6.3 On/o switch and mute button

6.3.1 Accessing the on/o switch

1.
Push the bottom part of the lever on the back of the Stick mic.
This will lift the upper part of the Stick mic and release the Clip.
2.
Open the Clip lever to access and turn the power switch on or o .
6.3.2 On/o switch and mute button
Press the mute button to control the microphone:
if the symbol is red, the Stick is muted;
if the symbol is white, the mic is unmuted.
While on the charging dock, the Stick mic is automatically muted.
The mic turns on and unmutes automatically when picked up from the
charging dock, allowing for immediate use.

6.4 Stick mic charging

The Stick mic should be charged on its dedicated charger -
the Charging Dock.
1.
Take the provided USB-C cable and plug it into the port located at the
bottom of the Charging Dock.
2.
Arrange the cable within the designated grooves to keep it organized
and ensure it does not hang loosely or cause any obstruction.
3.
Connect the other end of the cable to a power outlet.
4.
When the Charging Dock is powered, the LED light on the top part of
the Dock will light up.

6.4.2 Charging the Stick mic

5.4.1 Powering the Charging Dock

1.
Place the Stick mic on the Charging Dock. Magnetic pins will help
ensure the Stick is positioned correctly.
2.
If all LED lights on the front of the Stick are on, the mic is fully
3.
If one of the lights is blinking, the Stick mic is not yet fully charged and
is currently charging. A full charge takes 2 hours and the
battery life on a full charge is up to 8 hours.
4.
The Stick mic is automatically muted while charging.

6.5 Recommended Distance

When using the Stick mic, hold it about 10 cm/ 4 in away from your mouth.
Thanks to our advanced audio processing functionalities, the Stick mic
maintains excellent sound quality even if this distance is not strictly
maintained or if the presenter moves while speaking.
10cm/4''
