TEKTELIC Communications KONA HAZLOC MEGA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
K
H
ONA
AZ
U
G
SER
UIDE
Document Number:
D
I
:
OCUMENT
SSUE
D
S
:
OCUMENT
TATUS
P
C
:
RODUCT
ODES
I
D
:
SSUE
ATE
PROPRIETARY:
The information contained in this document is the property of TEKTELIC Communications Inc. Except as specifically
authorized in writing by TEKTELIC, the holder of this document shall keep all information contained herein
confidential, and shall protect the same in whole or in part from disclosure to all third parties.
© 2023 TEKTELIC Communications Inc., all rights reserved.
All products, names, and services are trademarks and registered trademarks of their respective companies.
TEKTELIC Communications Inc.
7657 10th Street NE
Calgary, AB, Canada T2E 8X2
Phone: (403) 338-6900
L
M
OC
EGA
T0007531_UG
2.0
A
PPROVED
S
T
EE
ABLE
M
18, 2023
AY
G
ATEWAY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KONA HAZLOC MEGA and is the answer not in the manual?

Questions and answers

Related Manuals for TEKTELIC Communications KONA HAZLOC MEGA

Summary of Contents for TEKTELIC Communications KONA HAZLOC MEGA

  • Page 1 SSUE PROPRIETARY: The information contained in this document is the property of TEKTELIC Communications Inc. Except as specifically authorized in writing by TEKTELIC, the holder of this document shall keep all information contained herein confidential, and shall protect the same in whole or in part from disclosure to all third parties.

  • Page 2: Revision History

    July 19, 2021 Obsolete S. Morrison Updated certification information May 18, 2023 Approved S. Morrison Removed issue/rev number from the IECEx/ATEX certificate numbers Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc. Confidential Page 2 of 19...

  • Page 3: Table Of Contents

    Safety Precautions ......................9 Unpacking and Inspection ....................10 Required Equipment for Installation ................11 Kona HazLoc Mega Gateway Mounting ................. 11 Ground Cable Installation ....................13 Direct DC Power Cable Installation ................14 Copper Ethernet Cable Installation ................15 LoRa RF Antenna Installation ..................

  • Page 4: Product Description

    T0007288 Note: The second antenna port connector may or may not be present on the single antenna models. Figure 1 illustrates the Kona HazLoc Mega Gateway. All models share the same mechanical form- factor. Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0...

  • Page 5: Physical Interfaces

    Figure 1: Kona HazLoc Mega Gateway 1.2 Physical Interfaces Figure 2 details the bulkhead layout for the Kona HazLoc Mega Gateway. Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc. Confidential Page 5 of 19...
  • Page 6 Indicator Port Antenna Port Figure 2: Kona HazLoc Mega Gateway Bulkhead Layout Connector types and their mating connectors are listed in Table 2. Table 2: Kona HazLoc Mega Gateway Interface Connector Types Interface Connector Type Mating Connector LoRa Antenna N-Type female...

  • Page 7: Specifications

    1.3 Specifications The Kona HazLoc Mega Gateway specifications are listed in Table 3. Table 3: Kona HazLoc Mega Gateway Specifications Attribute Specification Dimensions 222 mm (8.7”) wide x 101 mm (4.0”) deep x 287 mm (11.3”) tall Weight 5.4 kg (12 lbs) Operating Temperature -40°C to 60°C (-40°F to 140°F) at sea level Including solar loading...
  • Page 8 II 3 D Ex tc [ic] IIIC T100°C Dc IP67 EN 60079-11 Certificate UL 21 ATEX 2477X EN 60079-31 Temperature -40 °C ≤ Ta ≤ +60 °C Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc. Confidential Page 8 of 19...

  • Page 9: Installation

    Warning - Explosion Hazard! The Kona HazLoc Mega Gateway RF antennas must be limited in gain. The LoRa antenna gain must not exceed 6 dBi. The cellular antenna gain must not exceed 2 dBi.

  • Page 10: Unpacking And Inspection

    (for example, the U.S. National Electrical Code, NFPA 70, Article 810 or the Canadian Electrical Code, Section 54). Warning - The Kona HazLoc Mega Gateway must be installed in a restricted access location (such that touching of the Gateway by non-service persons is not likely).

  • Page 11: Required Equipment For Installation

    2.4 Kona HazLoc Mega Gateway Mounting Kona HazLoc Mega Gateway is designed to be mounted to a vertical pole or wall using a mounting bracket. The mounting bracket is a single part that bolts to the back surface of the Gateway using supplied hardware (four M6x1.0 - 14 mm bolts with flat and star lock washers) as illustrated in...
  • Page 12 Figure 3: Kona HazLoc Gateway Module with Mounting Bracket The Kona HazLoc Mega Gateway wall mounting procedure is as follows: 1. Bolt the wall mounting bracket to the Gateway module using the supplied bolts and washers. 2. Install 2 site supplied M8 bolts into the wall at 139.7 mm (5.5”) center spacing, leaving the bold heads protruding with a 2mm gap from the wall surface.

  • Page 13: Ground Cable Installation

    The Protective Earth Ground conductor terminated at the double hole lug point is mandatory and must be the first connection made to the Kona HazLoc Mega Gateway during installation. Proper routing and termination of this cable is key to robust lightning withstand performance; in high susceptibility installations, every effort shall be made to minimize connection inductance and ground bed resistance.

  • Page 14: Direct Dc Power Cable Installation

    Torque the connector to 0.6 Nm (0.44 ft·lbs). When the DC power connector is not in use, the tethered protective cap must be installed to maintain the required ingress protection. Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc.

  • Page 15: Copper Ethernet Cable Installation

    2.8 LoRa RF Antenna Installation The Kona HazLoc Mega Gateway supports connection to one or two LoRa RF antennas. The LoRa RF antenna attaches through a cable to an N-Type connector located on the bulkhead of the...
  • Page 16 TEKTELIC recommends taping with Scotch Wireless Weatherproofing Kit, WK-101. Follow the taping procedures outlined by the supplier of this tape system. Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc.

  • Page 17: Gps Rf Antenna Installation

    2.9 GPS RF Antenna Installation The Kona HazLoc Mega Gateway supports connection to a GPS RF antenna. The GPS antenna attaches through a cable to the N-Type connector located on the bulkhead of the Gateway. The GPS RF connector shield is grounded to earth through the Gateway’s Earth Ground connection.

  • Page 18: Compliance Statements

    This radio transmitter 22504-T0005158 has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc.
  • Page 19 WARNING: This product can expose you to chemicals including lead, beryllium & nickel, which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. Kona HazLoc Mega Gateway User Guide T0007531_UG Version 2.0 TEKTELIC Communications Inc.
