- Page 1 USB Wireless Transmitter and Receiver to HDMI Display ID# 722 Operation Manual...
-
Page 2: System Requirements
Introduction The USB wireless transmitter and receiver to HDMI display can allow you to view any PC information on a compatible TV with a wired like experience. An additional feature of this product is that it includes extra USB ports allowing it to perform KVM operations next to the TV, which is an added bonus for those of us who are multi-taskers. - Page 3 Operating Functions Controls Transmitter The following sections describe the hardware components of the unit and include a step by step installation guide and other suggested settings. Connect the wireless USB dongle to a PC or Laptop to deliver fast and reliable media through the use of Ultra Wide Band (UWB) technology.
-
Page 4: Software Installation
Rear Panel ① Power: This slot is where the user plugs in the 5V DC power supply of this unit before connecting the adaptor to an AC wall outlet. ② Link LED: When the LED is on it meems the system is ready and there is audio and Video can be sent. - Page 5 Install Microsoft Net Framework 2.0 Step 1: Click Install Microsoft Net Framework 2.0 to start the installation process. Step 2: Click “Next” to start the setup. Step 3: Click “I accept the terms of the License Agreement” and go to the Next page.
- Page 6 Step 4: Click “Finish” to complete the installation.
- Page 7 Install Wireless USB Manager Step 1: Click “Next” to Install Wireless USB Setup Step 2: Click “I accept the terms of the License Agreement” and go to the Next page.
- Page 8 Step 3: Select the installation folder for the Wireless USB. Step 4: Click “Install” to begin installing Step 5: For the software installation, click “Continue Anyway” to continue installing the software.
- Page 9 Step 6: Click Finish to complete the Wireless USB installation Install DisplayLink Software Select the preferred language and click automatically check for updates, and then click “I Accept” to install the DisplayLink Manager...
- Page 10 Hardware installation After inserting the Wireless USB dongle into the computers USB Port, the user needs to follow the system guidelines in order to install the Wireless USB dongle. Step 1: It is recommended to select “Install the software automatically” to install the Alereon WUSB Radio Controller interface and click “Next”...
- Page 11 Step 2: To install Alereon WUSB Radio Controller Interface, click “Continue Anyway” to continue to install the software Step 3: Click “Finish” to complete the Alereon WUSB Radio Controller Interface installation Step 4: Select “Install the software automatically” to install Alereon WUSB Host Adapter, click “Next” to start installing the driver.
- Page 12 Step 5: To install Alereon WUSB Host Adapter, click “Continue Anyway” to continue to install the software Step 6: Click “Finish” to complete the Alereon WUSB Host Adapter installation...
- Page 13 Step 7: It is recommended to select “Install the software automatically” in order to install Alereon Wireless USB Graphics Adapter w/Audio and click “Next” to start installing the driver. Step 8: To install Alereon Wireless USB Graphics Adapter w/Audio, click “Continue Anyway”...
- Page 14 Step 9: Click “Finish” to complete the Alereon Wireless USB Graphics Adapter w/Audio to finalize the installation process. Using Wireless USB Manager Running Wireless USB Manager Before the system has been connected the screen will show “Not Connected”...
- Page 15 Select Connection Rules item To connect a device for the first time the user must form an association...
- Page 16 System Association Enter pin code to associate with your computer Enter pin code “Alereon!” and click “Complete the association with this device”...
- Page 17 Association is successful Device Connection...
-
Page 18: Using Displaylink Manager
Using DisplayLink Manager After the driver is installed, a utility (DisplayLink Manager) will automatically appear in the system tray. The utility allows you to quickly change the settings and resolution for DisplayLink Manager. Right click on the icon will bring out the context menu. - Page 19 Color Quality: Select the screen color quality (available only in extended mode). Screen Rotation: Rotate the screen on the additional monitor by 90, 180 or 270 degrees.
- Page 20 Extend to: Reposition the extended screen to the top, bottom, left or right of the primary display. Extend: Set the DisplayLink Manager to Extended mode.
- Page 21 Set as Main Monitor: Set the monitor to be the main monitor. Notebook Monitor off: Set the PC/notebook's monitor off.
- Page 22 Mirror: Set the DisplayLink Manager to Mirror mode. You can see the same desktop image on the additional monitor. Off: Disable the DisplayLink Manager on the system.
- Page 23 Advanced: Opening the Display Properties will allow you to adjust the resolution, color quality, position and refresh rate. Using More DisplayLink manager You don’t have to install a new driver as long as you have completed the above installation process in advance. It will automatically define the ID of the new Display Link Manager and will list everything in the Display properties or the display manager menu.
- Page 24 Automatic Update Click the Updates → Configure… , the Updates Options window will appear as shown below. You can set the update method and frequency in the windows. Uninstall the Device Driver Follow the steps below to uninstall the Multi View driver. Step 1: Open the Control Panel: Start →...
- Page 25 Step 3: Click Yes to confirm the removal. Step 4: Click Yes to restart your computer.
-
Page 26: Installation
Installation... -
Page 27: Specifications
Specifications Input Port 1 x Mini USB Output Ports 1 x HDMI, 1 x D-Sub 15pin, 3.5Φ phone jack Extender Ports 2 x USB Hubs (A type) Power Supply 5V DC/2.6A (US/EU standards, CE/FCC/UL certified)ESD Protection Human body model: ± 8kV (air-gap discharge)± 4kV (contact discharge) Dimensions (mm) Transmitter:...
