- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE B7659 Owner's Manual Shop genuine replacement parts for FISHER PRICE B7659 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 Product features may vary from the picture above. Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers and Safety Scissors (tools not included). Use only with a Power Wheels ®...
-
Page 3: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior floor- independently owned and operated Authorized Service ing can be damaged by riding this vehicle indoors. Center Network with more than 400 authorized service Fisher-Price ® will not be responsible for damage to centers nationwide. The authorized service centers will the floor if the vehicle is used indoors. -
Page 4: Warnings And Cautions
Warnings and Cautions ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 6 Parts #8 x 4" Screw – 2 Key Assembly #10 x 1" Screw – 7 #8 x 1" Screw – 7 #10 x " Screw – 8 #8 - 32 x 1.625" Screw – 2 #8 Lock Nut – 2 Hood Latch –...
-
Page 7: Parts Diagram
Parts Diagram Note: Some parts shown are assembled on both sides of the vehicle. No. Part Quantity No. Part Quantity No. Part Quantity Vehicle Body #10 x 1" Screw Hood Steering Column #10 x " Screw Spacer .354 Cap Nut #8 x 4"... -
Page 8: Battery Charging
Battery Charging About Thermal Fuses ELECTRICAL HAZARD Your Power Wheels ® 12 volt battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting WARNING safety device which automatically “trips” and shuts down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. -
Page 9: Assembly
Battery Charging Assembly WARNING Battery Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. - Page 10 Assembly Battery Clamp Unit Labels - Dash • Before applying the labels, wipe the surface of the • Insert two #10 x 1" screws through the holes in the vehicle with a clean, dry cloth to remove any dust or oils. battery clamp unit and into the pegs in the dash.
- Page 11 Assembly End of Dash Key Assembly Steering Column Steering Cap Nut .354" Dash View Bottom View .354 Cap Nut • Insert and “snap” the key assembly into the opening in • Insert the end of the steering column through the hole the dash, as shown.
- Page 12 Assembly Steering Wheel Wide Tab Steering Column Lens Wide Notch Lens Guard “UP” • Fit the wide notch in the side of a headlight lens under .354" the wide tab on a lens guard. • Press firmly on the inside of the headlight lens to snap it into the lens guard.
- Page 13 Assembly Windshield Hood Latch Wipers Slot Large Large Large Slots Hood Latch Slot • Position the windshield so that the wipers face the front • Insert a hood latch into one of the slots in the vehicle end of the vehicle. body, near the hood area.
- Page 14 Assembly Spacers Long Seat Belt Strap T-Loop Fastener End Grille • Insert each fastener end of the long seat belt strap through a slot in the center of the seat. Make sure the fasteners face the outer edge of the seat. •...
- Page 15 Assembly Lights Light Covers Dash View • Insert a #8 x 1" screw into the rear of seat, as shown. • Tighten the screw with a Phillips screwdriver. Do not over-tighten. • Fit the light covers to the lights on the sport bar, as shown. "...
- Page 16 Assembly Taillight Housing Sport Bar Support PUSH HERE Side Taillight Fender Lens #8 x 1" Screws • Turn the vehicle upright. PULL HERE • Using safety scissors, remove the taillight lenses and the taillight housings from the plastic connectors. Dispose of the plastic connectors.
-
Page 17: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... - Page 18 Label Decoration Right Side View Left Side View...
-
Page 19: Battery Installation
Battery Installation Battery Battery IMPORTANT! Use only a Power Wheels ® 12 volt battery. Battery Clamp Use of any other battery will damage your vehicle. Make Compartment sure that you charge the battery for at least 18 hours using the enclosed Power Wheels 12 volt charger before ®... -
Page 20: Battery Care And Disposal
Battery Care and Disposal Disposal Care If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid acid and place the damaged battery in a plastic bag. Please battery. It must be recycled or disposed of in an refer to the information on this page for proper disposal. -
Page 21: Rules For Safe Driving
Rules for Safe Driving RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required. • Keep Children Within Safe Riding Areas Use vehicle on generally level ground ONLY! These areas must be: - away from swimming pools and other 7. -
Page 22: How To Operate Your Vehicle
How to Operate Your Vehicle To Back Up Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). It has been pre-set so it will only operate in low speed. After your child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to remove the high speed lock-out screw to allow the vehicle to operate in low or high speed. -
Page 23: Caring For Your Vehicle
How to Operate Your Vehicle Caring For Your Vehicle Advanced Use - High Speed Drive • Check all screws, cap nuts and protective coverings Disconnecting the High Speed Lock-Out regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. •... -
Page 24: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. - Page 25 Problems and Solutions Guide Problem Possible Cause Solution Short run time (Less than Undercharged battery Charge the battery. A new battery should have been 1 - 3 hours per charge) charged for at least 18 hours before using the vehicle for the first time.
- Page 26 Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs in low speed, but High speed lock-out not disconnected The vehicle was pre-set to run only in low speed. does not run in high speed To allow the vehicle to run in low and high speed, you must disconnect the High Speed Lock-Out.
-
Page 27: Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ®... - Page 29 For the location nearest you, visit us on-line at www.powerwheels.com. Fisher-Price, Power Wheels, and Power Wheels by Fisher-Price, Power Lock and Power Stick are U.S. trademarks of Mattel, Inc. ©2003 Mattel, Inc. All Rights Reserved. ® and ™ are registered trademarks of Mattel Inc.
