Converters.TV 15221 Operation Manual

Hdbaset hdmi over single cat5e/6/7 transmitter and receiver (with lan/poe/rs-232/ir)
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
HDBaseT HDMI over Single
CAT5e/6/7 Transmitter and Receiver
# 15221
(with LAN/PoE/RS-232/IR)
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 15221 and is the answer not in the manual?

Questions and answers

Related Manuals for Converters.TV 15221

Summary of Contents for Converters.TV 15221

  • Page 1 HDBaseT HDMI over Single CAT5e/6/7 Transmitter and Receiver # 15221 (with LAN/PoE/RS-232/IR) Operation Manual...
  • Page 2 Introduction The HDBaseT HDMI over Single CAT5e/6/7 Transmitter and Receiver (with LAN/PoE/RS-232/IR) set can send uncompressed audio/video and IP data over a single run of CAT5e/6/7 cable at a distance of up to 100 meters. It has the added benefit of control through the built-in RS-232 and IR ports and a bi-directional LAN serving connection.
  • Page 3 Operation Controls and Functions Transmitter 1. HDMI IN: Connect to HDMI source equipment such as a DVD or Blu-ray player. 2. LAN: Connect to an active network for LAN serving. This allows network access (including internet access if available) to be shared to any device (e.g. a smart TV or games console) connected to the LAN port of the receiver Warning: DO NOT connect the LAN connection to the CAT5e/6/7 output, doing so may trigger a power shut down and may damage the device.

  • Page 4: Power Led

    Receiver 1. HDMI OUT: Connect to a HDMI equipped TV/monitor for display of the HDMI input source signal. 2. LAN: Connect to a LAN equipped device (such as a smart TV or games console) to share the network access (including internet access if available). Warning: DO NOT connect the LAN connection to the CAT5e/6/7 output, doing so may trigger a power shut down and may damage the device.
  • Page 5 IR Cable Pin Assignment D-Sub 9-Pin Definitions DEFINE TX/RX TxD/RxD RxD/TxD...
  • Page 6 Connection Diagram...
  • Page 7 Specifications Video Bandwidth 300MHz/10.2Gbps Ethernet Speed 100Mbps Transmitter Input Ports 1×HDMI, 1×IR Extender,1×RS-232, 1×LAN Output Ports 1×CAT5e/6/7, 1×IR Blaster Receiver Input Ports 1×CAT5e/6/7, 1×IR Extender Output Ports 1×HDMI, 1×RS-232, 1×IR Blaster, 1×LAN HDMI In Cable Distance 15m/1080p@8-bit or 6m/1080p@12-bit HDMI Out Cable Distance 15m/1080p@8-bit or 10m/1080p@12-bit CAT6 Cable Distance...
