- Page 1 HDMI 3D 4k2k over Optical Fiber Transmitter & Receiver # 15135/15136 Operation Manual...
- Page 2 Introduction The 4Kx2K HDMI to Optical Transmitter and Receiver set uses fiber optic cables to give you longer transmission distances (up to 300m) utilizing thinner, lighter cables for greater flexibility in installations. With this system the HDMI signal is uncompressed and is fully compliant with HDMI and HDCP Applications •...
- Page 3 Operation Transmitter Front and Rear Panels Controls and Functions 1. POWER LED This LED will illuminate when connected to an AC wall outlet. 2.OPTICAL LINK LED The LED will illuminate when the optical cable is connected and has successfully detected and communicated data between the Transmitter and Receiver.
- Page 4 has successfully detected and communicated data between the Transmitter and Receiver. If the LED is not illuminated then check that the fiber optic cable is properly connected and that the cable itself is undamaged 3. HDMI LINK LED This LED will illuminate when the device is successfully communicating with the display 4.
- Page 5 Connection Diagram...
