lumishore Curved 20 Installation Manual

Spotlight - Curved Installation Manual
Please read the following pages before attempting installation to ensure complete understanding of
Lumishore Spotlight - Curved. This product should only be installed, inspected, and maintained by a
qualified electrician only, in accordance with all applicable electrical codes. Be certain electrical power
is OFF before and during installation and maintenance.
What's Included
10
Basic Dimensions
Model of Light
20"
30"
40"
50"
Lumishore UK Unit 3, Technium 1, Kings Road, Swansea, SA1 8PH, UK | +44(0)208 144 1694 | Info@Lumishore.com
Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com
2
1
5
6
3
9
E
D
A
92mm
92mm
92mm
92mm
3
4
3
7
8
B C
96mm 44°
111mm 44°
132mm 44°
158mm 44°
FOR REFERENCE ONLY
45-0189-RevD
Item
(1)
Spotlight - Curved
(2)
M6 x 40mm Hex Bolt
(3)
M6 Flat Washer
(4)
M6 x 16mm Hex Bolt
(5)
M6 Nylon Washer
(6)
Bracket
(7)
Flat Plate
(8)
M6 Spring Washer
(9)
M6 Nylon Insert Nut
(10)
Bracket Drill Jig
B
A
C
D E
573mm 498mm
823mm 749mm
1070mm 999mm
1315mm 1246mm
