Standard and optional cards
The following diagram shows the cards supplied as standard to the 861, and the optional cards (shown in
brackets):
IA04
Analogue inputs – IA04
Use this output To connect to this
ANALOGUE IN A1+A2, The analogue outputs of a
A3+A4 (Radio), A5+A6 source, such as a TV or tape
(TV), B1+B2 (Tape), deck.
B3+B4 (Cable/VCR1),
B5+B6*
Extra analogue inputs – IA04 (optional)
Use this output To connect to this
ANALOGUE IN A1+A2, The analogue outputs of a
A3+A4, A5+A6, B1+B2, source, such as a TV or tape
B3+B4, B5+B6* deck.
* In each case the odd-numbered input is the left
channel and the even-numbered is the right channel.
Alternatively A1-A6 and B1-B6 can each be configured
as a single 6-channel input.
(OA18) (OA18)
OE34 + IE44
(OA08) (OA08)
Balanced outputs – OA18 x 2 (optional)
Unbalanced outputs – OA08 x 2
(optional)
CO00 (IA04) (ID41) ID29
Use this output To connect to this
1 to 4 and 1 to 4 The balanced analogue inputs
of a preamplifier, or a power
amplifier such as the G57,
using XLR leads.
Use this output To connect to this
1 to 4 and 1 to 4 The unbalanced analogue
inputs of a preamplifier, or a
power amplifier such as the
G57, using analogue phono
leads.
IEC
37
Installing the 861
Reference Digital
Surround Controller
