4.3 Cube locking mechanism

The capsule is held in place
by magnets located on the
bottom of both the cover and
the capsule. To remove it, hold
1
the capsule by the foam cap
and turn it 90 degrees.
3
When reinserting the capsule,
align the triangles inside the
cover with those on the
bottom of the capsule.

4.4 Cube Charging

4.4.1 Powering the Charging Base

Cube mic should be charged on its dedicated charger - the Cube Charging Base.
1.
Take the provided USB-C cable and plug it into the port located at the
bottom of the Charging Base.
2.
Arrange the cable within designated grooves to keep it organized and ensure
it does not hang loosely or cause any obstruction.
3.
Connect the other end of the cable to a power outlet.
4.
When the Charging Base is powered, the middle one of the ve LED
indicators on the top part of the Charging Base will light up.

4.4.2 Charging the Cube mic

1.
Always ensure the capsule is in the soft cover before placing the Cube mic
on the Charging Base. The capsule alone will not charge.
2.
Make sure the Cube is placed fully on the Charging Base.
Improper placement can result in battery drainage rather than charging.
3.
Ensure there are no foreign objects between the Cube and
the Charging Base.
4.
If all LED lights on the Charging Base are on, the Cube mic is fully charged.
5.
If one of the lights is blinking, the Cube mic is not yet fully charged and is
currently charging. A full charge takes 6 hours and the battery life on a full
charge is 22 hours.
6.
The Cube mic is automatically muted when on the Charging Base.
4
Place the capsule back in,
ensuring the magnets are
properly aligned.
Once turned, you can pull
the capsule out as the twist
disengages the magnets.
2
5
You'll hear a click sound, con rming
the capsule is securely in place.
To double-check, hold the Cube
upside down. If the capsule
stays put, it's secure.
