- Page 1 I N S T R U C T I O N M A N U A L LINC84T-13 Series Chemical Metering Pump Pneumatic Plunger...
- Page 2 Please send RFQ’s to: Or FAX your order anytime to Technical service and support By Mail: 215.293.0498 begins with an easy toll-free call. Linc Milton Roy Many times, our experienced For the Nearest Authorized Attn: Customer Service customer service reps can isolate Representative:...
-
Page 3: Table Of Contents
M E T E R I N G P U M P S Contents - 84T-13 Pump Manual .......................... Page General Specifications ............................4 Selection Chart ..............................4 Ordering Chart ..............................4 Scope Of This Manual ............................5 Installation ................................5 Maintenance ................................. -
Page 4: General Specifications
M E T E R I N G P U M P S General Specifications: LINC84T-13 Series Pneumatic, Plunger Type Metering Pumps Wetted Parts: Pneumatic Section: Pump Body: 316 Stainless Steel Piston Housing: 303 Stainless Steel Plunger: 17-4 PH or Ceramic... -
Page 5: Scope Of This Manual
The timer can be set to vides instructions and parts list for supply pressure to overcome stroke the pump from 4 the LINC84T-13 Series Chemical the discharge pressure of the strokes/minute to the maxi- Metering Pump. This pump is a pump. -
Page 6: Timer
M E T E R I N G P U M P S to the timer and unscrew 5. Disconnect the suction 5. To test the relay prior to slowly until the pump starts to and discharge lines from the reassembly, connect the sup run. -
Page 7: Piston/Plunger
M E T E R I N G P U M P S 2. Carefully remove the plunger Replace if necessary. Reas- Plunger and Plunger Seal seal and plunger seal semble the check valve Lubrication: back up from the upper hous using new o-rings. -
Page 8: How To Determine Supply Pressure
M E T E R I N G P U M P S IMPORTANT: How To Determine Supply Pressure: The theoretical amplification ratio shown in the Selection Chart of this manual is the area of the piston divided by the area of the plunger. This amplification ration is used to determine how much gas supply pressure is required to enable the pump to generate the required liquid discharge pres- sure. -
Page 9: Assembly Drawings & Parts Lists Figure 1, 84T-13 Assembly Drawing
M E T E R I N G P U M P S Figure 1, LINC 84T-13 Series Pump • Page LINC MILTON • IVYLAND ROAD • IVYLAND 18974 • • TEL. 215.441.0800 84T-13 ver. 04082003 - pn 15105... -
Page 10: Pump Assembly Parts List: 84T-13
M E T E R I N G P U M P S LINC84T-13 Series Parts List Model 84T-13-x4 Plunger Size 1/2" Piston Size 4" Item Part# Description Material 1 ......31668 ....Pneumatic Timer ........303 ss ....... 1 2 ......23339 ....Vent Assembly ........Plated ....... 1 3 ...... -
Page 11: Plunger Seal Materials Parts List
M E T E R I N G P U M P S LINC84T-13 Series Seal Materials Model 84T-13-14 Item Description Part # Material 17A ..... Plunger Seal ........... 10525 ......Fluorocarbon ....1 17B ..... Back Up ..........25374 ......Peek ......... 1 18 ....... - Page 12 M E T E R I N G P U M P S Figure 2, Timer Reference fig. 1, item 1 1/8" NPT HEX NIPPLE TO TOP OF PISTON SUPPLY PRESSURE 150 psi MAX. (1/4" FNPT) 1/4"NPT VENT TO ATMOSPHER Assembly 31668 Timer...
- Page 13 M E T E R I N G P U M P S Figure 3, Single Acting Relay Reference fig. 1, item 3 Port #2 1/4"NPT TO PUMP "OUT" Port #4 1/8"NPT Port #3 Port #3 1/4"NPT 1/4"NPT SUPPLY EXHAUST 180 psi MAX.
- Page 14 M E T E R I N G P U M P S Figure 4, Discharge Check Valve Reference fig. 1, item 18 Assembly 22624 22525 22626 Discharge Check Valve Port Size 1/4" NPTF One Piece Body Item Part # Part # Part # Description...
- Page 15 M E T E R I N G P U M P S Figure 5, Suction Check Valve Reference fig. 1, item 19 Suction Check Valves - One Piece Body Part Number 24778 Port Size 1/2" NPTM Item Description Part # Material 1 ......
- Page 16 M E T E R I N G P U M P S LINC Chemical Pump Gas Consumption Table ACTUATION PISTON DIA. (IN)>> 1.50 2.25 > > SPRING SPRING SPRING SPRING SPRING CONFIGURATION RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN >...
- Page 17 M E T E R I N G P U M P S • Page LINC MILTON • IVYLAND ROAD • IVYLAND 18974 • • TEL. 215.441.0800 84T-13 ver. 04082003 - pn 15105...
- Page 18 LINC Milton Roy. represents and warrants that for a period of 3 years from receipt of the product: (1) the product will be free from defects in materials and workmanship; and (2) the product will perform substantially in accordance with product manuals, literature, or documentation. Any written or oral information or advice given by LINC Milton Roy representatives, agents, or employees will in no way increase the scope of this warranty.
