lumishore eclipse Courtesy Light CL30 Installation Manual

eclipse
60-0480 - Courtesy Light - Blue and White | 60-0572 - Courtesy Light - RGB
Before you start...
• Always ensure that the vessel's power source and battery are disconnected or isolated prior
to installation.
• A qualified professional should carry out both the electrical and mechanical installation.
• The ECLIPSE Courtesy light Is designed to be used in conjunction with a simple On/Off switch
or used with the ECLIPSE Command Center. Do not connect to any other 3rd party lighting
control products or dimmers.
• The ECLIPSE Courtesy light is fully sealed and can be installed inside or outside, it can be
installed in wet areas but is not designed to be permanently submerged in water.
• Choose a location – the light must be mounted on a flat – not curved surface.
• The ECLIPSE Courtesy light CL30 is designed to work with 12V boats ONLY. It can operate
between 10-15Volts DC. Do not connect voltages outside of this range or connect directly
to AC voltage.
Lumishore UK Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR | +44(0)1792 398500 | Info@Lumishore.com
Lumishore USA 7137 24TH Court East Sarasota, Florida 34243 | (941) 405-3302 | Sales@LumishoreUSA.com
Courtesy Light CL30 Installation Guide
60-0478 - Courtesy Light - Blue | 60-0479 - Courtesy Light - White
Please read the following pages before attempting installation
45-0199-Rev 3
