Installing the 861
Reference Digital
Surround Controller
SpeakerLink outputs – OE34
Use this output
L+R, C+SUB, SIDE
L+R, REAR L+R
Digital inputs – IE44
Use this input
D1 (CD), D2, D3, D4
(Sat), D5, and D6*
MD1 (DVD) and MD2
(using D1-D3 and
D4-D6)
O1 (Game) and O2
SL1 (Disc)
MMHR
To connect to this
Digital loudspeakers, using
Meridian SpeakerLink leads
or standard CAT5 network
cables. The Master speaker
must be connected to the
appropriate socket on the
right-hand column.
To connect to this
The digital output of a source
such as a DVD player.
The multichannel digital output
of an MHR SmartLink source.
The optical output of a source
such as a satellite receiver or
computer.
The SpeakerLink output of
a Meridian source with a
SpeakerLink output.
A multichannel digital source
with an MMHR output, such
as the Meridian HD621 HDMI
Audio Processor.
Extra digital inputs – ID29
Use this input To connect to this
O1 to O3 The optical output of a source
such as a satellite receiver or
computer.
USB INPUT U1 (VCR2) A personal computer USB
socket.
SL1 and SL2 The SpeakerLink output of
a Meridian source with a
SpeakerLink output
Sooloos connections – ID41 (optional)
Use this connection To connect to this
NETWORK (SLS) An Ethernet network, for use
in a Sooloos system.
USB For maintenance only.
Communications connections – CO00
Use this connection To connect to this
MERIDIAN COMMS Other Meridian equipment, or
Meridian DSP loudspeakers.
RS232 A computer, for configuring the
861, or a serial control system.
TRIGGER 1, 2, and 3 Equipment that can be
triggered by a 12V 100mA
signal.
