • Duplex Tray drive Pick roller Separator roller Separator pad Optional tray Standard tray The motor (main drive) in the printer drives the standard tray. The lift plate in the tray is spring loaded and is not driven by a motor.
Page 348: Adf Theory
Theory of operation ADF theory ADF paper path ADF tray ADF pick roller ADF separator pad ADF feed roller ADF scan roller Sensor (ADF scan) Sensor (ADF paper present) ADF exit roller ADF bin Paper from the ADF tray enters the ADF through the ADF pick roller, ADF feed roller, and ADF separator pad.
Page 349: Index
Index Index cleaning the scanner cleaning pick roller assembly advanced print quality samples clean adjustments fax volume ADF separator pad data security notice replacing diagnostics menu ADF paper path feed test controller calibration scanner calibration reset configurations accessing printer models develop cannot send or receive faxes using etherFAX configuration menu...
Page 350 Index 912 error messages humidity around the printer 200 paper jam messages 840 error messages indicator light 842 error messages understanding the status 843 error messages intelligent storage drive 845 error messages erasing 938–992 error messages invalid engine mode 280 paper jam messages accessing 295 paper jam messages invalid code, fixing...
Page 351 Index engine setting [x] printer model printer memory configurations paper erasing print quality troubleshooting selecting unacceptable fax transmission service check preprinted forms fax reception service check letterhead printer diagnostics and adjustments paper guidelines registration adjust paper characteristics margin offset preprinted forms universal override selecting parts catalog legend...
Page 352 Index paper path, simplex front USB paper path, duplex headphone jack upper front cover pick separator roller resetting the printer MPF pick roller without admin credentials sensor (input) reports transfer roller device settings duplex guide installed licenses redrive removal procedures printhead tips ADF cover...
Page 353 Index ADF separator pad scanner SE menu replacing supplies fax SE menu accessing imaging unit scheduled maintenance scanner storing paper cleaning supported paper sizes selecting location supported paper types for the printer supported paper weights sensors, paper path supported fax service checks troubleshooting 111 service error messages tools, required...
Page 354 Index replacing tray separator roller updating the printer firmware replacing using a flash drive theory using a network computer main drive using a USB cable connection tray drive using the control panel simplex paper path duplex paper path volatile memory paper path sensors erasing...
Page 355 Service Manual ...

This manual is also suitable for:

Xm3142

Lexmark MX432 Service Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark MX432

Summary of Contents for Lexmark MX432
