6. Stick handheld microphone

The Stick is a handheld presenter microphone.
Featuring a built-in pop lter, it reduces disruptive sounds, ensuring clear
and professional audio quality.
It has an 8-hour battery life and the Stick mic is compatible with both Single and Dual Charging
Docks that can be daisy-chained, optimizing the use of power outlets.
If the Stick mic is taken out of the Hub DSP receiver's range, an automatic Range Alarm will go o
and inform the user, encouraging them to bring the mic back to the designated room or event space.
The Stick microphone activates and unmutes automatically when picked up from its Charging Dock.
Its ergonomic design provides a comfortable grip, ideal for presentations and speeches.

6.1 Stick operating elements and connections

1. Pop lter
2. Microphone element
3. Battery LED
4. Adapter
5. Mute button
a. If Mute button is pressed for 10 sec, pairing is initiated

6.2 Stick LED behavior

O
Green
Orange
Orange blinking
1
2
3 5
4
Not powered
Power on, Transmitters paired to Hub
Power on, No transmitters connected to Hub
In pairing mode
6 11
7
8
6. Charging pads
7. Status LED
8. Lever
9. Power switch
10. Power jack (USB-C)
11. Serviceable battery compartment
9
10
