- Page 1 HDMI HD Wireless Transmitter & Receiver System - ID# 948 Operation Manual...
- Page 2 Introduction Wireless HD AV Transmitter & Receiver Kits run at 5GHz operation frequency to deliver uncompressed HD video/audio 20 meters open field and 10 meters through wall with hidden antenna. This device kits make wireless connection by using WHDI Technology from HD Media Source Devices such as HD Disc Player, PC, Game Console, Settop Box to Display Device for example LCD, Plasma or LED TV, Projector...
- Page 3 Operation Controls and Functions Transmitter Image 1 1. IR: Connect with IR Out port (9 in Image 3) of the HDMI Switch. Note: If you are not using enclosed HDMI Switch, you can only connect one HD Media Device with the Transmitter unit: Please connect the IR port with enclosed Infrared Eye Cable and place the IR flasher close to the IR sensor of the Media Device.
- Page 4 1 . ON/OFF Switch: Power on/off the Wireless Transmitter unit. 2 . Wireless Link Indicator: Indicate that the wireless connection is linked 3 . Video Signal Indicator: Indicate that the video signal connection is linked up. 4 Power Indicator: Indicate when the Wireless Transmitter Unit is powered on.
- Page 5 Matrix 4 In 2 Out HDMI Switch Image 3 1. HDMI IN 1: Connect with HD Media Device via HDMI Cable. 2. HDMI IN 2: Connect with HD Media Device via HDMI Cable. 3. HDMI IN 3: Connect with HD Media Device via HDMI Cable. 4.
- Page 6 12. IR Remote Sensor: Work with enclosed remote control for media source selection. 13. A Channel Indicator: Indicate selected media input source for HDMI OUT A output. 14. B Channel Indicator: Indicate selected media input source for HDMI OUT B output. 15.
- Page 7 7. Power Indicator: Indicate when the extension box is powered on. 8. IR Plug: Connect with IR port on the Switch (16 in Image 3) Image 6...
- Page 8 Installation Diagram for Matrix Display How to install the Transmitter unit: You can connect up to 4 HD media devices with the Wireless Transmitter unit • via the HDMI Switch. • Plug the HDMI Switch to the Transmitter unit and place them near your HD media devices.
- Page 9 Standard Package Image 7 Installation Diagram for Single Display How to install the Transmitter unit: Place the Transmitter unit near your HD media device. • Connect the Infrared Eye Extension Cable to the 'IR' port on the • Transmitter unit.
- Page 10 Place the IR flasher near the IR receiver of the HD media devices. • Connect the HDMI cable to the 'HD IN' connection of the • Transmitter unit. Connect the other side of the HDMI cable to your HD media •...
-
Page 11: Specifications
Specifications TV: 1080p, 1080i, 720p, 576p, 480p PC: Video Format Support VGA(640x480), SVGA(800x600), XGA(1024x768), SXGA(1280x1024) Audio Format Support PCM, DTS, DOLBY DIGITAL RF Communication System MIMO Modulation OFDM Maximum Transmission 12dBm Power Image Transmission 30 meters open field and 10 meters through Distance wall Image Delay...
