Speakerlink Controls - Meridian 861v8 User Manual

SpeakerLink controls

Certain Meridian DSP loudspeakers provide additional
digital processing features that can be controlled by the
861.
To access these features you need to:
• Connect to the DSP loudspeakers via the
SpeakerLink connection.
• Enable the SpeakerLink controls using the Meridian
Configuration Application (see Installing the Meridian
Configuration Application, page 57), or via the
SpeakerLink menu (see Setting up SpeakerLink ,
page 55).
The settings for each control are stored in the DSP
preset (see Defining your own presets , page 26),
allowing you to customise the settings for each source.
The Centre Elevation control raises the image
projected by the centre speaker. This creates a
much more involving movie experience, with superior
image integration across the whole width of the audio
presentation.
The Enhanced Bass Alignment control improves
the presentation of music. Note that the extra
processing adds a time delay, so it should be disabled
for video sources.
You may need to update the firmware in your DSP
loudspeakers to access these features.
To change the Centre Elevation
• Press < or > until the display shows the current
Centre Elevation setting.
For example: DVD
Press up or down to select between Off, Min, Med,
or Max.
To change the Enhanced Bass
Alignment
• Press < or > until the display shows the current
Enhanced Bass Alignment setting.
For example:
Press A or V to choose between On or Off.
C.Elev. Med
CD EBA On
23
Customising the 861
Reference Digital
Surround Controller
