This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 74020 Owner's Manual Shop genuine replacement parts for FISHER PRICE 74020 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
Page 2
Product features and decoration may vary from the picture above. Jeep Wrangler ® Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74020 Tools needed for assembly: Phillips Screwdriver, Hammer, and Safety Scissors (not included). Use only with a Power Wheels 12 Volt Lead-acid Rechargeable Battery and ®...
Warnings WARNING • Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
Page 6
Parts " x " Machine Screw - 2 Dashboard Knob – 2 Hood Latch – 2 #8 x 1" Screw – 11 #8 x 1 " Screw – 10 #10 x " Screw – 2 #10 x 1" Screw – 2 Key Assembly Knob Plate #6 x 1...
Page 8
Parts Diagram Part Quantity Part Quantity Steering Wheel Vehicle Body Steering Column Steering Wheel Cap .354 Cap Nut Seat Hood Latch Long Seat Belt Strap Short Seat Belt Strap 12 Volt Battery Battery Retainer Headlight Lens Light Cover Lens Guard Taillight Lens Hood Windshield, Front...
Battery Charging About Thermal Fuses WARNING Your Power Wheels ® 12 volt battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting • The battery must be handled by adults safety device which automatically “trips” and shuts down operation of the vehicle if the vehicle is overloaded or the only.
Page 10
Battery Charging Important Notes • Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time. • You do not need to remove the battery from your vehicle to recharge it. Battery •...
Assembly Dash Dash Knob Plate Pocket Key Assembly Channel Cover Microphone T-End Cord • Bend the end of the microphone cord so that it forms a “T”. • Position the dash on the vehicle body. Make sure the • Insert the end of the microphone cord through the square holes in the dash tabs align with the holes in the vehicle opening in the dash pocket.
Page 12
Assembly Steering Wheel Hole Steering Column Cap Nut Steering Column “UP” Bottom View • Turn the vehicle body upright. • Wipe the steering column with a paper towel to remove • Position the steering wheel so that the spokes form a any excess lubricant.
Page 13
Assembly Wide Tab Wide Notch Hood Latch Lens Hole Lens Guard Hood • Fit the wide notch in the side of a headlight lens under Latch the wide tab on a lens guard. Hole • Press firmly on the inside of the headlight lens to snap it •...
Page 14
Assembly Windshield #8 x 1" Screws #8 x 1" Screws Hinge Pin Frame - Windshield Front Half Brackets Windshield Bracket Lip of Bracket • Rotate the front half of the windshield frame down so it Slot lays flat on the vehicle body. •...
Page 15
Assembly Short Seat T-Loop (Pull through slot) Belt Strap Seat Seat Back Tabs Fastener End T-Loops Tabs Slot PUSH HERE Seat Slot Slot • Turn the seat upside down. • Insert the fastener end of a short seat belt strap through the slot near the outer edge of the seat.
Page 16
Assembly Light Rack - Back Half Sport Bar Bracket Tabs Ring Sport Bar Sport Bar Support Sport Bar Hole Light Rack - Side Leg Front Half • Using safety scissors, remove the sport bar brackets • Position the sport bar with the ends on a flat surface, from the plastic connector.
Page 17
Assembly Taillight Sport Bar Housing PUSH HERE Side Fender Taillight Lens PULL HERE • Using safety scissors, remove the taillight lenses and the taillight housings from the plastic connectors. Dispose of the plastic connectors. • Face the rear of the vehicle. •...
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: ® • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.
Battery Installation Important Note: Use only a Power Wheels ® 12 volt battery. Use of any other battery will damage your vehicle. Make Battery Retainer sure that you charge the battery for at least 18 hours using Looped End the enclosed Power Wheels ®...
Battery Care and Disposal Battery Installation Care Hood If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
Rules for Safe Driving • While driving across a steep slope, the vehicle may tilt and tip over. The wheels could lose traction, WARNING causing the vehicle to slip. • While driving up a steep incline, the motor may stop •...
How to Operate Your Vehicle To Back Up Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). It has been pre-set so it will only operate in low speed. After your child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to remove the high speed lock-out screw to allow the vehicle to operate in low or high speed.
How to Operate Your Vehicle Caring For Your Vehicle Advanced Use - High Speed Drive • Check all screws, retainers and protective coverings Disconnecting the High Speed Lock-Out regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. •...
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Affairs, toll- free at 1-800-348-0751 between 8 AM and 5 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center.
Page 25
Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the motor suddenly stopped harness connector is plugged into the battery, and that there are no loose wires around the motors. Tripped thermal fuse Each Power Wheels ®...
Page 26
Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use.
Page 27
Problems and Solutions Guide Problem Possible Cause Solution When the foot pedal is pressed, Loose wire or connector Check all wires around the motors and all connectors the vehicle won’t run without to make sure they are tight. a push “Dead Spot”...
Bumper-to-Bumper* Limited Warranty not cover, and is intended to exclude, any liability on the *One year limited warranty from the date of part of Power Wheels , whether under this warranty or ® purchase on the Power Wheels ® vehicle. implied by law or any indirect or consequential damages for Six month limited warranty on the breach of warranty.
