EOS MINI / EOS MINI WIFI
The Lumishore Color Change system takes the concept of marine underwater lighting installations to new
levels of brightness, color and underwater experience. The innovative EOS Mini / EOS Mini WiFi allows the
boat owner to achieve unrivalled levels of color options and lighting modes over the full color spectrum.
The Color Controller allows you to choose and easily adjust your light color, and by scrolling through the
various inbuilt lighting modes, you can select from a number of predefined colors, color cycle sequences. The
Controller also incorporates fish attraction modes with variable strobe rates to enhance your fishing trip or sea
life observation requirements.
Color cycles and color sweeps bring dynamic moving light scenes to the boat. The EOS Mini WiFi controller has
built in WiFi. This allows you to control your lights from your iPhone or iPad using the Lumishore App, which
mimics the controller on you mobile device.
For the ultimate party boat, The EOS Mini Controller has built in sound to light capabilities. The lights can be
setup to synchronise their color change with the beat and frequency of your favourite music.
Note: Refer to the relevant light installation instructions for how to install the lights onto your boat, and how
to connect the system together.
PN: 45 – 0050 Rev 2
Advertisement
Table of Contents
Related Manuals for lumishore EOS Mini
Summary of Contents for lumishore EOS Mini
- Page 1 For the ultimate party boat, The EOS Mini Controller has built in sound to light capabilities. The lights can be setup to synchronise their color change with the beat and frequency of your favourite music.
- Page 2 1.0 EOS MINI / EOS MINI WIFI COLOUR CHANGE CONTROLLER INSTALLATION EOS CONTROLLER COMPONENTS: Mounting EOS Mini / EOS Mini WiFi Nuts Colour Controller Protective Sun Cover Mounting Bracket 1.1 EOS MINI / EOS MINI WIFI MECHANICAL INSTALLATION The Color Controller has been designed to be mounted inside or outside within the cockpit or dash board of the vessel.
- Page 3 The controller uses a proprietary form of DMX to communicate between the lights and controller. Whilst Lumishore lights can be controlled by any DMX controller, the EOS controller can only be used to control Lumishore product. The Color Controller is plugged into the first Lumi-Hub in the series.
- Page 4 Do not connect the external DMX wires to anything other than an external DMX module. If an external DMX module is not used then the DMX wires should be cut back and insulated to prevent a short circuit on the wires. EOS MINI / EOS MINI WIFI Overview and Basic Operation Back Button...
- Page 5 Starboard side. At each stage note the number of each light in accordance with these schematics. Example Positions Transom Only Position 3 Position 2 Position 1 Example Positions for 5 lights Position 1 Position 5 Position 2 Position 4 Position 3 www.Lumishore.com...
- Page 6 Select button to save the vessel. the settings. The next light will start to flash a color Repeat these steps until all lights have been sequence of “Blue , Green and Red” Light Setup is now Complete! assigned the correct position. www.Lumishore.com...
- Page 7 Ice blues – Whites, Blues and Greens · Sunset – Reds and Ambers · Miami – Blues and Reds Press the select button to start the sweep, use the up and down arrows to adjust the speed of sweep. www.Lumishore.com...
- Page 8 Using wifi mode allows you to control your lights using an iPhone, or iPad via the Lumishore App, or by using a third party DMX software such as “Luminair” or “Alcorn McBride inc LightingPad” Note: For this mode to function the iPhone or iPad will need to be set up first. See section iPad / iPhone setup.
- Page 9 Note, if the input music is supplied by a stereo that does not a have a fixed line level output then the sound to light sensitivity will be dependent on music volume. If little or no lighting effect is observed ensure the volume of the stereo is turned up to a high enough level. www.Lumishore.com...
- Page 10 To configure the iPhone / iPad refer to the next section. 5.3 Display Settings The screen colours can be changed from normal (Black text on white background) to inverse (White text on black background) by pressing the select button www.Lumishore.com...
- Page 11 6.0 EOS MINI WIFI - iPhone / iPad Pairing To control the lights using an iPhone or iPad the device first has to be configured to link with the EOS Mini WiFi. This setup only needs to be carried out once per device. The following guide shows how to pair the controller with an iPhone device.
- Page 12 Use your phone to control your lights to their full capability with the new, four channel, control EOS App from Lumishore. The Lumishore EOS App is designed for iPad and iPhone control of the Lumishore EOS Color change system installed on boats with Lumishore EOS Color controllers (with WiFi option).
- Page 13 United Kingdom +44(0)208 144 1694, or France +33(0)493 582 537. LUMISHORE Ltd warrants the EOS Controller to be free from defects in workmanship and materials for a period of two years, starting from the date of original purchase. Misuse, abuse, improper...
