- Page 1 HDMI v1.3 over ONE CAT6 HDMI Transmitter - ID# 992 Operation Manual...
- Page 2 Introduction The HDMI 1.3 transmitter over ONE CAT 6 is a tool for extending your HDMI signal over long distances to a compatible display. Instead of using expensive HDMI cables, your existing CAT 6 cables/sockets can be utilized to perform advanced functions like transferring Deep Color (12 bits/color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a bandwidth up to 225MHz.
- Page 3 Operation Controls and Functions Front Panel ① HDMI INPUT: This slot is where you connect the HDMI or DVI output port of your source equipment such as DVD/Blu Ray players or Set-top- boxes with an HDMI cable or link up with another receiver unit from the same family to extend a signal over long distances.
- Page 4 Connection Specifications Frequency Bandwidth 2.25Gbps(singlelink) TransmitterInput/Output Ports 1 x HDMI Female port/1 x CAT6 Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified) ESD Protection Human Body Model: ± 8kV (air-gap discharge) ± 4kV (contact discharge) Dimensions (mm) 78.5 (W) X 102 (d) X 30 (H) / Tx Weight(g) 182 / Tx Chassis Material...
