This Owner's Manual is provided and hosted by Appliance Factory Parts.
FISHER PRICE 75840
Owner's Manual
Shop genuine replacement parts for FISHER PRICE
75840
Find Your FISHER PRICE Ride On Parts - Select From 999 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 75840 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher-Price 75840

Summary of Contents for Fisher-Price 75840

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 75840 Owner's Manual Shop genuine replacement parts for FISHER PRICE 75840 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
  • Page 2 Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission. Fisher-Price, Power Wheels, Power Wheels by Fisher-Price, Power Lock and Power Stick are U.S. trademarks of Mattel, Inc. www.powerwheels.com...

  • Page 3: Table Of Contents

    • Use this vehicle ONLY outdoors. Most interior floor- Estados Unidos. Tenemos representantes que hablan ing can be damaged by riding this vehicle indoors. español para atender su llamada. Fisher-Price ® will not be responsible for damage to • For your convenience, Power Wheels ®...

  • Page 4: Warnings And Cautions

    Warnings and Cautions ELECTRICAL HAZARD WARNING • Batteries can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.

  • Page 5: Parts

    Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
  • Page 6 Parts #8 x 1 " Screw – 10 #10 x 1" Screw – 7 #10 x " Screw – 2 " x " Machine Screw - 2 #6 x 1 " Screw – 4 #8 x 1" Screw – 11 .354 Cap Nut –...

  • Page 7: Parts Diagram

    Parts Diagram Note: Some parts shown are assembled on both sides of the vehicle.
  • Page 8 Parts Diagram Part Quantity Part Quantity Long Seat Belt Strap Vehicle Body Short Seat Belt Strap Steering Column .354 Cap Nut Headlight Lens Hood Latch Lens Guard Hood 12 Volt Battery Battery Clamp Unit Windshield, Front Light Cover Windshield, Back Taillight Lens Sport Bar Sport Bar Support...

  • Page 9: Battery Charging

    Battery Charging ELECTRICAL HAZARD About Thermal Fuses WARNING Your Power Wheels ® 12 volt battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting safety device which automatically “trips” and shuts down • Batteries can fall out and injure a operation of the vehicle if the vehicle is overloaded or the child if vehicle tips over.

  • Page 10: Assembly

    Battery Charging Assembly WARNING Battery Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
  • Page 11 Assembly Battery Clamp Unit Dashboard Knobs Knob Plate • Insert and snap the dashboard knobs into the knob plate. Note: Gently squeeze the tabs on the knobs together before inserting the knobs into the knob plate. • Insert two #10 x 1" screws through the holes in the battery clamp unit and into the pegs in the dash.
  • Page 12 Assembly End of Steering Column HEAT COOL Steering Rod Cap Nut Bottom View Dash View • Insert the end of the steering column through the hole in the steering rod. • Before applying labels to the dash, wipe the dash with a •...
  • Page 13 Assembly Steering Wheel Hood Latch Steering Wheel Hole Hood • Fit the steering wheel cap into the center of the steering wheel with the screw holes aligned. Latch • Insert two #8 x 1" screws as shown. • Tighten the screws with a Phillips screwdriver. •...
  • Page 14 Assembly Windshield Brackets Lip of Bracket Brush Guard Front Bumper Slot • Fit and hold the brush guard against the front bumper. • Insert two #10 x 1" screws through the front of the brush • Fit the screw pegs on the windshield brackets into the guard and into the front bumper.
  • Page 15 Assembly Short Seat T-Loop (Pull through slot) Windshield Frame Hinge Pin Belt Strap Front Half Windshield Fastener End Bracket T-Loops Seat Slot • Turn the seat upside down. • Rotate the front half of the windshield frame down so it lays flat on the vehicle body.
  • Page 16 Assembly Seat Sport Bar Bracket Seat Back Tabs Tabs Ring PUSH Sport Bar HERE Sport Bar Support Slot Side Leg • Using safety scissors, remove the sport bar brackets from the plastic connector. Dispose of the • With the seat at an angle, insert the tabs on the front plastic connector.
  • Page 17 Assembly Light Rack - Back Half Slots Light Covers Tabs Housing Sport Bar Light Rack - Front Half • Align the four tabs on the inside of a light cover • Position the sport bar with the ends on a flat surface, with the four slots in one of the light housings on the as shown.
  • Page 18 Assembly Taillight Housing Rear Wheel Well Taillight Lens • Using safety scissors, remove the taillight lenses and the taillight housings from the plastic connectors. Dispose of the plastic connectors. • Face the rear of the vehicle. • Fit a taillight lens inside a taillight housing. "...

