- Page 1 LabelManager 360D ® User Guide...
- Page 2 © 2019 Newell Rubbermaid Europe, LLC. All rights reserved. Rev. 7/19 No part of this document may be reproduced or transmitted in any form or by any means or translated into another language without the prior written consent of Newell Rubbermaid Europe, LLC.
-
Page 3: Table Of Contents
Contents About Your New Label Maker ............2 Product Registration................2 Getting Started ................2 Connecting the Power ................2 Inserting the Battery Pack..............3 Recharging the Battery Pack..............3 Inserting the Label Cassette ..............4 Using the Label Maker for the First Time ........6 Getting to Know the Label Maker ..........7 Power ...................... - Page 4 Aligning the Text ................... 14 Creating Fixed-Length Labels ..............15 Creating Two-Line Labels ..............16 Using Clip Art, Symbols, and Special Characters ......17 Adding Clip Art ..................17 Adding Symbols ..................18 Using the Symbol Keys ................18 Adding International Characters ............19 Printing Options ...............
- Page 5 16 17 18 19 20 21 22 23 24 Figure 1 DYMO® LabelManager 360D Electronic Label Maker 17 Format Cutter button Accented character Print 10 Space bar 18 Open 11 Insert 19 AC Power adapter Backspace 12 Caps 20 Navigation Symbols - Punctuation 13 Numeric keys 21 LCD display...
-
Page 6: About Your New Label Maker
About Your New Label Maker With the DYMO® LabelManager 360D electronic label maker, you can create a wide variety of high-quality, self-adhesive labels. You can choose to print your labels in many different fonts, font sizes, and styles. The label maker uses DYMO D1 label cassettes in widths of 6 mm (1/4”), 9 mm (3/8”), 12 mm (1/2”), or 19 mm (3/4"). -
Page 7: Inserting The Battery Pack
Inserting the Battery Pack The battery pack included with your label maker comes partially charged. You do not need to charge the battery pack before using your label maker for the first time. To insert the battery pack Figure 2 Slide the battery compartment cover away from the label maker. -
Page 8: Inserting The Label Cassette
To recharge the battery pack Plug the power adapter into the power connector on the top of the label maker. Plug the other end of the power adapter into a power outlet. Inserting the Label Cassette Your label maker comes with one label cassette. - Page 9 Before using the label maker for the first time, remove the protective cardboard insert from the label exit slot. See Figure 4. Insert the cassette with the label facing up and positioned between the label guides. Click! Figure 5 Press firmly until cassette clicks into place. See Figure 5.
-
Page 10: Using The Label Maker For The First Time
Using the Label Maker for the First Time The first time you turn on the power, you are asked to select the language and label width. These selections remain set until you change them. You can change these selections using the key. -
Page 11: Getting To Know The Label Maker
Getting to Know the Label Maker Become familiar with the location of the feature and function keys on your label maker. Refer to Figure 1. The following sections describe each feature in detail. Power button turns the power on and off. After two minutes of inactivity, the power is switched off automatically. -
Page 12: Lcd Display
LCD Display The display can show two lines of text at a time. The number of characters displayed on each line will vary due to proportional spacing. With DYMO’ s exclusive graphical display, most of the formatting you add is visible instantly. -
Page 13: Format
Format key displays the Font, Font Size, Style, Borders and Underline, Format Label Length, Alignment, and Mirror submenus. These formatting features are described later in this User Guide. Insert key allows you to insert symbols, clip art, or saved text on Insert your label. -
Page 14: Navigation Keys
Navigation Keys You can review and edit your label using the left and right navigation keys. You can also navigate through menu selections using the up and down navigation keys, and then press to make a selection. Cancel key allows you to exit from a menu without making a selection or Canc el to cancel an action. -
Page 15: Formatting Your Label
Formatting Your Label You can choose from several format options to enhance the appearance of your labels. Font type Mirror Font size Alignment Font style Label length Borders/Underline To adjust the formatting Press Format Use the navigation keys to select the formatting option to change and press Select the option to apply to your label and press... -
Page 16: Font Type
Font Type Three font types are available for your labels: Basic Serif Use the up and down navigation keys to select the font type. Font Size Seven font sizes are available for your labels: The font sizes available depend on the label width you have selected. The font size applies to all characters on a label. -
