lumishore Eclipse SMX23 Installation Manual

eclipse
60-0490 - SMX23 - Blue | 60-0491 - SMX23 - White | 60-0313 - SMX23 - Blue and White
Please read the following pages before attempting installation to ensure complete understanding of
Lumishore ECLIPSE SMX23. This product should only be installed, inspected, and maintained by a qualified
electrician only, in accordance with all applicable electrical codes. Be certain electrical power is OFF before
and during installation and maintenance.
Color Output
Single and dual color

Before you start:

• Always ensure that the vessel's power source and battery are disconnected or isolated prior to installation.
• A qualified professional should carry out both the electrical and mechanical installation.
• For best underwater illumination, LUMISHORE recommends installation 4" to 12" (100-300mm) below the
minimum load water line.
• Choose a location - The light must be mounted on a flat (not curved) surface. For underwater installs mount
on transom or side hull only.
• A hole will be drilled to allow the cable to be inserted; care must be taken to ensure there is unrestricted
access inside the hull.
• When installing three or more lights, equal spacing 2.5'- 3' is recommended to give a consistent light pool.
• The light is temperature sensitive and must not be located close to the exhaust outlet or other heat source.
• SMX 23 Lights operate on 12V DC ONLY. Never connect a light directly to the mains AC voltage, or DC voltage
other than that specified.
• Each light should be individually fused with a 4A fuse.
• For Installation on boats up to 7.5m (25 ft). Isolation kit (39-0203) MUST be used on boats with conductive
hulls.
