STORAGE
Refrigerator Storage

GLASS SHELVES

To remove or adjust a glass shelf, tilt up, then lift up and out.
To reposition, insert shelf in the tracks along the back wall,
then lower the front until it locks into position. Refer to the
illustration below.
The stationary glass shelf at the bottom of the compartment
should be placed with beveled edge facing front. Rear sup-
port legs space the shelf away from the back wall to ensure
proper air flow through the unit.
IMPORTANT NOTE: Use care when handling glass shelves to
prevent breakage or scratching the interior.
CAUTION
Glass shelves should warm to room temperature before
immersing in warm water.
Glass shelf removal.

REFRIGERATOR DRAWERS

To remove a refrigerator drawer, pull open until the drawer
stops. Lift the front of the drawer slightly and pull straight
out. To reinstall, pull drawer carrier out and align the bottom
of the drawer with the carrier. Refer to the illustration below.
Dividers in refrigerator drawers can be removed by pulling
straight up. To replace, align tabs on the divider with
notches in the drawer and push down.
Refrigerator drawer removal.
Freezer Storage

FREEZER BASKETS

To remove, pull forward until basket stops. Pull the two
plastic tabs located behind the bottom two corners of the
basket forward, then lift up and out. Refer to the illustrations
below.
If door opening is limited to 90°, the top basket must be
removed before removing the middle or lower basket.
Column | To reinstall, push basket slides in. Align the
basket with slides and push back until it stops. Press down
on the front of the basket to engage slides.
Column combination | To reinstall, fully extend the basket
slides. Align the basket with slides and push back until the
rear of the basket contacts the slide tabs. Push back and
down on the front of the basket to engage with the tabs.
Column freezer basket. Column combination freezer
basket.

ICE CONTAINER

Column | To remove ice container, pull freezer drawer open
until it stops and lift container out. Refer to the illustration
below.
Column combination | To remove ice container, pull freezer
drawer open until it stops and slightly angle the container to
lift out. Refer to the illustration below.
Tall and drawer | To remove ice container, pull freezer
drawer open until it stops and lift container out. Refer to the
illustration below.
The ice maker must be turned off by touching when
the ice storage container is removed. The unit is equipped
with a 3-minute delay after the ice container is removed, to
ensure cubes are not ejected before ice maker can be deac-
tivated or ice container is reinstalled.
Column ice container. Column combination ice
container.
Tall and drawer ice container.
|
