Summary of Contents for Belling BIH90TB
- Page 1 Belling BIH90TB...
-
Page 7: Electrical Shock Hazard
Foreword Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •... - Page 8 • Children or persons with a disability which limits their ability to use the appliance should have a responsible and competent person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to themselves or their surroundings.
-
Page 9: Product Introduction
Health Hazard • This appliance complies with electromagnetic safety standards. • However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will not be affected by the electromagnetic field. -
Page 10: Control Panel
Control Panel 1. Heating zone selection controls 2. Timer control 3. Boost control 4. keylock control 5. ON/OFF control Working Theory Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. -
Page 11: Choosing The Right Cookware
Choosing the right Cookware • Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test. - Page 12 How to use Start cooking 1. Touch the ON/OFF control for a while. After power on, the buzzer beeps once, all displays show “ – “ or “ – – “, indicating that the induction hob has entered the state of standby mode.
- Page 13 Finish cooking 1. Touching the heating zone selection control that you wish to switch off 2. Turn the cooking zone off by touching the slider to ” ”. Make sure the displayshows”0” 3. Turn the whole cooktop off by touching the ON/OFF control.
- Page 14 Cancel the Boost function 1. Touching the heating zone selection control that you wish to cancel the boost function. 2. Touching the "Boost" control to cancel the Boost function, then the cooking zone will revert to its original setting. • The function can work in any cooking zone •...
- Page 15 We don’t recommend other operations except for above mentioned three operations because it might effect the heating of appliance. As two independent zones To use the flexible area as two different zones, you can have two choices of heating. (a) Put a pan on the right up side or the right down side of the flexible zone. (b)Put two pans on both sides of the flexible zone.
-
Page 16: Timer Control
Timer control You can use the timer in two different ways: • You can use it as a minute minder. In this case, it will not turn any cooking zone off when the set time is up. • You can set it to turn one or more cooking zones off after the set time is up. •... -
Page 17: Setting The Timer To Turn One Or More Cooking Zones Off
b) Setting the timer to turn one or more cooking zones off If the timer is set on one zone: 1. Touching the heating zone selection control that you want to set the timer for. 2. Touch timer control , the “10” will show in the timer display. and the “0” flashes. 3. - Page 18 If the timer is set on more than one zone: 1. When you set the time for several cooking zones simultaneously, decimal dots of the relevant cooking zones are on. The minute display shows the min. timer. The dot of the corresponding zone flashes. (set to 15 minutes) (set to 45 minutes) 2.
-
Page 19: Cooking Guidelines
Default working times Another safety feature of the hob is automatic shutdown. This occurs whenever you forget to switch off a cooking zone. The default shutdown times are shown in the table below: Power level Default working timer (hour) When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch off after 2 minutes. -
Page 20: For Stir-Frying
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before serving. For stir-frying 1. Choose an induction compatible flat-based wok or a large frying pan. 2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. -
Page 21: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling on Everyday soiling on glass (fingerprints, • When the power to the cooktop is switched off, there will be no‘hot marks, stains left by food or glass (fingerprints, surface’ indication but the cooking non-sugary spillovers on the glass) marks, stains left by zone may still be hot! Take... - Page 22 The touch controls are The controls are locked. Unlock the controls. See section ‘Using your ceramic cooktop’ for unresponsive. instructions. The touch controls are There may be a slight film of water over Make sure the touch control area is dry and use the ball of your finger the controls or you may be using the tip difficult to operate.
-
Page 23: Failure Display And Inspection
Failure Display and Inspection If an abnormality comes up, the induction hob will enter the protective state automatically and display corresponding protective codes: Problem Possible causes What to do F3-F8 Temperature sensor failure Please contact the supplier. F9-FE Temperature sensor of the IGBT failure. Please contact the supplier. - Page 24 Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm.
-
Page 25: Before Locating The Fixing Brackets
Before locating the fixing brackets • The work surface is square and level, and no structural members interfere with space requirements. • The work surface is made of a heat-resistant and insulated material. • If the hob is installed above an oven, the oven has a built-in cooling fan. •... - Page 26 Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The hob will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the hob electronics 3.
-
Page 27: Technical Specification
• The cable must be checked regularly and replaced by authorised technicians only. The bottom surface and the power cord of the hob are not accessible after installation. Technical Specification Cooking Hob BIH90TB Cooking Zones 5 Zones Supply Voltage 220-240V~ 50/60Hz... -
Page 28: Information For Domestic Electric Hobs
Information for domestic electric hobs Symbol Value Unit Model identification BCH60RB Type of hob Built-in hob Number of cooking zones and/or areas 4 zones Heating technology(induction cooking zones and induction cooking zones cooking areas,radiant cooking zones,solid plates) zone 1: 18,0 For circular cooking zones or area:diameter of zone 2: 18,0 useful surface area per electric heated cooking...
