- Page 1 DBaseT-Lite HDMI over CAT5e/6/7 with PoE Transmitter - ID# 15125 Operation Manual...
- Page 2 Introduction HDBaseT-Lite HDMI over CAT5e/6/7 with PoE Transmitter can send uncompressed video and audio over a single run of CAT5e/6/7 cable up to 60 meters (1080p) or 35 meters (4K×2K) with the added benefit of control through the built-in RS-232 and 2-way IR ports. The Power over Ethernet (PoE) function provides greater flexibility in installations.
- Page 3 Operation Controls and Functions Transmitter Front and Rear Panel 1. RS-232 In: Connect to a PC/laptop or RS-232 enabled device(with supplied 3.5 mm phone jack to D-Sub 9 pin adaptor) for the transmission of RS-232 commands. 2. IR2 Extender: Connect to the supplied IR extender cable for IR signal reception.
- Page 4 Receiver Front and Rear Panels 1. RS-232 Out: Connect to the device that is to be controlled (with the supplied 3.5mm phone jack to D-Sub 9-pin adaptor) by RS-232 commands. 2. IR1 Extender: Connect to the supplied IR extender cable for IR signal reception.
- Page 5 IR Pin Assignment D-Sub 9-Pin Definitions Definitions TxD/RxD RxD/TxD...
- Page 6 Connection Diagram...
- Page 7 Specifications Video Bandwidth 300 MHz/10.2 Gbps Transmitter input port 1 × HDMI audio and video terminals , 1 × IR receiver , 1 × RS-232 terminal (D-sub 9-pin connector ) Transmitter output port 1 × CAT5e/6/7 terminal , 1 × IR emitter Receiver input port 1 ×...
