RDMOTO CF123 Mounting Instructions

Kit for Left Side
ID Description
1 Lower Frame
2 Strut
3 Washer M10-flat
4 Self-lock nut M10
5 Dural. roller d=22mm
6 Screw M10x50mm
7 AL screw cover
8 Plastic allen bolt cover
9 Screw M6x20mm
10 Washer M6 – flat
11 Washer M6 – large
12 Self-lock nut M6
Mounting Instructions:
Follow mounting procedure as shown on attached photographs.
Take off the original lower plastic casing.
Then install X125 strut into the frame, but don't tighten it yet.
Put on the lower frame in rear part into rubber housings and lean it
towards the X125 strut.
Take M10x50mm screws, equip them with Al covers and mount into
thread on the X125 strut. To cover the bolt heads, use plastic covers
for allen bolts.
Finally, you can tighten everything.
KTM 690 Enduro R 2019-
Kit for Right Side
Cat. No. Pcs ID
CF123 1 1
X125 1 2
804 1 3
810 1 4
1337 1 5
849 1 6
X115 1 7
X4 1 8
1022 3 9
947 3 10
987 3 11
948 3 12
1
RDMOTO CZECH REPUBLIC
CF123
Description
Lower Aluminium plate
Screw M10x175mm
Washer M10-flat
-------------------------
Dural. roller d=22mm
Screw M10x50mm
AL screw cover
Plastic allen bolt cover
Screw M6x20mm
Washer M6 – flat
Washer M6 – large
Self-lock nut M6
info@rdmoto.cz
www.rdmoto.cz
Cat. No. Pcs
X124 1
936 1
804 1
---
1337 1
849 1
X115 1
X4 1
1022 3
947 3
987 3
948 3
