Kit for lef side:
ID. Description
1
Cash bar
2
Bolt M6x50
3
Washer M6
4
Spacer d=12mm
5
Bolt M10x120
6
Washer M10
7
Nut M10
8
Steel rod 10x300x30x30
9
Spacer d=82mm
Assembly instruction:
We recommend to use glue of threads, medium strong. During the assembly.
Kawasaki Versys 650´15-
Kit for right side:
Kat.
Qt
ID. Description
CF50
1
1
Cash bar
867
1
2
Bolt M6x50
987
1
3
Washer M6
120
1
4
Spacer d=12mm
881
1
5
Bolt M10x160
804
2
6
Washer M10
814
2
7
Nut M10
1
8
Bolt M8x25
1175
1
-
-
1
RDMOTO CZECH REPUBLIC
info@rdmoto.cz
www.rdmoto.cz
CF50
Kat.
CF50
867
987
120
979
804
814
833
Bolt M6x50 + washer M6.
Place spacer d=12mm. Under
the cash bar.
Bolt M10x120 + washer
M10. For tighten use nut
M10. Replace original nut.
Original silentblock leave on
the frame.
Take out orig. bolt M10x200.
Insert rod M10x300 throught
the engine. Insert spacer
d=82mm. For tighten use nut
M10 + washer M10.
Qt
1
1
1
1
1
2
2
1
-
-
