Summary of Contents for Fisher-Price POWER WHEELS Jeep Wrangler

Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 78538 Owner's Manual Shop genuine replacement parts for FISHER PRICE 78538 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
Page 2 Product features may vary from the picture above. Jeep Wrangler ® Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 78538 Tools needed for assembly: Phillips Screwdriver, Hammer, and Safety Scissors. Use only with Power Wheels ®...
Page 3: Table Of Contents
Table of Contents Important Information ..............2 Warnings .
Page 4: Warnings
Warnings WARNING • Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the batteries, or help in assembly of the vehicle.
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
Page 6 Parts #10 x 3" Screw – 2 Hood Latch – 2 Dashboard Knob – 2 " x " Machine Screw - 2 #8 x 1" Screw – 11 Key Assembly #10 x " Screw – 2 #10 x 1" Screw – 2 Knob Plate 30 Amp Fuse –...
Page 7: Parts Diagram
Parts Diagram...
Page 8: Parts List
Parts List Part Quantity Part Quantity Vehicle Body Steering Wheel Steering Wheel Cap Steering Column .354 Cap Nut Seat Hood Latch Long Seat Belt Strap Short Seat Belt Strap 6 Volt Battery Battery Retainer Headlight Lens 30 Amp Fuse Lens Guard Taillight Lens Hood Windshield...
Page 9: Battery Charging
Battery Charging WARNING • The batteries must be handled by adults only. The batteries are heavy and contain sulfuric acid (electrolyte). Dropping the batteries could result in serious injury. • Never allow children to charge the batteries. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the batteries.
Page 10 Battery Charging • Your new batteries must be charged for at least 18 hours before you use them in your vehicle for the first time. Charger • We recommend that you start charging your batteries before beginning assembly of your new vehicle. •...
Page 11: Assembly
Assembly Do not omit any steps. Please set aside at least 45 minutes for assembly. Dash Dash Knob Plate Pocket Key Assembly Channel Cover Microphone T-End Cord • Bend the end of the microphone cord so that it forms a “T”. •...
Page 12 Assembly End of Steering Column Steering Wheel Steering Wheel Steering Rod Cap Nut Bottom View • Fit the steering wheel cap into the center of the steering wheel with the screw holes aligned. • Insert the end of the steering column through the hole in •...
Page 13 Assembly Hood Grille Slots Tabs Tabs Slot Slot • Fit the lens tabs on the back of a lens assembly into the headlight slots in the grille. • Press firmly to snap the lens assembly into the grille. • Position the hood over the front of the vehicle body •...
Page 14 Assembly Short Seat Windshield T-Loop (Pull through slot) Belt Strap Slots Fastener End Slots T-Loops #10 x 3" Screw #10 x 3" Screw Slot Seat Bracket Slot • Turn the seat upside down. • Insert the fastener end of a short seat belt strap through the slot near the outer edge of the seat.
Page 15 Assembly Seat Sport Bar Bracket Seat Back Tabs Ring Tabs PUSH Sport Bar HERE Sport Bar Support Hole Slot Side Leg • Using safety scissors, remove the sport bar brackets from the plastic connector. Dispose of the plastic • With the seat at an angle, insert the tabs on the front connector.
Page 16 Assembly Light Rack - Back Half Sport Bar PUSH Tabs HERE Sport Bar Support Side Fender Sport Bar PULL HERE Light Rack - Front Half • Place the sport bar and sport bar support legs into the holes in the vehicle body. •...
Page 17 Assembly Taillight Housing Taillight Lens • Using safety scissors, remove the taillight lenses and the taillight housings from the plastic connectors. Dispose of the plastic connectors. • Face the rear of the vehicle. • Fit a taillight lens inside a taillight housing. •...
Page 18: Label Decoration
Label Decoration Proper label application will help to keep the labels look- ing their best! When applying labels, keep the following guidelines in mind: ® • Wash your hands before applying the labels. BATTERY POWERED BATTERY POWERED RECHARGEABLE RECHARGEABLE FWD /REV FWD /REV 2 SPEED 2 SPEED...