  • Page 19: Label Decoration

    Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.

  • Page 20: Battery Installation

    Battery Installation Battery Battery Important Note: Use only a Power Wheels ® 12 volt battery. Battery Clamp Use of any other battery will damage your vehicle. Make Compartment sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®...

  • Page 21: Battery Care And Disposal

    Battery Care and Disposal Care Disposal If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid acid and place the damaged battery in a plastic bag. See battery. It must be recycled or disposed of in an information below for proper disposal.

  • Page 22: Rules For Safe Driving

    Rules for Safe Driving RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required • Keep Children Within Safe Riding Areas These areas must be: - away from swimming pools and other Use vehicle on generally level ground ONLY! bodies of water to prevent drownings - generally level to prevent tipovers 7.

  • Page 23: How To Operate Your Vehicle

    How to Operate Your Vehicle IMPORTANT! Use the vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price ® will not be responsible for damage to floors if vehicle is used indoors. To Back Up...

  • Page 24: Caring For Your Vehicle

    How to Operate Your Vehicle Caring For Your Vehicle Advanced Use - High Speed Drive • Check all screws, capnuts and protective coverings Disconnecting the High Speed Lock-Out regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. •...

  • Page 25: Problems And Solutions Guide

    Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Affairs, toll- free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center.
  • Page 26 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the motor suddenly stopped harness connector is plugged into the battery, and that there are no loose wires around the motors. Tripped thermal fuse Each Power Wheels ®...
  • Page 27 Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use.

  • Page 28: Fcc Statement (United States Only)

    Problems and Solutions Guide Problem Possible Cause Solution When the pedal is pressed, Loose wire or connector Check all wires around the motors and all connectors the vehicle won’t run without to make sure they are tight. a push “Dead Spot” on motor Contact your local Power Wheels ®...

  • Page 29: Limited Warranty

    Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ride-on vehicle (purchased from Power ®...
  • Page 30 Authorized Service Centers BOYNTON BEACH - Palm Beach Vacuum, Inc., SAVANNAH - Hagins Appliance Service, DUBUQUE - Shaver’s Plus, 450 Central Avenue, 52001, 1865 W. Woolbright Road, 33425, (561) 243-9999 3 West Victory Drive, 31405, (912) 233-8372 (319) 556-4442 CALLAHAN -Arc Electronic Repair, 951 Blackhills Dr., THOMASVILLE - Carroll Hill Auto, FT DODGE - Messerly Electronics, 614 1st Avenue Suite D, 32011, (904) 879-3556...
  • Page 31 Authorized Service Centers LOVEVILLE - Hancock Refrigeration Co Inc., 28650 MISSOURI HOWARD BEACH- Crossbay Appliance Service, Point Lookout Rd, 20656, (301) 475-8298 158-34 Crossbay Blvd, 11414, (718) 843-4422 GLADSTONE - Mar-Beck Appliance Service Co., HUDSON - Sweeps Vacuum & Repair Center, Inc., MASSACHUSETTS 6559 North Oak Traffic Way, 64118, (816) 436-9191 705 Warren Street, 12534, (518) 828-5457...
  • Page 32 Authorized Service Centers TOLEDO - Mr. Appliance of Toledo Inc., SOUTH CAROLINA WICHITA FALLS - Allens Appliance Service, 1621 Broadway, 43609, (419) 241-9731, 2403 10th Street, 76309, (940) 766-2635 AIKEN - Dunagan’s Sewing & Vacuum, (800) 436-5415 1536 Whiskey Road, 29803, (803) 649-6777 UTAH WELLINGTON - Travelite Inc., 750 Industrial Avenue, BELTON - American Pro Office Equipment,...
  • Page 33 Authorized Service Center. For the location nearest you, refer to the Authorized Service Center list in this manual. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. ©2001 Mattel, Inc. All Rights Reserved. Printed in the U.S.A.
