- Page 1 User Manual Model ID: OVATIONH55WWBLK, OVATIONH55WWWHT...
- Page 2 Edition Notes The Ovation H-55WW User Manual includes a description, safety precautions, installation, programming, operation and maintenance instructions for the Ovation H-55WW as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, and Ovation are registered trademarks or trademarks of Chauvet &...
-
Page 3: Table Of Contents
RDM2go Programming ................. Menu Map ..................... Control Configuration ..................DMX Personalities....................14 Starting Address....................14 Control Channel Assignments and Values............ Standalone Configuration................Static Dimmer..................... 15 Static Strobe....................... 15 Automatic Program .................... 15 Automatic Program Speed....................Ovation H-55WW User Manual Rev. 1... - Page 4 Dimmer Speed Mode ..................16 Pulse Width Modulation ..................16 Emergency Mode ....................16 Reset Device Hours ................... 16 Factory Reset..................... 16 5. Maintenance................Product Maintenance ..................6. Technical Specifications ............Contact Us ..................Warranty & Returns..................Ovation H-55WW User Manual Rev. 1...
-
Page 5: Before You Begin
The product has XLR sockets for DMX input and output. • Notice: This control circuit is isolated and belongs to the Class 2 data port. • The control circuit has a cumulative leakage current of less than 3.5 mA. Ovation H-55WW User Manual Rev. 1... -
Page 6: Safety Notes
To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the product from power via breaker or by unplugging it. • In the event of a serious operating problem, stop using immediately. If a Chauvet product requires service, contact Chauvet Technical Support. Ovation H-55WW User Manual Rev. 1... -
Page 7: Fcc Statement Of Compliance
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. Ovation H-55WW User Manual Rev. 1... -
Page 8: Introduction
2. Introduction Description The Ovation H-55WW is a small, silent, convection cooled LED house light with warm white output and high CRI, ideal for theaters, worship venues, recital halls, or any application with a small trim height. The Ovation H-55WW features 16-bit dimming, RDM and W-DMX control, adjustable PWM to prevent flickering on televised performances, and interchangeable lenses for height adjustment. -
Page 9: Product Dimensions
253.6 mm 11.31 in 287 mm 4.52 in 115 mm 4.52 in 115 mm 6.92 in 176 mm 2.36 in 60 mm 5.12 in 130 mm 6.65 in 169 mm 6.11 in 155 mm Ovation H-55WW User Manual Rev. 1... -
Page 10: Setup
3. Setup AC Power The Ovation H-55WW has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 11: Master/Slave Connectivity
Wireless Operation In optimal conditions, the Ovation H-55WW can operate up to 300 m (900 ft) away from a W-DMX transmitter. It is necessary to pair the W-DMX receiver in this product with a W-DMX transmitter for wireless operation. -
Page 12: Product Pairing With Rdm2Go
If the Ovation H-55WW has already been paired with the W-DMX transmitter, the red LED indicator will show the strength of the signal. In this case, the Ovation H-55WW is ready to work in wireless mode. To pair the Ovation H-55WW to a new W-DMX transmitter with an RDM interface: 1. -
Page 13: Sconce Mounting
Setup Sconce Mounting The Ovation H-55WW comes with a sconce kit for mounting the product to a wall. To install the sconce kit to the product and mount it to a wall: 1. Remove the mounting bracket by removing the bracket adjustment knobs. -
Page 14: Recess Kit Installation
Setup Recess Kit Installation The Ovation H-55WW comes with a recess kit. Follow the instructions below to install the product to a ceiling tile. • Make sure the ceiling can support the weight of the product and recess kit prior to installation. - Page 15 (x4) Trim ring 5. Install the trim ring to the support rail with the 4 included long M4 screws. Long M4 screw (x4) Make sure the trim ring is flush against the ceiling. Ovation H-55WW User Manual Rev. 1...
-
Page 16: Lenses And Filter
3. Re-install the front cover of the product with the 4 hex screws. Egg Crate The Ovation H-55WW comes with an optional egg crate which installs to the front of the product with 4 Phillips-head screws. Ovation H-55WW User Manual Rev. 1... -
Page 17: Operation
4. Operation RDM2go Programming The RDM2go from Chauvet Professional, or another RDM-capable interface, is required to setup and program the Ovation H-55WW. Plug the interface into the DMX input of the product to access the menu map. Menu Map Refer to the Ovation H-55WW product page on www.chauvetprofessional.com... -
Page 18: Control Configuration
Operation Control Configuration Use an RDM2go from Chauvet Professional (or another RDM-capable interface) to set the control configurations and operate the product with a DMX controller. DMX Personalities To set the DMX personality: 1. Go to the DMX Channel main level. -
Page 19: Standalone Configuration
Operation Standalone Configuration Use an RDM2go from Chauvet Professional (or another RDM-capable interface) to set the product to run in a standalone mode. Static Dimmer To set the standalone dimmer of the product: 1. Go to the Specific PIDS main level. -
Page 20: Settings Configuration
Operation Settings Configuration Use an RDM2go from Chauvet Professional (or another RDM-capable interface) to configure the settings of the product. Master Slave To configure the product to act as a master or slave: 1. Go to the Specific PIDS main level. -
Page 21: Maintenance
6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Ovation H-55WW User Manual Rev. 1... -
Page 22: Technical Specifications
5-pin XLR, W-DMX 1, 2, 3, or 6 Ordering Product Item Name Item Code UPC Number Ovation H-55WW (black) OVATIONH55WWBLK 03031628 781462219765 Ovation H-55WW (white) OVATIONH55WWWHT 03031627 781462219758 UL 1573 CSA C22.2 No. 166 E113093 Ovation H-55WW User Manual Rev. 1... -
Page 23: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Ovation H-55WW User Manual Rev. 1...
