Audio Technica AT-LP70X Quick Start Manual

AT-LP70X
Quick Start Guide
Automatic Belt-Drive Turntable
Guide de démarrage rapide
Automaattinen hihnakäyttöinen levysoitin
Kurzanleitung
Automatischer riemenbetriebener Plattenspieler
Guida rapida
Giradischi automatico a trasmissione cinghia
Guía de inicio rápido
Giradiscos automático de transmisión por correa
Guia de início rápido
Toca-discos automático acionado por correia
Краткое руководство по установке
Автоматический проигрыватель с ременным приводом
快速启动指南
自动皮带传动唱盘机
快速入門指南
全自動皮帶式驅動黑膠唱盤機
간편 사용 설명서
오토매틱 벨트 드라이브 턴테이블
Audio-Technica Corporation
2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan
www.audio-technica.com
©2024 Audio-Technica Corporation
Global Support Contact: www.at-globalsupport.com
351709390-01-01
Contents
Turntable body
Dust cover
45 RPM adapter AC adapter
User Manual (Online Manual)
https://www.audio-technica.co.jp/document/AT-LP70X/Default.html
Support
For more information on how to use this product and troubleshoot any problems, refer to the user
manual on the Audio-Technica website.
Support
Pour plus d'informations sur l'utilisation de ce produit et la résolution des problèmes, reportez-vous
au manuel de l'utilisateur sur le site Web d'Audio-Technica.
Unterstützung
Weitere Informationen zum Gebrauch dieses Produkts und zur Behebung eventueller Probleme
entnehmen Sie bitte der Bedienungsanleitung auf der Website von Audio-Technica.
Assistenza
Per maggiori informazioni sull'utilizzo del presente prodotto e per la risoluzione di eventuali
problemi, fare riferimento al manuale dell'utente sul sito Audio-Technica.
Asistencia
Para más información sobre el uso de este producto y la resolución de problemas, consulte el
manual de usuario en el sitio web de Audio-Technica.
Suporte
Para obter mais informações sobre como usar este produto e solucionar qualquer problema,
consulte o manual do usuário no site da Audio-Technica.
Техническая поддержка
Для получения дополнительной информации о том, как использовать этот продукт и устранять любые
неисправности, обратитесь к руководству пользователя на веб-сайте Audio-Technica.
支持信息
关于如何使⽤本产品及解决各种问题的详细信息， 请参阅 "铁三⾓" ⽹站上的⽤户⼿册。
支援資訊
有關本產品的使⽤⽅法以及各種問題的故障排除⽅法 ，請參閱 「鐵三⾓」 網站上的使⽤說明書
지원
본 제품의 사용법 및 문제 해결에 관한 자세한 사항은 Audio-Technica 웹사이트의 사용자 설명서를 참조하십
시오 .
ver.1 2024.02.01
Platter (with drive belt)
Felt mat
RCA audio cable
Preparation
1
Set the platter.
Motor pulley
(brass-colored)
2
Attach the drive belt to the motor pulley (brass-colored).
3
Remove the red ribbon from the drive belt.
Drive belt 4
Set the felt mat.
Dust cover hinges
5
Mount the product on a level surface.
Connection
This product has a built-in phono equalizer function. You can use the product, even if you do not have
a phono amplifier or connectable equipment with a built-in phono amplifier, by connecting an active
speaker, etc. Use the pre-amplifier selector switch to set the output.
With PHONO input
Without PHONO input
Amplifier /
Speaker
With PHONO input Without PHONO input
PHONO LINE/AUX
L R L R
