RDMOTO CF120 Mounting Instructions

Kit for Left Side
ID Description
1 Frame
2 Screw M10x50mm
3 Washer-Flat M10
4 Plastic Cover M10
5 Dural. roller d=15mm
6 Screw M8x35mm
7 Washer-Flat M8
8 Screw M8x30mm
9 Dural. roller d=4mm
10 Self-Lock nut M8
11 Plastic cover M8
12 Dural. roller d=50mm
13 Washer M12
14 Nut M12
15 Rod M12x340x30x30
16 Screw M6x60mm
17 Washer M6
18 Screw M8x25mm
We recommend using medium strenght thread glue during assembly.
Mounting Instructions:
1.) On left side, unscrew the original M10 front bolt where stand meets the frame and
M12 bolt in the middle of bike (see pictures). Replace it with M12 ID.15 Rod.
2.) Fit the M12 ID.15 rod with ID.12 dural. roller, crash frame, washer M12 ID.13 and
M12 ID.14 nut (dont tighten anything yet).
3.) Attach bottom part at the place of stand with M10 ID.2 bolt and ID.3 washer.
4.) In front part, use M8 ID.6 bolt and M8 ID.7 washer and insert the ID.5 roller in
between frame and engine.
5.) Then, attach upper front part with M8 ID.8 bolt and M8 ID.7 washer, slide the frame
from the back and insert ID.9 roller in between. Then, put on the washer and fix in
place with M8 ID.10 nut (see pictures).
6.) Use the same procedure on the right side, following pictures attached.
7.) Finally, tighten all screws and put on the plastic covers.
8.) Upper frame is secured in place with M8 bolt on both sides. Use ID.18 screw, ID.7
washer and M8 ID.10 nut on left side. On right side, use the ID.15 screw, ID.7
washer and ID.9 M8 nut.
9.) Now, use M6 ID.16 screws (right side), M16 ID.17 washers (left side) and M6 nuts
(right side) to fix ID.18 strut (right side) to the frame and other side to indicators.
Cat.No. Pcs.
BMW-2-L+CF121 1
849 1
804 1
X4 1
465 1
861 1
802 5
834 1
1305 1
809 2
X5 2
209 1
803 1
811 1
1
872 2
947 6
831 1
1
CF120
BMW R1200GS 2013-
Kit for Right Side
ID Description
1 Frame
2 Screw M10x50mm
3 Washer-Flat M10
4 Plastic Cover M10
5 Dural. roller d=15mm
6 Screw M8x35mm
7 Washer-Flat M8
8 Screw M8x30mm
9 Self-Lock nut M8
10 Plastic cover M8
11 Dural. roller d=50mm
12 Washer M12
13 Nut M12
14 RDmoto Sticker
15 Screw M8x25mm
16 Screw M6x20mm
17 Self-lock nut M6
18 Strut
RDMOTO CZECH REPUBLIC
info@rdmoto.eu
www.rdmoto.eu
Cat. No. Pcs.
BMW-2-P+CF121 1
849 1
804 1
X4 1
465 2
861 2
802 5
834 1
809 2
X5 2
209 1
803 1
811 1
2
831 1
875 2
948 2
X120 1
