- Page 1 HDBaseT HDMI over Single CAT5e/6/7 Transmitter and Receiver with LAN/PoE/RS-232/IR - # 15222 / #15223 Operation Manual...
- Page 2 Introduction The CH-2507 Transmitter and Receiver set can send uncompressed audio/video and IP data over a single run of CAT5e/6/7 cable at a distance of up to 100 meters with the added benefit of control through the built-in RS- 232 and IR ports and a bidirectional LAN serving connection. The transmitter (PD) can be powered by the PoE (48V) function of the receiver (PSE), allowing for greater flexibility in installations.
- Page 3 Operation Controls and Functions Transmitter Front and Rear Panels 1. HDMI IN: Connect to HDMI source equipment such as a DVD or Blu-ray player. 2. LAN: Connect to an active network for LAN serving. This allows network access (including internet access if available) to be shared to any device (e.g. a smart TV or games console) connected to the LAN port of the receiver Warning: DO NOT connect the LAN connection to the CAT5e/6/7 output, doing so may trigger a power shut down and may damage the...
- Page 4 Receiver Front and Rear Panels 1. HDMI OUT: Connect to a HDMI equipped TV/monitor for display of the HDMI input source signal. 2. LAN: Connect to a LAN equipped device (such as a smart TV or games console) to share the network access (including internet access if available) 3.
- Page 5 IR Cable Pin Assignment D-Sub 9-Pin Definitions DEFINE TX/RX TxD/RxD RxD/TxD...
- Page 6 Connection Diagram...
- Page 7 Specifications Video Bandwidth 300MHz / 10.2Gbps Ethernet Speed 100Mbps Transmitter Input Ports 1×HDMI, 1×IR Extender,1×RS-232, 1×LAN Output Ports 1×CAT5e/6/7, 1×IR Blaster Receiver Input Ports 1×CAT5e/6/7, 1×IR Extender Output Ports 1×HDMI, 1×RS-232, 1×IR Blaster, 1×LAN HDMI In Cable Distance 15m/1080p@8-bit or 6m/1080p@12-bit HDMI Out Cable Distance 15m/1080p@8-bit or 10m/1080p@12-bit CAT6 Cable Distance Up to 100m...
