THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES:
1.Inspect equipment before each workout. Check that all nuts, bolts, screws and
2.Keep clear of the cylinder and all moving parts when the machine is in use.
3.Exercise with care. Perform your exercises at a smooth moderate pace; never
4.It is recommended that you should workout with a training partner.
5.Do not allow children or minors to play on or around this equipment.
6.If unsure of proper use of equipment, call your local distributor.
7.WARNING: Consult your physician before starting your exercise program. For your
CRT-1500
pop pins are in place and fully tightened. Also, before use, check cylinders for leaking.
Replace all worn parts immediately. Never use machine if any parts are
damaged or missing. Fallure to follow these rules may result in serious injury.
perform jerky or uncoordinated movements that may cause injury.
own safety do not begin any exercise program without proper instruction.
OWNER'S MANUAL
The Surgeon General
has determined that lack
of physical activity is
detrimental to your health.
TM
Trademark of United States Fitness Produots Council

Advertisement

loading
Need help?

Need help?

Do you have a question about the CRT-1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for SteelFlex CRT-1500

  • Page 1 5.Do not allow children or minors to play on or around this equipment. 6.If unsure of proper use of equipment, call your local distributor. 7.WARNING: Consult your physician before starting your exercise program. For your own safety do not begin any exercise program without proper instruction. CRT-1500 OWNER'S MANUAL...
  • Page 2 CRT-1500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (A1)ROUND ALLEN HEAD M8x16L PARTIAL THREAD QTY.1 (A2)ROUND ALLEN HEAD M8x25L PARTIAL THREAD QTY.2 (A3)HEX HEAD BOLT M10X25L PARTIAL THREAD QTY.2 (A4)ROUND ALLEN HEAD M8x40L PARTIAL THREAD QTY.1 (A5)HEX HEAD BOLT M8X70L PARTIAL THREAD QTY.2 (A6)HEX HEAD BOLT M10X65L PARTIAL THREAD QTY.4...
  • Page 3 CRT-1500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (A7)ALLEN SCREW M5X4L FULL THREAD QTY.6 inch 1" 2" 3" 5" 6" 4" CRT1500-092017 Page...
  • Page 4 CRT-1500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (B1)NYLON LOCK NUT M8 QTY.1 (C5)M8(I.D.)FLAT WASHER Ø18X1.5T QTY.2 (B2)NYLON LOCK NUT M10 QTY.4 (C6)M8(I.D.)FLAT WASHER Ø24X1.6T QTY.5 (C1) 3/8" ROUDN END CAP WASHER QTY.4 (C7)M10(I.D.)FLAT WASHER Ø27X1.6T QTY.4 (C2)M8 SPRING WASHER QTY.4 (C8)1/2" BOLT CAP(9212-024) QTY.4 (C3)M10 SPRING WASHER QTY.2...
  • Page 5 CRT-1500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION D1. Ø16.1XØ8X22.5L STEEL BUSHING(8110-150)----------[1PCS] D2.ROLLER THRUST BEARING(8510-051)-------------------[1PCS] D3.Ø30XØ20X1.5T CU WASHER(8520-007)------------------[1PCS]  35XØ26X19L STEEL BUSHING (8890-079)------------[3PCS] D5. 3" NylON WASHER (9214-008)------------------------------[6PCS]  60X42H DECK BUFFER (9214-037)----------------------[2PCS]  0X80 ROUND END COVER (9261-070)-----------------[2PCS]  0X80 FOOT CAP (9261-071)---------------------------------[1PCS] D9.
  • Page 6 CRT-1500 ASSEMBLY INSTRUCTIONS PARTS ILLUSTRATION SHEET A[1PCS] B[1PCS] C[1PCS] F[1PCS] E[2PCS] D[1PCS] 5584-K008 8386-101 oval 40X80X2TX600L I[1PCS] G[1PCS] H[1PCS] 9121-064 8220-288 8830-018 Ø20X194L J[1PCS] K[3PCS] 9131-068 9161-077 CRT1500-092017 Page...
  • Page 7 CRT-1500 ASSEMBLY INSTRUCTIONS Above shows STEP 1 assembled and completed CRT1500-092017 Page...
  • Page 8 CRT-1500 ASSEMBLY INSTRUCTIONS Above shows STEP 2 assembled and completed STEP 1 CRT1500-042022 Page...
  • Page 9 CRT-1500 ASSEMBLY INSTRUCTIONS Above shows STEP 3 assembled and completed STEP 2 CRT1500-042022 Page...
  • Page 10 CRT-1500 ASSEMBLY INSTRUCTIONS Above shows STEP 4 assembled and completed C6 C2 STEP 3 CRT1500-042022 Page...