Page 19: Battery Installation
Battery Installation Important Note: Use only Power Wheels Type H batteries ® with Power Wheels ® 30 amp fuses installed. Use of any Small End other batteries or fuses will damage your vehicle. Make sure that you charge the batteries for at least 18 hours using the enclosed Power Wheels ®...
Page 20: Battery Care And Disposal
Battery Installation Battery Care and Disposal Care If a battery leak develops, avoid contact with the leaking Hood acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
Page 21: Rules For Safe Driving
Rules for Safe Driving • While driving across a steep slope, the vehicle may tilt and tip over. The wheels could lose traction, WARNING causing the vehicle to slip. • While driving up a steep incline, the motor may • Adult supervision is required. Children do stop and the vehicle could roll backwards at an not have the judgement necessary to avoid unsafe speed.
Page 22: How To Operate Your Vehicle
How to Operate Your Vehicle Beginner Use - Low Speed Drive To Back Up As assembled, your vehicle is ready to roll in low speed mph, maximum). It has been pre-set so it will only operate in low speed. After your child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to disconnect the high speed lock-out to allow the vehicle to operate in low or high speed.
Page 23: Caring For Your Vehicle
How to Operate Your Vehicle Caring For Your Vehicle Advanced Use - High Speed Drive • Check all nuts, bolts, and their protective coverings Disconnecting the High Speed Lock-Out regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. •...
Page 24: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Affairs, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center.
Page 25 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery suddenly stopped connector is tightly plugged into the motor harness connector and that there are no loose wires around the motors.
Page 26 Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs sluggishly Undercharged batteries Charge the batteries. New batteries should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the batteries for at least 14 hours after each use.
Page 27 Problems and Solutions Guide Problem Possible Cause Solution When the foot pedal is pressed, Loose wire or connector Check all wires around the motors and all connectors the vehicle won’t run without to make sure they are tight. a push “Dead Spot”...
Page 28: Statement Of Limited Warranty
Statement of Limited Warranty 90-day limited warranty for the Power Wheels ® not cover, and is intended to exclude, any liability on the part of Power Wheels , whether under this warranty or ® Ride-On Toy Vehicle implied by law or any indirect or consequential damages for A 6-month battery warranty applying only to breach of warranty.
Page 29 Authorized Service Centers NORTH FORT MYERS - Family Hardware,13817 SAN JOSE - California Electric Service Center, HAWAII N. Cleveland Ave., 33903, (941) 995-6161 481 So. Bascom, 95126, (408) 295-1723 HONOLULU - McCully Bicycle & Sporting Goods, NORTH PALM BEACH - Appliance Doctors, SANTA ANA - California Electric Service Center, 2025 932 Hausten Street, 96826, (808) 946-1192 450 Northlake Blvd., 33408, (407) 845-0377,...
Page 30 Authorized Service Centers KANSAS MASSACHUSETTS JACKSON (RIDGELAND) - Propeller Service, 291 Hwy. 51, Suite D6, 39157, (601) 856-3191 COLBY - Gavon’s Electronics, 1870 South Range, BOSTON (MEDFIELD) - Wills Hardware, 5 Janes 67701, (913) 462-6601 MERIDIAN - Broadmoor Home Center, Avenue, 02052, (508) 359-4381 2420 Old North Hills Street, P.O.
Page 31 Authorized Service Centers TOMS RIVER - South Jersey TV Service, Inc., PHILADELPHIA - Appliance Care/Service Corp., 6407 STATESVILLE - First Flight Bicycles, 216 S. Center St., Stella Towne Center, 1258 Route 166, 08753, Rising Sun Ave., 19111, (215) 725-3112 28677, (704) 878-9683 (908) 505-1771 PHILADELPHIA (COLLINGDALE) - J.F.
Page 32 Authorized Service Centers TEXAS SAN ANTONIO - Brand Service Center, 7065 San WASHINGTON Pedro Avenue, 78216, (210) 344-8577 ABILENE - Metro Small Appliance Service Co., SEATTLE - Ajax Electric, 2911 First Avenue South, SEYMOUR - Western Auto, 211 N. Main Street, 76308, 141 S.
Page 33 Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission. ©1998 Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 - All Rights Reserved Printed in the U.S.A.