Page 17: Font Styles
Font Styles You can choose from six different font styles: Normal Bold Italic Outline Shadow Vertical Use the up and down navigation keys to select the font style. Adding Borders and Underline Styles You can highlight your text by choosing a border or underline style. Underline Parchment Square... -
Page 18: Using Mirror Text
Use the up and down navigation keys to select the border or underline style. A label can be underlined or enclosed in a border, but not both together. When using borders on two-line labels, both lines are enclosed in one border. When using underline on two-line labels, both lines are underlined. -
Page 19: Creating Fixed-Length Labels
Creating Fixed-Length Labels Normally, the length of the label is determined by the length of the text. However, you can choose to set the length of the label for a specific application. When you choose a fixed label length, the size of the label text is automatically adjusted to fit the label. -
Page 20: Creating Two-Line Labels
Creating Two-Line Labels You can print a maximum of two lines on a label. Only one line of text can be printed on 6 mm (1/4") labels. To create a two-line label Type the text for the first line and press Type the text for the second line. -
Page 21: Using Clip Art, Symbols, And Special Characters
Using Clip Art, Symbols, and Special Characters Clip art, symbols, punctuation, and other special characters can be added to your labels. Adding Clip Art The label maker includes the clip art shown below. ↔ © ® ™ ☺ ♠ ♣ ♥... -
Page 22: Adding Symbols
Adding Symbols The label maker supports the extended symbol set shown below. ₅ ₆ ₇ ₈ ₉ ¹ ² ³ " ⁴ ⁰ ’ ¡ ¿ ⁵ ⁶ ⁷ ⁸ ⁹ α β γ δ ε & ‰ ζ η θ... -
Page 23: Adding International Characters
To quickly add symbols Press one of the following: • to add a general symbol. • to add a punctuation mark. • to add a currency symbol. Select the symbol you want and press Adding International Characters The label maker supports the extended Latin character set. After pressing the Accent key, pressing a letter brings up a menu containing all the available variations of that letter. -
Page 24: Printing Options
Printing Options You can preview your label and print multiple labels. Previewing Your Label You can preview the text and formatting of your label prior to printing. To preview your label Press The label length is displayed. Then, if necessary, the text of the label scrolls across the display. -
Page 25: Using The Label Maker Memory
Using the Label Maker Memory The label maker has a powerful memory feature that allows you to save the text of up to nine frequently-used labels. You can recall saved labels and you can insert saved text into a label. Saving a Label You can save up to nine frequently-used labels. -
Page 26: Inserting Saved Text
Inserting Saved Text You can insert the text of a saved label into the current label. Only the saved text is inserted, not the formatting. To insert saved text Position the cursor at the location in the label where you want to insert the text. -
Page 27: Caring For Your Label Maker
Caring for Your Label Maker Your label maker is designed to give you long and trouble-free service, while requiring very little maintenance. Clean your label maker from time to time to keep it working properly. Clean the cutter blade each time you replace the label cassette. -
Page 28: Troubleshooting
Troubleshooting Review the following possible solutions if you encounter a problem while using your label maker. Problem/Error Message Solution • Ensure the label maker is turned on. • Attach the power adapter to recharge the No display Recharging the battery pack. See Battery Pack •... -
Page 29: Rechargeable Battery Safety Precautions
Problem/Error Message Solution Battery Failure! • Ensure the battery pack is inserted correctly. Inserting the Battery Pack Battery pack not inserted properly or damaged. • Replace the battery pack. Wait - Battery Charging Allow the battery pack to recharge before unplugging the label maker. - Page 30 Warning • Stop charging the battery if charging is not completed within three hours. Caution • Do not use the label maker or battery in a place that generates static electricity. • Use the label maker only at room temperature. •...
-
Page 31: Environmental Information
Environmental Information The equipment that you have bought requires the extraction and use of natural resources for its production. It may contain substances that are hazardous to health and the environment. In order to avoid the dissemination of those substances in our environment, and to diminish the pressure on natural resources, we encourage you to use the appropriate take-back systems.
