lumishore LUX Strip Light SL180 Installation Manual

LUX Strip Light SL180 (IP68) CRGBW (Cut and Seal) Installation Guide
LUX Strip Light SL180 (IP68) CRGBW (Cut and Seal) Installation Guide
Full spectrum color tunable lighting, including cold and warm white light

Before you start...

• Always ensure that the vessel's power source and battery are disconnected or isolated prior
to installation.
• A qualified professional should carry out both the electrical and mechanical installation.
• The Lux Strip Light Is designed to be used in conjunction with the Lumishore Lux Strip Light
Driver modules (see diagram below). Do not connect to any other 3rd party lighting control
products or drivers.
• The lux Strip Light must be cut and sealed prior to installation. Failure to follow the
instructions in this manual will invalidate the warranty. Only sealant supplied is to be used.
• The lux Strip Light is fully sealed and can be installed inside or outside, it can be installed in
wet areas but is not designed to be permanently submerged in water.
• Choose a location – the Strip Light is made from UV resistant material but should not be
installed in areas of strong direct sunlight.
• The Strip Light has a bend radius of 50mm in the vertical axis, do not bend in the horizontal
axis or twist the Strip Light.
Lumishore UK Unit 3, Technium 1, Kings Road, Swansea, SA1 8PH, UK | +44(0)208 144 1694 | Info@Lumishore.com
Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com
Please read the following pages before attempting installation to ensure
complete understanding of the LUMISHORE Strip Lights
45-0181-Rev2
1
