5. Clip lavalier presenter microphone

Clip is a wearable presenter microphone designed for ease of use and high audio quality.
It has an 8-hour battery life and the Clip mic is compatible with both Single and Dual Charging
Docks that can be daisy-chained, optimizing the use of power outlets.
If the Clip mic is taken out of the Hub DSP receiver's range, an automatic Range Alarm will go o
and inform the user, encouraging them to bring the mic back to the designated
room or event space.
Clip mic has only 2 buttons: the on/o switch, which is hidden under the Clip lever,
and the Mute button.
The Clip unmutes automatically when picked up from the charging dock.
It can be clipped onto clothing or worn around the neck with the provided lanyard.
Clip mic captures clear audio regardless of head movement, ensuring that every word is heard clearly.

5.1 Clip operating elements and connections

3
1. Status LED
2. Microphone element
3. Clip
4. Charging pads
5. Battery LED's

5.2 Clip status LED behavior

O
Green
Orange
Orange blinking
1
4
8
6. Mute button
a. If Mute button is pressed for 10 sec, pairing is initiated
7. Power switch
8. Power jack (USB-C)
9. Serviceable battery compartment
Not powered
Power on, Transmitters paired to Hub
Power on, No transmitters connected to Hub
In pairing mode
2
5
9 6 7
12
