RDMOTO CF124 Quick Start Manual

Husqvarna 701 Enduro/Supermoto 2016-2020
Kit for Left Side
ID. Description
1 Top Crash Frame
2 Screw M10x60mm
3 Frame insertion (d=16mm)
4 Frame insertion (d=13mm)
5 Washer M10-spring
6 Plastic cap for frame
7 Strut
8 Washer M10-flat
9 Safety nut M10
10 Dural. roller d=22mm
11 Screw M10x50mm
12 AL screw cap
13 Plastic cap for Allen bolt
14 Lower frame
15 Screw M6x20mm
Washer M6 – flat
16
Washer M6 – large
17
18 Safety nut M6

Mounting Instructions:

Follow steps and instructions on the attached photographs.
First, uninstall the lower original plastic cover.
Then, mount strut X125 into the frame, but dont tighten it yet.
Mount the lower frame in rear part into rubber brackets and lean it towards the X125 strut.
Attach it slightly by M10x50mm screw on one side.
Now take off screws in the left top frame part and insert brackets (wider bracket for the top
hole).
Take the left crash frame and screws M10x60mm, mount it into motorcycle frame with
spring washers (dont tighten yet).
Do the same with the top right crash frame.
Now, the top frame should meet lower frame in the area of X125 strut, take screws
M10x50mm, equip them with the AL screw covers and mount into thread on the X125 strut.
Use the plastic allen bolt covers to hide screw heads.
KTM 690 Enduro R 2019-
Kit for Right Side
Cat. No. Pcs ID
CF122 1 1
850 2 2
499 1 3
1143 1 4
804 2 5
X19 2 6
X125 1 7
804 1 8
810 1 9
1337 1 10
849 1 11
X115 1 12
X4 1 13
CF123 1 14
1022 3 15
947 3 16
987 3 17
948 3 18
1
RDMOTO CZECH REPUBLIC
CF124
Description
Top Crash Frame
Screw M10x60mm
Frame insertion (d=16mm)
Frame insertion (d=13mm)
Washer M10-spring
Plastic cap for frame
Screw M10x180mm
Washer M10-flat
-------------------------------
Dural. roller d=22mm
Screw M10x50mm
AL screw cap
Plastic cap for Allen bolt
Lower AL cover
Screw M6x20mm
Washer M6 – flat
Washer M6 – large
Safety nut M6
info@rdmoto.cz
www.rdmoto.cz
Cat. No. Pcs
CF122 1
850 2
499 1
1143 1
804 2
X19 2
978 1
804 1
---
1337 1
849 1
X115 1
X4 1
X124 1
1022 3
947 3
987 3
948 3
