- Page 1 User Manual Model ID: WELLPANELXX4...
-
Page 2: Edition Notes
Edition Notes The WELL Panel X X4 User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the WELL Panel X X4 as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, WELL and WELL Panel are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
Procedure......................11 4. Operation ..................Control Panel Description ................Control Options ..................... Programming....................Home Screen ....................Control Panel Lock..................Password ......................12 Menu Map ..................... DMX Configuration..................DMX Personalities....................15 Starting Address....................15 WELL Panel X X4 User Manual Rev. 1... - Page 4 RF Setting ......................20 RF Controller Operation ..................20 Error Codes....................5. Maintenance................Product Maintenance ..................Torque Measurements .................. Vacuum Test Measurements ................ 6. Technical Specifications ............Contact Us ..................Warranty & Returns..................WELL Panel X X4 User Manual Rev. 1...
-
Page 5: Before You Begin
The product has XLR sockets for DMX input and output. • Notice: This control circuit is isolated and belongs to the Class 2 data port. The control circuit has a cumulative leakage current of less than 3.5 mA. WELL Panel X X4 User Manual Rev. 1... -
Page 6: Safety Notes
• In the event of a serious operating problem, stop using immediately. If this Chauvet product requires service, contact Chauvet Technical Support. WELL Panel X X4 User Manual Rev. 1... -
Page 7: Battery Charge Notes
Leaving the product powered on while charging in a closed case may lead to damage. • In the event a WELL Panel X X4 fixture remains powered on when plugged in to the charging case, and the case is closed, the battery charge indicators will flash on and off as a warning. -
Page 8: Fcc Statement Of Compliance
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. WELL Panel X X4 User Manual Rev. 1... -
Page 9: Introduction
# Name # Name # Name 1 Power in 4 GORE® valve 7 Power button 2 DMX in 5 Menu buttons 8 DMX out 3 Antenna 6 Menu display 9 Power out WELL Panel X X4 User Manual Rev. 1... -
Page 10: Product Dimensions
233 mm 5.31 in 6.37 in 135 mm 161.8 mm Charging Case Overview # Name 1 Power in 2 Power out 3 Fuse holder 4 USB type-C port 5 Battery charge indicators WELL Panel X X4 User Manual Rev. 1... -
Page 11: Charging Case Dimensions
722.8 mm 250 mm 13.62 in 346 mm 36.4 in 925 mm 19.69 in 500 mm 12.99 in 330 mm 12.74 in 730 mm 25.98 in 660 mm 13.62 in 346 mm WELL Panel X X4 User Manual Rev. 1... -
Page 12: Setup
4. Screw the fuse holder cap back in place and reconnect power. Power Linking It is possible to power link WELL Panel X X4 products. See the table below for the current draw at each voltage and frequency: WELL Panel X... -
Page 13: Remote Device Management
If the WELL Panel X X4 has already been paired with the CRMX™ transmitter, the signal strength indicator on top of the display will show the strength of the signal. In this case, the WELL Panel X X4 is ready to work in Wireless mode. -
Page 14: Transmitter Configuration
If the WELL Panel X X4 has already been linked to a receiving product, the signal strength indicator on top of the display will show the strength of the signal. In this case, the WELL Panel X X4 is ready to work in wireless mode. -
Page 15: Mounting
Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Procedure The WELL Panel X X4 comes with Omega brackets. The user can directly attach mounting clamps (sold separately) to these Omega brackets. Make sure the clamps are capable of supporting the weight of this product. -
Page 16: Operation
<Down> Navigates downwards through the menu list or decreases the value when in a function Control Options Set the WELL Panel X X4 starting address in the 001-508 DMX range. This enables control of up to 102 products in the 5-channel 5 Ch personality. -
Page 17: Menu Map
Operation Menu Map Refer to the WELL Panel X X4 product page on www.chauvetprofessional.com for the latest menu map. Main Level Programming Levels Description Selects DMX address DMX Address 001–508 (highest channel restricted to personality chosen) 5 Ch 5-channel: RGBW, control... - Page 18 Turns off display backlight after 30 seconds of inactivity Back Light Turns off display backlight after 2 minutes of 2Min inactivity Always On Display backlight always on Locks display (password is <Up>, <Down>, <Up>, Password <Down>, <Enter>) WELL Panel X X4 User Manual Rev. 1...
-
Page 19: Dmx Configuration
To set the starting address in DMX mode: 1. Go to the DMX Address main level. 2. Select the starting address (001–512). Personality Highest Address Products per Universe 5 Ch 8 Ch 9 Ch 12 Ch WELL Panel X X4 User Manual Rev. 1... -
Page 20: Dmx Channel Assignments And Values
075 079 Linear dimmer curve* 175 249 Reserved for future use 080 084 Square dimmer curve* 250 255 No function 085 089 Inverse square dimmer curve* *Hold for 5 seconds WELL Panel X X4 User Manual Rev. 1... -
Page 21: Dmx Chart
227 255 Automatic program 9 (cycle 6–8) – – – 15 Automatic program speed 000 255 Program speed, slow to fast 16 Control 000 255 See the Control Chart WELL Panel X X4 User Manual Rev. 1... -
Page 22: Standalone Configuration
3. Set the Speed value (001–100). Settings Configuration Master/Slave To set the WELL Panel X X4 product to master or slave mode: 1. Go to the Master/Slave main level. 2. Select from Master (sends control signal) or Slave (receives control signal). -
Page 23: White Balance
Information main level. Factory Reset To reset the product to factory default settings: 1. Go to the Factory Reset main level. 2. Select No (do not reset) or Yes (reset). WELL Panel X X4 User Manual Rev. 1... -
Page 24: Radio Frequency Configuration
• Link: DO NOT press <ENTER>. Highlight the Link option, and press and hold <Blackout> on the RF Controller until the WELL Panel X X4 display shows RF Connected or RF Disconnected. • Group: assign the product to the desired group, from Group 1–4. -
Page 25: Maintenance
Torque Rating (Kgf.cm) Torque Rating (lbf.in) Rear cover 10.41554 Top cover 8.67916 Vacuum Test Measurements Use the IP Tester from Chauvet Professional to ensure the product has been reassembled correctly by following the information below: Parameters Values Method Positive Test pressure... -
Page 26: Technical Specifications
DMX I/O Connector Channel Range 5-pin XLR, Wireless Lumenradio CRMX™ 5, 8, 9, 12, or 16 Ordering Product Name Item Name Item Code UPC Number WELL Panel X X4 WELLPANELXX4 03032237 781462225858 WELL Panel X X4 User Manual Rev. 1... -
Page 27: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. WELL Panel X X4 User Manual Rev. 1...
